Epigenetic and Genetic Integrity, Metabolic Stability, and Field Performance of Cryopreserved Plants

Min-Rui Wang^1,2, Wenlu Bi³ , Mukund R. Shukla³ , Li Ren⁴, Zhibo Hamborg⁵ , Dag-Ragnar Blystad⁵, Praveen K. Saxena³ and Qiao-Chun Wang^2,*

Citation: Wang, M.-R.; Bi, W.; Shukla, M.R.; Ren, L.; Hamborg, Z.; Blystad, D.-R.; Saxena, P.K.; Wang, Q.-C.

Epigenetic and Genetic Integrity, Metabolic Stability, and Field Performance of Cryopreserved Plants.

Plants2021,10, 1889. https://

doi.org/10.3390/plants10091889

Academic Editor: Panayiotis Dimitrakopoulos

Received: 12 August 2021 Accepted: 7 September 2021 Published: 13 September 2021

Publisher’s Note:MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affil- iations.

Licensee MDPI, Basel, Switzerland.

This article is an open access article distributed under the terms and conditions of the Creative Commons Attribution (CC BY) license (https://

creativecommons.org/licenses/by/

4.0/).

1 State Key Laboratory of Crop Stress Biology for Arid Areas, College of Life Science,

Northwest A&F University, Yangling District, Xianyang 712100, China; [email protected]

2 State Key Laboratory of Crop Stress Biology for Arid Areas, College of Horticulture, Northwest A&F University, Yangling District, Xianyang 712100, China

3 Department of Plant Agriculture, Gosling Research Institute for Plant Preservation, University of Guelph, Guelph, ON N1G 2W1, Canada; [email protected] (W.B.); [email protected] (M.R.S.);

[email protected] (P.K.S.)

4 Institute for Agri-Food Standards and Testing Technology, Shanghai Academy of Agricultural Sciences, Shanghai 201403, China; [email protected]

5 Division of Biotechnology and Plant Health, Norwegian Institute of Bioeconomy Research (NIBIO), 1431 Ås, Norway; [email protected] (Z.H.); [email protected] (D.-R.B.)

* Correspondence: [email protected]

Abstract:Cryopreservation is considered an ideal strategy for the long-term preservation of plant genetic resources. Significant progress was achieved over the past several decades, resulting in the successful cryopreservation of the genetic resources of diverse plant species. Cryopreservation procedures often employ in vitro culture techniques and require the precise control of several steps, such as the excision of explants, preculture, osmo- and cryoprotection, dehydration, freeze-thaw cycle, unloading, and post-culture for the recovery of plants. These processes create a stressful environment and cause reactive oxygen species (ROS)-induced oxidative stress, which is detrimental to the growth and regeneration of tissues and plants from cryopreserved tissues. ROS-induced oxidative stresses were documented to induce (epi)genetic and somatic variations. Therefore, the development of true-to-type regenerants of the source germplasm is of primary concern in the application of plant cryopreservation technology. The present article provides a comprehensive assessment of epigenetic and genetic integrity, metabolic stability, and field performance of cryopreserved plants developed in the past decade. Potential areas and the directions of future research in plant cryopreservation are also proposed.

Keywords:cryopreservation; (epi)genetic integrity; field performance; metabolic stability; reactive oxygen species; shoot tips; tissue culture

1. Overall Developments and Progresses in Plant Cryopreservation

Cryopreservation refers to the storage of biological samples, such as cells, tissues, and organs, in liquid nitrogen (LN) at extremely low temperatures, usually−196^◦C. The motive of initial studies was to establish cryopreservation methods for the long-term preservation of plant genetic resources [1,2]. Since the first success of plant cryopreservation using the two-step freezing of mulberry (Morus alba) by Sakai [1], considerable progress has been made in the field over the past 65 years [3–6]. Successful cryopreservation studies resulted in a number of technical advancements, including the development of various cryopreservation methods, such as vitrification [7–9], encapsulation-vitrification [9,10], droplet- vitrification [11], encapsulation-dehydration [10,12] and the use of cryo-plates [13,14]. Of these, the droplet-vitrification method, described by Panis et al. [11], is noteworthy as it has largely helped to remove the genotype-specific barriers, which had impeded the

Plants2021,10, 1889. https://doi.org/10.3390/plants10091889 https://www.mdpi.com/journal/plants

(2)

potential application of cryopreservation technology across diverse species. These technical refinements led to the successful cryopreservation of a wide range of genotypes in many plant species, such asMalus[15],Vitis[16,17], andLilium[18]. The cryopreservation technology is considered an ideal strategy for the long-term preservation of plant genetic resources [3–6].

Diverse plant species have been successfully cryopreserved, including tuber crops [19,20], fruit crops [15,21], ornamental species [22], medicinal herbs [23], and forest species [24], as well as endangered and endemic plants [25–29]. Cryo-banks using shoot tips have been set up in several countries for economically important plant species [3,4,20,23,30,31]. Studies have also advanced in the evaluation of the performance of cryo-derived plants when they are re-introduced from laboratories to their natural habitat [25,28,32].

Cryopreservation has been shown to retain or even promote the regenerative capacity of embryogenic tissues, which were widely used in genetic transformation in various plant species [31,33]. The use of cryopreserved embryogenic tissues for genetic transformation improved the transformation efficiency and regeneration frequency of transformed plant tissues [34]. Cryopreservation was shown to maintain the transgenes in transformed materials, providing a safe and reliable strategy for the long-term preservation of transgenes [31,33,34]. These studies demonstrated the usefulness of cryobiotechnology in plant genetic engineering.

Shoot tip cryotherapy, which was refined based on shoot tip cryopreservation, has been established as a novel method for the efficient eradication of plant pathogens, including viruses, phytoplasma, and bacteria [31,35,36]. Cryopreservation has also been successfully applied to cryopreservation of plant viruses and viroids in cryopreserved shoot tips [37–39], opening a new avenue for the long-term preservation of plant obligate pathogens, which are otherwise difficult-to-preserve for long periods with the traditional methods. Thus, cryobiotechnology offers the dual advantage in the preservation as well as eradication of plant pathogens [38,40].

A number of plant species have been threatened and are currently facing extinction, mainly by anthropogenic processes, such as deforestation, land clearing for agricultural, industrialization, and urbanization, as well as through plant diseases and pests [41,42].

Global warming has further worsened the situation. A recent report warned that about 21% of total global plant species (approximately 390,900 plants) are at risk of extinction [43].

Therefore, special attention should be paid to the cryopreservation of these endangered and rare species [41,42,44,45]. However, studies on cryopreservation of endangered and rare plant species are far behind those of horticultural species, ornamental plants, tuber crops, and forest species [6,15,19–29,41,42].

2. Major Concerns in Recovery of Plants from Cryopreserved Tissues

For the preservation of plant genetic resources, it is necessary to not only ensure viability and quality of the preserved plants, but to also ensure the true-to-type status of the regenerants (Figure1). Shoot tips or buds are able to develop into plants that are generally genetically stable and identical to the source plants, and are therefore preferred over other tissues, such as cell suspensions, embryogenic tissues, and callus for preserving plant genetic resources [6,31,46–48].

In vitro tissue culture has become an integral part of the cryopreservation technology currently used for the establishment and maintenance of stock cultures, and the post- culture process for the recovery of shoot tips, cell suspensions, and embryogenic tissues, in a number of plant species [6,31,46,48]. However, in vitro tissue cultures are prone to somaclonal and (epi)genetic variations [49–52]. It is well documented that in vitro tissue culture imposes stressful conditions and induces the generations of reactive oxygen species (ROS), thus resulting in ROS-induced oxidative stress [49–51]. Cryopreservation requires the use of plant tissue culture methods in several essential steps, including the excision of explants, preculture, osmo- and cryoprotection, dehydration, freeze-thaw cycle, unloading,

(3)

and the re-initiation of cultures for plant recovery. All of these steps have been shown to cause ROS-induced oxidative stress [4,26,47,53–55].

Figure 1.General cryopreservation procedures (black arrows), post-culture for recovery and re-establishment of plants in vivo (blue arrows), assessments of (epi)genetic stability and evaluations of field performance in cryo-derived regenerants/plants (red arrows), and measures taken to ensure (epi)genetic stability and true-to-type regenerants/plants recovered after cryopreservation (green arrows). DMSO, dimethyl sulfoxide; LN, liquid nitrogen; PGRs, plant growth regulators.

ROS are highly reactive and toxic by-products of aerobic metabolism. ROS include the superoxide anion, hydrogen peroxide, and hydroxyl radicals, all of which have inherent re- activity to different biological targets, playing a dual role of inducing cellular toxicity, while also serving as signaling transduction stimuli in plant responses [56,57]. The ROS-induced oxidative stresses have proven to induce the somaclonal and (epi)genetic variations in in vitro-derived regenerants [49–51,58] and in cryo-derived regenerants [4,26,47,53–55].

Therefore, it is necessary to assess and monitor the (epi)genetic integrity and field performance of cryo-derived regenerants. Literature (up to 2010) on relevant aspects of such genetic variations in plants originating from in vitro and cryopreserved cultures was comprehensively reviewed previously [31,41,42,47,53–55].

The present review focuses on the advances made in the past decade in the assessment and improvement of the (epi)genetic integrity, metabolic efficiency, and field performance of cryo-derived plants. Research areas and applications that may benefit from further studies on plant cryopreservation are also discussed. These efforts would certainly promote further studies on cryopreservation of endangered and rare plant species.

3. Assessments of Epigenetic and Genetic Integrity 3.1. Epigenetic Integrity

Epigenetics refers to heritable changes in gene expression that is not associated with changes in the underlying DNA sequence [59]. Major types of epigenetic changes include DNA methylation, histone modification, and changes in chromatin structure [60]. DNA methylation has been widely used for the assessments of epigenetic integrity in cryo- derived plants [47,53–55] and methylation-sensitive amplified polymorphism (MSAP) is the most frequently used marker for the assessments of epigenetic stability in plant populations of cryogenic origin.

Hao et al. [61–63] were the first to assess epigenetic stability in cryo-derived regenerants. Changes in DNA methylation were detected in plants recovered from the cryopreserved shoot tips ofMalus pumila“M2” andFragaria gracilis“Joho” [61,63], and somatic embryogenic calli ofCitrus sinensis“Newhall” [62]. Some representative examples of the

(4)

use of DNA methylation-induced changes in cryopreservation research in the past decade are listed in Table1.

Peredo et al. [64] assessed epigenetic integrity inHumulus lupulusplants recovered from shoot tips cryopreserved for three years. Changes in DNA methylation were detected in 36% of the loci. Further analysis showed that only 2.6–9.8% of the changes were induced by cryopreservation procedure and the rest were attributed to the in vitro culture processes.

In vitro culture-induced DNA methylation was also found in the regenerants recovered from cryopreservedCarica papayashoot tips [65] andTheobroma cacaosomatic embryos [66].

DNA methylation levels were higher in in vitro stock somatic embryos ofTheobroma cacao than those regenerated after cryopreservation [66]. Therefore, the manipulations of in vitro culture procedures, particularly for regeneration via somatic embryogenic, are needed to reduce the probability of alternations in DNA methylation.

Alternations in DNA methylation varied with cryogenic steps and cryopreservation durations: 0.12% following PVS2 treatment, 0.12% after 2 h of cryo-storage, and 5.5% after 10 years of cryo-storage inWasabia japonica[67]. Variations in DNA methylation varied among threeRibesspecies, includingR. ciliatum,R. sanguineumandR. nigrum[68], and Humulus lupulus[64], andCarica papayagenotypes [65] subjected to cryopreservation. The assessment of epigenetic stability in the regenerants of the sameCarica papayagenotype Z6 following cryopreservation detected higher levels of DNA methylation in DNA extracts pooled from mixed leaves of several plants [65] than in those from single leaves of single plants [69]. These data indicated that variations in DNA methylation differed among clones resulted from the same cryopreservation experiment.

Johnston et al. [68] reported DNA methylation in regenerants recovered fromRibes cilia- tumshoot tips cryopreserved by encapsulation-dehydration. They found that DNA methylation initially occurred during sucrose preculture and progressively increased during successive steps of the encapsulation-dehydration protocol. However, DNA methylation values were similar between the controls and the regenerants recovered from cryopreserved shoots after 18–20 weeks of post-recovery, including two subculture cycles. These data indicate that cryopreservation-mediated DNA methylation is a reversible epigenetic mechanism [68]. Such reversible epigenetic mechanism has also been noted in the regenerants recovered from cryopreserved shoot tips ofCarica papaya[65],Mentha×piperita[70], andActinidia chinensisvar.deliciosa[71], and from the cryopreserved somatic embryos of Bactris gasipaes[72] andTheobroma cacao[66]. As speculated by Harding et al. [54], changes in DNA methylation may be an adaptive response to oxidative stress induced during cryopreservation. Therefore, once the stress is removed, DNA demethylation occurs and the regenerants can gradually revert to the normal DNA status.

In contrast with the studies addressed above, no marked alternations in DNA methylation were found in the regenerants recovered fromQuercus roburplumules cryopreserved by desiccation [73],Solanum tuberosumplants from shoot tips preserved with dimethyl sulfoxide (DMSO)-droplet method and cryo-stored for nearly 7 years [74],Wasabia japonica plants from vitrified shoot tips cryo-stored for 10 years [68], andGentiana cruciataregener- ants from embryogenic cell suspensions cryopreserved by encapsulation-dehydration [75].

(5)

Table 1.Some examples from the past decade of epigenetic integrity assessments by DNA methylation in regenerants recovered after cryopreservation.

Plant Species Explants Cryopreservation

Method * Molecular Methods ** DNA

Methylation (%) Causes Reference

Actinidia chinensisvar.deliciosa Shoot tips Drop-vitri MSAP 1.6 and 12.8 Cryoprocedures and in vitro cultures [71]

Bactris gasipaes Somatic embryos Drop-vitri The global DNA methylation 25.2–29.7 Cryoprocedures [72]

Carica papaya Shoot tips Vitri AMP 0–0.22 Genotypes and cryoprocedures [65]

Gentiana Shoot tips Encap-dehy MSAP 16.61–16.88 in vitro culture [75]

Mentha×piperita Shoot tips Encap-dehy MSAP 17.1–32 Cryoprocedures [70]

Quercus robur Seed plumules Desiccation The global DNA methylation 8.7–11 Cryoprocedures [73]

Solanum tuberosum Shoot tips DMSO droplet MSAP 0.9 Cryoprocedures and in vitro cultures [74]

Theobroma cacao Somatic embryos Encap-dehy MSAP 3.6 Cryoprocedures [66]

Wasabia japonica Shoot tips Vitri MSAP 0.12–5.5 Cryoprocedures [67]

* Dehy, dehydration; DMSO, dimethyl sulfoxide; Drop, droplet; Encap, encapsulation; Vitri, vitrification. ** AMP, amplified DNA methylation polymorphism; MSAP, methylation sensitive amplified polymorphism.

(6)

3.2. Genetic Integrity

Molecular markers were widely used for assessments of genetic stability in cryo- derived plants, including random amplified polymorphic DNA (RAPD), inter-simple sequence repeats (ISSR), amplified fragment length polymorphism (AFLP), and single sequence repeats (SSR) [53–55]. The RAPD amplifies some areas of the genome and screens a low fraction of the genome, whereas the ISSR amplifies DNA segments between two microsatellite regions [54]. The AFLP technique is based on the selective amplification of restriction fragments from a total digest of genomic DNA [76], and the SSR can detect differences in the length of a particular locus [77,78]. Since different DNA markers detect polymorphisms in different genomic regions, use of more than one molecular marker would provide more reliable results of genetic integrity assessments [31,79]. Therefore, most of the studies conducted in the past decade employed more than one molecular marker for assessments of genetic stability in the regenerants recovered from cryopreservation. Flow cytometry (FCM) was usually used for assessments of DNA ploidy levels in cryopreserved plants [80–82].

Krajnákováet al. [83] reported some changes in the RAPD profiles ofAbies cephalonica embryogenic cells after six years of cryopreservation. However, proliferation and maturation abilities were maintained in the cryopreserved cells. Applying microsatellite and sequence-related amplified polymorphism (SRAP) for assessments of the genetic stability in the cryo-derived plants ofHedeoma todseniiafter 13 years of cryo-storage, Pence et al. [84]

did not find any DNA variations in the same genotypes, but found an average of 10.4%

variation between the replicate samples. Genetic variations were observed in the regenerants recovered from cryopreserved shoot tips ofChrysanthemum morifolium, with 40%

and 6% of polymorphic bands detected by AFLP and RAPD, respectively [85]. Further analysis found that the genetic variations detected by RAPD were induced in the sucrose preculture step (0.3 M sucrose at 5^◦C for 3 days), while those detected by AFLP were in the cold-hardening of the in vitro stock shoots (10^◦C for 3 weeks). Freezing in LN induced the highest levels of genetic variations analyzed by both RAPD and AFLP [85]. Applying RAPD to assessments of genetic stability in the regenerants recovered from cryopreserved shoot tips ofMentha×piperita, Martín et al. [86] reported that genetic stability varied with genotypes and cryoprocedures: 97% by droplet-vitrification and 87% by encapsulation- dehydration in “MEN 198” (stable genotype), and 80% by droplet-vitrification and 24%

by encapsulation-dehydration in “MEN 186” (sensitive genotype). In the analysis of the genetic stability by FCM, RAPD, and ISSR in the cryo-derived plants of threeChrysanthe- mum chimericcultivars grown in greenhouse conditions, Kulus et al. [80] reported that FCM did not detect any differences in DNA ploidy levels among the three cultivars. RAPD detected no polymorphic bands in “Richmond” (a solid mutant), but detected 7.8% and 3.2% polymorphic bands in “Lady Orange” and “Lady Salmon” (periclinal chimeras). ISSR markers detected 15% polymorphic bands in “Lady Orange” and no polymorphic bands in

“Lady Salmon” and “Richmond” [80].

González-Benito et al. [87] tested the effects of adding vitamin E in the pretreatment medium on cryopreservation and genetic stability in “MEN 186” and “MEN 198”. They found that although it did not have significant effects on recovery, vitamin E improved the genetic stability in the regenerants recovered after cryopreservation, particularly in the sensitive genotype “MEN 186”.

In the cryopreservation ofRubus grabowskiishoot tips, Castillo et al. [88] reported that the SSR did not detect any polymorphic bands in the cryo-derived regenerants immediately after cryopreservation and those that were subcultured in vitro for seven months after the recovery. The AFLP did not detect any polymorphic bands in the cryo-derived regenerants immediately after cryopreservation, but detected polymorphic bands in the cryo-derived shoots that were subcultured in vitro for seven months. However, when these in vitro cultured shoots were re-established in the field conditions, polymorphic bands were no longer detected [88]. These results indicated that there might be a transitory phase of the polymorphism when the cryopreserved plants were transferred to the field conditions.

(7)

Similar results were also found in the cryo-derived plants ofAbies cephalonica[89] and Carica papaya [65]. Nevertheless, further studies are needed to verify these findings of varied polymorphism in plants from cryopreserved tissues.

A number of studies showed that cryopreservation did not cause or caused minor changes in genetic stability of the regenerants. Genetic stability assessments in the regenerants ofWasabia japonicafollowing shoot tip cryopreservation detected only 0.27%, 0.95%, and 2.2% variations in AFLP profiles in the samples following exposure to PVS2, cryo-storage in LN for 2 h, and for 10 years, respectively [67]. RAPD and ISSR did not detect any polymorphic bands in the plants recovered from cryopreservation ofPassiflora pohlii nodal segments [90]. The maintenance of genetic stability was reported in the regenerants recovered after shoot tip cryopreservation in various plant species, including tuber crops such asSolanum tuberosum,analyzed by ISSR and FCM [91] and by AFLP and ISSR [79].

The ornamental plant analyses includedOncidium flexuosumby FCM [92],Chrysanthemum morifoliumby SSR and FCM [82] and RAPD and ISSR [93],Argyranthemumby AFLP and ISSR [94],Torenia fournieriby FCM and ISSR [95], andPleione bulbocodioides(protocorm-like bodies) by ISSR [96]. Similar results were obtained in vegetable crops, such asPhaseolus vulgariss(seeds) by SSR [97],Asparagus officinalis(rhizome buds) by EST-SSR and FCM [98], andAlliumby SSR [81], AFLP and ISSR [99]. Examples of analyses of other crops included fruit trees, such asMusa(suck meristem) by SSR [100],Malusby FCM and ISSR [101,102], Vaccinium corymbosumby RAPD and ISSR [103,104],Vitis by RAPD and ISSR [17], and Actinidia chinensisby AFLP and ISSR [71], and medicinal species, such asRabdosia rubescens by FCM and SRAP [105] andBacopa monnieriby RAPD [106].

Thus far, there were only a few studies that assessed the genetic stability in pathogen- free plants recovered after shoot tip cryotherapy. FCM did not detect any variations in ploidy levels in Chinese jujube plants (Ziziphus jujuba), free of Jujube witches’ broom phytoplasma [107], and artichoke plants (Cynara scolymus), free of artichoke latent virus, produced by shoot tip cryotherapy [108]. The SSR and AFLP did not detect any polymorphic bands in cryo-derived potato plants (Solanum tuberosum) free of potato leafroll virus, potato virus S, and potato virus Y [109].

Cryopreservation was reported to maintain theNPTIIandGUSgenes in transgenic Oryza sativaprotoplasts [110],hCTlA4Igin the transgenic cell suspensions ofO. sativa[111], Escherichia coli heat labile enterotoxin(LT) protein in the transgenic cells ofNicotiana tabacum[112], andnpt II and Gus genes in the transgenic sweetgum (Liquidambar) embryogenic cultures [113]. Similar examples of genes maintained in other species included the GUS gene in the transgenicCitruscallus [114],npt IIgene in the transgenic shoots ofBetula pendula[115] andPopulus tremula×P.tremuloides[116], human serum albumin in the transgenic BY-2 cell cultures [117],uidAgene in the transgenic plants ofCastanea sativa[118], and the Cry 1Ab in the transgenic plantlets ofTorenia fournieri[95]. The successful cryopreservation of transgenes provides a safe and reliable strategy for long-term preservation of the transgenic plant materials, which otherwise may be lost by preservation through in vitro cultures and environmental contamination or gene flow by preservation in vivo [33,34].

Some examples of genetic integrity assessments in cryo-derived regenerants are listed in Table2.

(8)

Table 2.Some examples from the past decade of genetic integrity assessments by molecular markers and FCM in regenerants recovered after cryopreservation.

Method * Molecular Markers ** Polymorphism (%) Causes Reference

Abies Embryogenic cells Vitri RAPD Not specified Cryoprocedures and

in vitro culture [83]

Actinidia chinensisvar.deliciosa Shoot tips Drop-vitri AFLP and ISSR None [71]

Allium cepavar.aggregatum Shoot tips Drop-vitri AFLP and ISSR None [99]

Allium sativum Shoot tips Vitri SSR and FCM None [71]

Arachis glabrata Leaflets Drop-vitri RAPD 0–3.4 Cryoprocedures [119]

Asparagus officinalis Rhizome buds Encap-dehy EST-SSR and FCM None [98]

Bacopa monnieri Shoot tips Vitri RAPD None [106]

Carica papaya Shoot tips Vitri RAF 0–0.7 Genotypes and

cryoprocedures [66]

Chrysanthemum×grandiforum Shoot tips Encap-dehy

ISSR 0–2 Genotypes and

cryoprocedures [80]

RAPD 0–7.8

FCM None

Chrysanthemum×morifolium Shoot tips

Encap-dehy AFLP 40.1

Sucrose preculture [85]

RAPD 5.78

Drop-vitri SSR None

FCM None [82]

Drop-vitri ISSR and RAPD None [93]

Cynara scolymus Shoot tips Vitri FCM None [108]

Hedeoma todsenii Shoot tips Encap-dehy and

Encap-vitri

Microsatellite 5.36–13.04 Genotypes and

cryoprocedures

[84]

SRAP 4.55–20.45 Genotypes and

cryoprocedures

Lotus tenuis Adventitious buds clusters Vitri ISSR 63 Cryoprocedures [120]

(9)

Table 2.Cont.

Malusspp. Shoot tips

Encap-dehy ISSR None [101]

Drop-vitri or

Encap-dehy ISSR and RAPD None [102]

Mentha×piperita Shoot tips

Drop-vitri

RAPD 30–40 Genotypes and

cryoprocedures [121]

cryoprocedures

[86]

Encap-dehy

cryoprocedures

AFLP 0–85.7 Genotypes,

cryoprocedures, and in vitro culture

RAPD 0–62 [87]

AFLP 2.65 Sucrose preculture and

encapsulation [70]

RAPD None

Musaspp. Sucker meristems Vitri SSR None [122]

Passiflora pohlii Nodal segments Encap-vitri ISSR and RAPD None [90]

Vitri ISSR and RAPD None

Phaseolus vulgaris Seeds Direct immersion into

LN SSR None [123]

Picea abies Embryogenic tissues Vitri SSR None [124]

Pinus nigra Embryogenic tissues Slow-freezing RAPD None [125]

Pistacia vera Shoot tips Vitri RAPD 5.4 Cryoprotants and

post-culture [126]

Pleione bulbocodioides Protocorm-like bodies Vitri ISSR None [96]

Rabdosia rubescens Shoot tips Encap-dehy SRAP 0.01 Cryoprocedures

[105]

FCM None

(10)

Table 2.Cont.

Saccharumspp. Shoot tips Drop-vitri ISSR 1.5 Cryoprotection [127]

Solanum tuberosum Shoot tips

Vitri AFLP and ISSR None [79]

Drop-vitri

ISSR and RAPD None [91]

Encap-vitri

Thymus lotocephalus Shoot tips Drop-vitri RAPD 0.06 Cryoprocedures [128]

Torenia fournieri Shoot tips Drop-vitri ISSRFCM None [95]

Triticum aestivum Calli Dehy ISSR None

[129]

REMAP 0.3 Cryoprocedures

Vaccinium corymbosum Shoot tips Drop-vitri ISSR and RAPD None [103]

Adventitious buds Drop-vitri ISSR and RAPD None [104]

Vitisspp. Shoot tips Drop-vitri ISSR and RAPD None [17]

Wasabia japonica Shoot tips Vitri AFLP 0.27–2.2 Cryoprocedures [67]

Ziziphus jujuba Shoot tips Drop-vitri FCM None [107]

* Dehy, dehydration; Drop, droplet; Encap, encapsulation; LN, liquid nitrogen; Vitri, vitrification. ** AFLP, amplified fragment length polymorphism; EST-SSR, expressed sequence tags-simple sequence repeats;

FCM, flow cytometry; ISSR, inter-simple sequence repeats; SRAP, sequence-related amplified polymorphism; SSR, simple sequence repeats; RAF, randomly amplified DNA fingerprinting; RAPD, random amplified polymorphic DNA; REMAP, retrotransposon-microsatellite amplified polymorphism.

(11)

4. Metabolic Stability

For plant species that contain special biochemical compounds, the assessment of metabolic abilities is an important issue in cryo-derived plants.Chrysanthemum morifolium

“Hangju” contains valuable biochemical compounds, such as anthocyanins and carotenoids, and has long been used as a medicine in China [93]. Applying high performance liquid chromatography (HPLC) for quantitative analyses of biochemical compounds in the cryo- derived plants grown in greenhouse conditions, Bi et al. observed no differences in the levels of the five selected biochemical compounds produced between the cryo-derived plants and in vitro-derived plants in the control [93]. No differences were found in the contents of anthocyanins and carotenoids in the inflorescences of the cryo-derived plants and the control of threeChrysantemum chimericcultivars grown in greenhouse conditions, except for reduced chlorophyll contents found in the cryo-derived plants [80]. InBacopa monnieri, HPLC analysis detected no differences in the level of bacoside A, a functional biocompound inBacopa monnieri, in the cryo- and in vitro-derived (control) plants [106].

More recently, Wang et al. [99] observed no significant differences in the levels of carbohy- drates and flavanols in bulbs produced by cryo- and in vitro-derived shallots plants grown in greenhouse conditions. These results indicate that metabolic stability can be maintained in the plants derived from cryopreserved tissues.

5. Field Performance

5.1. Seed Germination and Seedling Growth

Seed conservation provides a useful and relatively easy strategy for preserving genetic resources in seeded plants [41,130]. Three categories of seed storage behavior are generally recognized among species: orthodox, intermediate, and recalcitrant [41,130]. Seeds of most species belong to the orthodox category, and can be dried to low water contents and thus stored at low temperature for extensive periods [4,26,29,130]. Intermediate seeds can with- stand partial dehydration, while recalcitrant seeds are sensitive to dehydration. Therefore, they cannot be stored under the desiccation and low temperature conditions for a long period of time [4,26,29,41,130]. The intermediate and recalcitrant seeds contain numerous important tropical and tropical rain forest species [26,29,130]. Cryopreservation is the only technique available for long-term germplasm preservation of these two categories of seeds [4,26,29,130]. There were several studies conducted over the past decade on seed germination and seedling growth in cryopreserved seeds.

No significant differences in seed germinations were obtained between cryopreserved and non-cryopreserved (control) seeds in Phaseolus vulgaris [97,131], Solanum lycopersicum[132], andZea mays[133]. However, reduced seed germinations were reported in the cryopreserved seeds ofZea maysandGlycine max[133,134]. In the study of cryopreservation ofSolanum lycopersicumseeds, Zevallos et al. [135] reported that cryopreservation increased the germination percentage of cryopreserved seeds at day 5 of germination, albeit with no significant differences at day 7. Increased seed germinations were also observed in the cryopreserved seeds ofTeramnus labialisat 7 and 28 days of germination [136]. The increased seed germinations were attributed to the breaking of physical dormancy by increased malondialdehyde levels induced during cryopreservation [97,132,135,136].

More than 90% and 94% seedlings from the cryopreserved seeds ofOncidium flexuosum[92] andHibiscus sabdariffa[137], respectively, survived after transfer to greenhouse conditions. The morphology of the seedlings developed from cryopreserved seeds were similar to those from the control inPhaseolus vulgaris[97,131],Solanum lycopersicum[135], Zea mays[134],Glycine max[134], andHibiscus sabdariffa[137]. Seedling growth, measured by the fresh weight of roots, stem, and leaves, was markedly delayed in cryopreserved seeds ofZea mays[133]. Seedling growth, including plant height and fresh and dry mass, was greater in seedlings recovered from cryopreserved seeds than in those from the control during the four-week growth [136]. No differences were found in vegetative growth, including shoot length, number of leaves, number and length of roots, and fresh and dry weight, between the cryo-derived and the control seedlings inOncidium flexuosum[92].

(12)

Evaluating vegetative growth and grain production in cryo-seed-derived plants ofPhaseo- lus vulgaris, Cejas et al. [123] did not find significant differences in all parameters tested, including the number of stem internodes, plant height, fruit number, grain number per plant, and weight per grain between the cryopreserved and the control seeds. In addition, Cejas et al. [131] reported that seed cryopreservation decreased Cu, Cd, and Na uptake, and increased the absorption of B and Al in the cryo-derived seedling (10 days old) of Phaseolus vulgaris.

5.2. Field Performance of Cryopreserved Plants

Field performance is critical for evaluating the true-to-type cryopreserved plants in comparison to the source plants (Figure1). Similar survival percentages and vegetative growth were obtained for the cryo- and in vitro-derived (control) plants ofActinidia chinensisvar. deliciosaafter their re-establishment in greenhouse conditions [71]. Agrawal et al. [100] compared the field performance of cryo-derived, micropropagated, and field sucker-propagatedMusaplants and found that greater than 90% of the cryo-derived and in vitro micropropagated plants survived and were established in field conditions. Veg- etative growth (plant height and leaf number) and reproductive growth (flowering and fruit production) were similar among the three sources of plants [100]. Vegetative growth patterns, and morphologies of leaves and flower production, were identical in the cryo- and in vitro-derived plants ofTorenia fournieri[95] and Chrysanthemum morifolium [88]

when grown under greenhouse conditions. Wang et al. [99] reported that there were no significant differences in rooting, vegetative growth, and bulb production between the cryo- and in vitro-derived plants ofAllium cepavar.aggregatumwhen grown in the greenhouse.

Zhang et al. [94] reported that, although root formation and vegetative growth in cryo-derived plants was reduced to a certain degree, the quantity and quality of the flowers were similar in both the cryo- and in vitro-derived plants of perennial ornamental species Argyranthemumgrown in greenhouse conditions. Vegetative regrowth at the early stage was lower in cryo-derived plants ofChrysanthemum morifoliumgrown in the greenhouse [93]

andSolanum tuberosumcultured in vitro [91] than their corresponding controls. Vegetative growth markedly increased, however, in the cryo-derived plants ofSolanum tuberosumafter 6 months of in vitro culture [91]. Furthermore, in vitro microtuber production inSolanum tuberosumwas significantly greater in cryo-derived shoots than in the control [91].

Evaluating the field performance of cryo-derived plants of threeChrysanthemum× grandiforumchimeric cultivars Lady Orange, Lady Salmon, and Richmond, Kulus et al. [80]

found that some cryo-derived plants had shorter internodes and shorter and/or narrower leaves than the control plants. The inflorescences of Lady Salmon opened slower, but faded faster than the control. However, flower traits, including color, diameter, fresh weight, and length of ray florets, were similar between the cryo-derived plants and the control in all three cultivars.

5.3. Reintroduction of Cryo-Derived Plants to Nature

Castilleja levisecta,a hemiparasitic herbaceous plant, naturally inhabits British Colom- bia, Canada and the USA. This species is currently listed as an endangered plant in Canada and the USA. Recently, a cryopreservation method was described for this plant [32]. Cry- opreserved plants were successfully acclimated in greenhouse conditions. Acclimatized plants were reintroduced to their natural habitats in Canada and 21% of the reintroduced plants survived the transit from lab to the natural habitat and also showed flower development [32].

Hill’s thistle (Cirsium hillii) is also listed as a threatened species in Canada and its populations are restricted to alvars of Southern Ontario. Cryopreservation was applied for preserving germplasm of Hill’s thistle and cryopreserved plants were reintroduced to their natural habitats [25]. Field performances, including survival, vegetative growth, and plant developments, over 10 months were comparable or even better than the micropropagated

(13)

plants (the control), although site-specific differences in the percent flowering and amount of indole amines compounds were observed among the plants [25].

These two studies provide a paradigm for the use of cryopreservation for the long-term preservation of plants at risk and their reintroduction in natural habitats.

6. Conclusions and Perspectives

Significant progress was made in the development of plant cryopreservation technology. A wide range of genetically diverse plants that are propagated sexually through seeds and vegetatively through shoot tips have now been successfully cryopreserved. The reintroduction of plants from cryobanks into natural habitats and assessments of field performance, including growth, reproduction, and adaptation to natural environments, was also achieved in many species. The plants from cryopreserved sources survived as well as those from non-cryopreserved tissues when established in vivo conditions. Overall, morphologies, vegetative growth, and reproduction of the cryopreserved plants were comparable to those of the non-cryopreserved ones. However, certain changes in DNA methylation were detected in the regenerants recovered after cryopreservation in some plant species. Some of these changes were attributed to in vitro culture processes, particularly in the cases of embryogenic tissues. The reversible epigenetic mechanism indicates that DNA methylation is temporary and plants can revert to normal DNA status when in vitro cryopreserved plants are established in the field conditions. Therefore, DNA methylation was not closely related to genetic variations in cryopreserved plants. Although the genetic variation was detected in the regenerants recovered after cryopreservation in some plant species, such variations were small in locus and low in frequency, and some of the variations were attributed to in vitro culture processes. Analyses by FCM and molecular markers proved that overall genetic stability was maintained in the regenerants recovered after cryopreservation in many of the plant species. Therefore, cryopreservation can maximally maintain genetic stability of cryo-derived plants compared to other traditional methods. Cryopreservation of transgenes provides a safe and reliable strategy for the long-term preservation of transgenic plant materials. Cryopreservation processes do not adversely affect the metabolic stability of plants of cryogenic origin and biochemical profiles are also maintained in the regenerated progeny. In addition, cryopreservation can preserve transgenes in the transformed materials.

Nevertheless, manipulations of in vitro stock cultures and cryogenic procedures are still needed to ensure genetic stability in the cryo-derived plants, and assessments of epigenetic and genetic stability in cryo-derived plants are necessary before any cryopreservation protocols are used for establishing cryobanks (Figure1). Manipulations of in vitro stock cultures can be performed by shortening the time periods from establishing in vitro stock cultures to implementing cryopreservation as much as possible, and minimizing the use of plant growth regulators for the maintenance of in vitro stock cultures and post-culture of cryopreserved samples for plant recovery (Figure1). Manipulations of cryoprocedures can be performed by avoiding or minimizing the use of toxic substances, such as DMSO, polyethylene glycol, and glycerol (Figure1). Due to the low fraction of the genome screened in the analysis of genetic fidelity using available molecular markers, new methods are needed for broader screening of the genome in the regenerants recovered after cryopreservation. Next generation sequencing provides an ultra-high throughput platform by which the sequence of the entire genome of DNA or RNA can be determined and epigenetic variations can be detected, thus providing a solid evidence of epigenetic and genetic fidelity in the regenerants recovered after cryopreservation.

In conclusion, the process of cryopreservation seems to preserve the genetic make- up of plants and the plants regenerated from cryopreserved tissues demonstrate the ability to adapt through transient adaptation and through DNA methylation. It would be interesting to investigate the impact of stress ameliorating treatments before, during, and after cryotreatments at the biochemical and molecular level. Stress mitigation during

(14)

the culture process prior and after vitrification may further improve the cryopreservation technology and reduce incidences of genetic and epigenetic variations.

Author Contributions:M.-R.W.: data collection and analysis, preparation of tables, and manuscript writing and revisions; W.B.: data collection and analysis, and manuscript revision; M.R.S.: manuscript revision; L.R.: manuscript revision; Z.H. and D.-R.B.: valuable discussions; P.K.S.: manuscript proposal and manuscript revision; Q.-C.W.: manuscript proposal, manuscript writing and revision, and financial supports. All authors have read and agreed to the published version of the manuscript.

Funding: We acknowledge funding from the National Key R&D Program of China (project no.

2019YFD1001803) for M.-R.W. and Q.-C.W., the National Natural Science Foundation of China (project no. 31870686) for L.R., and the Research Council of Norway (project No. 255032/E50) and NIBIO for Z.H. and D.-R.B.

Conflicts of Interest:The authors declare that they have no competing interests.

Abbreviations

AFLP Amplified fragment length polymorphism DMSO Dimethyl sulfoxide

FCM Flow cytometry

HPLC High performance liquid chromatography ISSR Inter-simple sequence repeats

LN Liquid nitrogen

MSAP Methylation sensitive amplified polymorphism RAPD Random amplified polymorphic DNA

ROS Reactive oxygen species SSR Single sequence repeats

SRAP Sequence-related amplified polymorphism References

1. Sakai, A. Survival of plant tissue of super-low temperature.Contrib. Inst. Temp. Sci. Haikkaido Univ. Ser. B1956,14, 17.

2. Sakai, A. Survival of the twigs of woody plants at−196^◦C.Nature1960,185, 392–394. [CrossRef]

3. Bettoni, J.C.; Bonnart, R.; Volk, G.M. Challenges in implementing plant shoot tip cryopreservation technologies.Plant Cell Tissue Org. Cult.2021,144, 21–34. [CrossRef]

4. Pence, V.C.; Ballesteros, D.; Walters, C.; Reed, B.M.; Philpott, M.; Dixon, K.W.; Pritchard, H.W.; Culley, T.M.; Vanhove, A.-C.

Cryobiotechnologies: Tools for expanding long-term ex situ conservation to all plant species.Biol. Conserv.2020,250, 108736.

[CrossRef]

5. Tanner, J.D.; Chen, K.Y.; Bonnart, R.M.; Minas, I.S.; Volk, G.M. Considerations for large-scale implementation of dormant budwood cryopreservation.Plant Cell Tissue Org. Cult.2021,144, 35–48. [CrossRef]

6. Wang, M.-R.; Lambardi, M.; Engelmann, F.; Pathirana, R.; Panis, B.; Volk, G.M.; Wang, Q.-C. Advances in cryopreservation of in vitro-derived propagules: Technologies and explant resources.Plant Cell Tissue Org. Cult.2021,144, 7–20. [CrossRef]

7. Langis, R.; Schnabel-Preikstas, B.J.; Earle, E.D.; Steponkus, P.L. Cryopreservation ofBrassica campestrisL. suspensions by vitrification.CryoLetters1989,10, 421–428.

8. Sakai, A.; Hirai, D.; Niino, T. Development of PVS-based vitrification and encapsulation-vitrification protocols. InPlant Cryopreservation: A Practical Guide; Reed, B.M., Ed.; Springer: New York, NY, USA, 2008; pp. 33–58.

9. Uragami, M.; Sakai, A.; Nagai, M.; Takahashi, T. Survival of cultured cells and somatic embryos ofAsparagus officinaliscryopre- served by vitrification.Plant Cell Rep.1989,8, 418–421. [CrossRef]

10. Fabre, J.; Dereuddre, J. Encapsulation-dehydration, a new approach to cryopreservation ofSolanumshoot tips.CryoLetters1990, 11, 413–426.

11. Panis, B.; Piette, B.; Swennen, R. Droplet vitrification of apical meristems: A cryopreservation protocol applicable to all Musaceae.

Plant Sci.2005,168, 45–55. [CrossRef]

12. Engelmann, F.; Arnao, M.T.; Wu, Y.; Escobar, R. Development of encapsulation dehydration. InPlant Cryopreservation: A Practical Guide; Reed, B.M., Ed.; Springer: New York, NY, USA, 2008; pp. 59–75.

13. Niino, T.; Yamamoto, S.; Fukui, K.; Martínez, C.R.C.; Arizaga, M.V.; Matsumoto, T.; Engelmann, F. Dehydration improves cryopreservation of mat rush (Juncus decipiensNakai) basal stem buds on cryo-plates.CryoLetters2013,34, 549–560.

14. Yamamoto, S.-I.; Rafque, T.; Priyantha, W.S.; Fukui, K.; Matsumoto, T.; Niino, T. Development of a cryopreservation procedure using aluminum cryo-plates.CryoLetters2011,32, 256–265.

(15)

15. Wang, M.-R.; Chen, L.; Teixeira da Silva, J.A.; Volk, G.M.; Wang, Q.-C. Cryobiotechnology of apple (Malusspp.): Development, progress and future prospects.Plant Cell Rep.2018,37, 689–709. [CrossRef]

16. Bi, W.-L.; Pan, C.; Hao, X.-Y.; Cui, Z.-H.; Kher, M.M.; Markovi´c, Z.; Wang, Q.-C.; Teixeira da Silva, J.A. Cryopreservation of grapevine (Vitisspp.)—A review.In Vitro Cell. Dev. Biol.-Plant2017,53, 449–460. [CrossRef]

17. Bi, W.-L.; Hao, X.-Y.; Cui, Z.-H.; Volk, G.M.; Wang, Q.-C. Droplet-vitrification cryopreservation of in vitro-grown shoot tips of grapevine (Vitisspp.).In Vitro Cell. Dev. Biol.-Plant2018,54, 590–599. [CrossRef]

18. Li, J.-W.; Zhang, X.-C.; Wang, M.-R.; Bi, W.-L.; Faisal, M.; Teixeira da Silva, J.A.; Volk, G.M.; Wang, Q.-C. Development, progress and future prospects in cryobiotechnology ofLiliumspp.Plant Meth.2019,15, 125. [CrossRef] [PubMed]

19. Feng, C.-H.; Yin, Z.-F.; Ma, Y.-L.; Chen, L.; Zhang, Z.-B.; Wang, B.; Li, B.-Q.; Huang, Y.-S.; Wang, Q.-C. Cryopreservation of sweetpotato (Ipomoea batatas) and its pathogen eradication by cryotherapy.Biotechnol. Adv.2011,29, 84–93. [CrossRef]

20. Vollmer, R.; Villagaray, R.; Egúsquiza, V.; Espirilla, J.; García, M.; Torres, A.; Rojas, E.; Panta, A.; Barkley, N.; Ellis, D. The potato cryobank at the International Potato Center (CIP): A model for long term conservation of clonal plant genetic resources collections of the future.CryoLetters2016,37, 318–329.

21. Benelli, C.; De Carlo, A.; Engelmann, F. Recent advances in the cryopreservation of shoot-derived germplasm of economically important fruit trees ofActinidia,Diospyros,Malus,Olea,Prunus.Biotechnol. Adv.2013,31, 175–185. [CrossRef]

22. Kulus, D.; Zalewska, M. Cryopreservation as a tool used in long-term storage of ornamental species—A review.Sci. Hortic.2014, 168, 88–107. [CrossRef]

23. Yang, X.X.; Popova, E.; Shukla, M.R.; Saxena, P.K. Root cryopreservation to biobank medicinal plants: A case study forHypericum perforatumL.In Vitro Cell. Dev. Biol.-Plant2019,55, 392–402. [CrossRef]

24. Li, J.-W.; Ozudogru, E.A.; Li, J.; Wang, M.-R.; Bi, W.-L.; Lambardi, M.; Wang, Q.-C. Cryobiotechnology of forest trees: Recent advances and future prospects.Biodivers. Conserv.2017,27, 795–814. [CrossRef]

25. Bi, W.; Saxena, A.; Ayyanath, M.M.; Harpur, C.; Shukla, M.R.; Saxena, P.K. Conservation, propagation, and redistribution (CPR) of Hill’s thistle: Paradigm for plant species at risk.Plant Cell Tissue Org. Cult.2021,145, 75–88. [CrossRef]

26. Coelho, N.; Gonçalves, S.; Romano, A. Endemic plant species conservation: Biotechnological approaches. Plants2020,9, 345.

[CrossRef]

27. Normah, M.N.; Sulong, N.; Reed, B.M. Cryopreservation of shoot tips of recalcitrant and tropical species: Advances and strategies.

Cryobiology2019,87, 1–14. [CrossRef]

28. Popova, E.V.; Shukla, M.R.; McIntosh, T.; Saxena, P.K. In vitro and cryobiotechnology approaches to safeguardLupinus rivularis Douglas ex Lindl., an endangered plant in Canada.Agronomy2021,11, 37. [CrossRef]

29. Streczynski, R.; Clark, H.; Whelehan, L.M.; Ang, S.-T.; Hardstaff, L.K.; Funnekotter, B.; Bunn, E.; Offord, C.A.; Sommerville, K.D.;

Mancera, R.L. Current issues in plant cryopreservation and importance for ex situ conservation of threatened Australian native species.Aust. J. Bot.2019,67, 1–15. [CrossRef]

30. Jenderek, M.M.; Reed, B.M. Cryopreserved storage of clonal germplasm in the USDA National Plant Germplasm System.In Vitro Cell. Dev. Biol.-Plant2017,53, 299–308. [CrossRef]

31. Wang, B.; Wang, R.-R.; Cui, Z.-H.; Bi, W.-L.; Li, J.-W.; Li, B.-Q.; Ozudogru, E.A.; Volk, G.M.; Wang, Q.-C. Potential applications of cryogenic technologies to plant genetic improvement and pathogen eradication.Biotechnol. Adv.2014,32, 583–595. [CrossRef]

32. Salama, A.; Popova, E.; Jones, M.P.; Shukla, M.R.; Fisk, N.S.; Saxena, P.K. Cryopreservation of the critically endangered golden paintbrush (Castilleja levisectaGreenm.): From nature to cryobank to nature. In Vitro Cell. Dev. Biol.-Plant2018,54, 69–78.

[CrossRef]

33. Wang, B.; Zhang, Z.; Yin, Z.; Feng, C.; Wang, Q.C. Novel and potential application of cryopreservation to plant genetic transformation.Biotechnol. Adv.2012,30, 604–612. [CrossRef]

34. Wang, Q.C.; Wang, R.R.; Li, B.Q.; Cui, Z.H. Cryopreservation: A strategy for safe preservation of genetically transformed plant materials.Adv. Genet. Eng. Biotechnol.2012,1, 1–2. [CrossRef]

35. Wang, Q.C.; Panis, B.; Engelmann, F.; Lambardi, M.; Valkonen, J.P.T. Cryotherapy of shoot tips: A technique for pathogen eradication to produce healthy planting materials and prepare healthy plant genetic resources for cryopreservation.Ann. Appl.

Biol.2009,154, 351–363. [CrossRef]

36. Wang, Q.C.; Valkonen, J.P.T. Cryotherapy of shoot tips: Novel pathogen eradication method.Trends Plant Sci.2009,14, 119–122.

[CrossRef] [PubMed]

37. Li, J.-W.; Wang, M.-R.; Chen, H.-Y.; Zhao, L.; Cui, Z.-H.; Zhang, Z.; Blystad, D.-R.; Wang, Q.-C. Long-term preservation of potato leafroll virus, potato virus S, and potato spindle tuber viroid in cryopreserved shoot tips.Appl. Microbiol. Biotechnol.2018,102, 10743–10754. [CrossRef] [PubMed]

38. Wang, M.-R.; Hamborg, Z.; Ma, X.-Y.; Blystad, D.-R.; Wang, Q.-C. Double-edged effects of cryogenic technique for virus eradication and preservation in shallot shoot tips.Plant Pathol.2021, accepted.

39. Wang, M.-R.; Yang, W.; Zhao, L.; Li, J.-W.; Liu, K.; Yu, J.-W.; Wu, Y.-F.; Wang, Q.-C. Cryopreservation of virus: A novel biotechnology for long-term preservation of virus in shoot tips.Plant Meth.2018,14, 47. [CrossRef] [PubMed]

40. Zhao, L.; Wang, M.-R.; Li, J.-W.; Volk, G.M.; Wang, Q.-C. Cryobiotechnology: A double-edged sword for plant obligate pathogens.

Plant Dis.2019,103, 1058–1067. [CrossRef]

41. Engelmann, F. Use of biotechnologies for the conservation of plant biodiversity. In Vitro Cell. Dev. Biol.-Plant2011,47, 5–16.

[CrossRef]

(16)

42. Kaczmarczyk, A.; Turner, S.R.; Bunn, E.; Mancera, R.L.; Dixon, K.W. Cryopreservation of threatened native Australian species—

What have we learned and where to from here?In Vitro Cell. Dev. Biol.-Plant2011,47, 17–25. [CrossRef]

43. RBG Kew. The State of the World’s Plants Report—2016; Royal Botanic Gardens, Kew: Richmond, UK, 2016. Available online:

https://stateoftheworldsplants.org/2016/(accessed on 30 August 2021).

44. Edesi, J.; Tolonen, J.; Ruotsalainen, A.L.; Aspi, J.; Häggman, H. Cryopreservation enables long-term conservation of critically endangered speciesRubus humulifolius.Biodivers. Conserv.2020,29, 303–314. [CrossRef]

45. Sharma, N.; Gowthami, R.; Devi, S.V.; Malhotra, E.V.; Pandey, R.; Agrawal, A. Cryopreservation of shoot tips ofGentiana kurroo Royle—A critically endangered medicinal plant of India.Plant Cell Tissue Org. Cult.2021,144, 67–72. [CrossRef]

46. Grout, B.W.W. Cryopreservation of plant cell suspensions. InCryopreservation and Freeze-Drying Protocols; Methods in Molecular Biology^TM; Day, J.G., Stacey, G.N., Eds.; Human Press: Totowa, NJ, USA, 2007; Volume 368, pp. 153–161.

47. Kaczmarczyk, A.; Funnekotter, B.; Menon, A.; Phang, P.Y.; Al-Hanbali, A.; Bunn, E.; Mancera, R.L. Current issues in plant cryopreservation. InCurrent Frontiers in Cryobiology; Katkov, I.I., Ed.; InTech: Rijeka, Croatia, 2012; pp. 417–438.

48. Kulus, D. Application of cryogenic technologies and somatic embryogensis in the storage and protection of valuable genetic resources of ornamental plants. InSomatic Embryogenesis in Ornanmental and Its Applications; Mujib, A., Ed.; Springer: New Delhi, India, 2016; pp. 1–26.

49. Bednarek, P.T.; Orłowska, R. Plant tissue culture environment as a switch-key of (epi)genetic changes.Plant Cell Tissue Org. Cult.

2020,140, 245–257. [CrossRef]

50. Miguel, C.; Marum, L. An epigenetic view of plant cells cultured in vitro: Somaclonal variation and beyond.J. Exp. Bot.2011,62, 3713–3725. [CrossRef]

51. Us-Camas, R.; Rivera-Solís, G.; Duarte-Aké, F.; De-la-Peña, C. In vitro culture: An epigenetic challenge for plants.Plant Cell Tissue Org. Cult.2014,118, 187–201. [CrossRef]

52. Zhang, D.; Wang, Z.; Wang, N.; Yang, G.; Ying, L. Tissue culture-induced heritable genomic variation in rice, and their phenotypic implications.PLoS ONE2014,9, e96879.

53. Benson, E.E. Cryopreservation of phytodiversity: A critical appraisal of theory & practice.Crit. Rev. Plant Sci.2008,27, 141–219.

54. Harding, K. Genetic integrity of cryopreserved plant cells: A review.CryoLetters2004,25, 3–22.

55. Harding, K.; Johnson, J.W.; Benson, E.E. Exploring the physiological basis of cryopreservation and failure in clonally propagated in vitrocrop plant germplasm.Agric. Food Sci.2009,18, 103–116. [CrossRef]

56. Gill, S.S.; Tuteja, N. Reactive oxygen species and antioxidant machinery in abiotic stress tolerance in crop plants.Plant Physiol.

Biochem.2010,48, 909–930. [CrossRef]

57. Mittler, R. ROS are good.Trends Plant Sci.2017,22, 11–19. [CrossRef] [PubMed]

58. Smulders, M.J.M.; de Klerk, J.R. Epigenetics in plant tissue culture.Plant Growth Regul.2011,63, 137–146. [CrossRef]

59. Ito, A.; Yoshida, M. Epigenetics. InBioprobes: Biochemical Tools for Investigating Cell Functions, 2nd ed.; Osada, H., Ed.; Springer:

Tokyo, Japan, 2017; pp. 47–65.

60. Boyko, A.; Kovalchuk, I. Epigenetic control of plant tress response.Environ. Mol. Mutagen.2008,49, 61–72. [CrossRef] [PubMed]

61. Hao, Y.J.; Liu, Q.L.; Deng, X.X. Effect of cryopreservation on apple genetic resources at morphological, chromosomal, and molecular levels.Cryobiology2001,43, 46–53. [CrossRef]

62. Hao, Y.J.; You, C.X.; Deng, X.X. Analysis of ploidy and the patterns of amplified fragment length polymorphism and methylation sensitive amplified polymorphism in strawberry plants recovered from cryopreservation.CryoLetters2002,23, 37–46.

63. Hao, Y.J.; You, C.X.; Deng, X.X. Effects of cryopreservation on developmental competency, cytological and molecular stability of citrus callus.CryoLetters2002,23, 27–35.

64. Peredo, E.L.; Arroyo-García, R.; Reed, B.M.; Revilla, M.A. Genetic stability of in vitro conserved germplasm ofHumulu lupulusL.

Agric. Food Sci.2009,18, 144–151. [CrossRef]

65. Kaity, A.; Drew, R.A.; Ashmore, S.E. Genetic and epigenetic integrity assessment of acclimatised papaya plants regenerated directly from shoot-tips following short- and long-term cryopreservation.Plant Cell Tissue Org. Cult.2013,112, 75–86. [CrossRef]

66. Adu-Gyamfi, R.; Wetten, A.; Rodriguez, L.C.M. Effect of cryopreservation and post-cryopreservation somatic embryogenesis on the epigenetic fidelity of cocoa (Theobroma cacaoL.).PLoS ONE2016,11, e0158857.

67. Maki, S.; Hirai, Y.; Niino, T.; Matsumoto, T. Assessment of molecular genetic stability between long term cryopreservation and tissue cultured wasabi (Wasabia japonica) plants.CryoLetters2015,36, 318–324.

68. Johnston, J.W.; Benson, E.E.; Harding, K. Cryopreservation induces temporal DNA methylation epigenetic changes and differential transcriptional activity inRibesgermplasm.Plant Physiol. Biochem.2009,47, 123–131. [CrossRef]

69. Kaity, A.; Ashmore, S.E.; Drew, R.A. Assessment of genetic and epigenetic changes following cryopreservation in papaya.Plant Cell Rep.2008,2, 1529–1539. [CrossRef]

70. Ibáñez, M.A.; Alvarez-Mari, A.; Rodríguez-Sanz, H.; Kremer, C.; González-Benito, M.E.; Martín, C. Genetic and epigenetic stability of recovered mint apices after several steps of a cryopreservation protocol by encapsulation-dehydration. A new approach for epigenetic analysis.Plant Physiol. Biochem.2019,143, 299–307. [CrossRef]

71. Zhang, X.-C.; Bao, W.-W.; Zhang, A.-L.; Pathirana, R.; Wang, Q.-C.; Liu, Z.-D. Cryopreservation of shoot tips, evaluations of vegetative growth, and assessments of genetic and epigenetic changes in cryo-derived plants ofActinidiaspp.Cryobiology2020, 94, 18–25. [CrossRef]

(17)

72. Heringer, A.S.; Steinmacher, D.A.; Fraga, H.P.F.; Vieira, L.N.; Ree, J.F.; Guerra, M.P. Global DNA methylation profiles of somatic embryos of peach palm (Bactris gasipaesKunth) are influenced by cryoprotectants and droplet-vitrification cryopreservation.

Plant Cell Tissue Org. Cult.2013,114, 365–372. [CrossRef]

73. Plitta, B.P.; Michalak, M.; Naskret-Barciszewska, M.Z.; Barciszewski, J.; Chmielarz, P. DNA methylation ofQuercus roburL.

plumules following cryo-pretreatment and cryopreservation.Plant Cell Tissue Org. Cult.2014,117, 31–37. [CrossRef]

74. Kaczmarczyk, A.; Houben, A.; Keller, E.R.J.; Mette, M.F. Influence of cryopreservation on the cytosine methylation state of potato genomic DNA.CryoLetters2010,31, 380–391.

75. Mikuła, A.; Tomiczak, K.; Rybczy ´nski, J.J. Cryopreservation enhances embryogenic capacity ofGentiana cruciata(L.) suspension culture and maintains (epi)genetic uniformity of regenerants.Plant Cell Rep.2011,30, 565–574. [CrossRef]

76. Vos, P.; Hogers, R.; Bleeker, M.; Reijans, M.; van de Lee, T.; Hornes, M.; Frijters, A.; Pot, J.; Peleman, J.; Kuiper, M.; et al. AFLP: A new technique for DNA fingerprinting.Nucleic Acids Res.1995,23, 4407–4414. [CrossRef] [PubMed]

77. Jacob, H.J.; Lindpainter, K.; Lincoln, S.E.; Kusumi, K.; Bunker, R.K.; Mao, Y.-P.; Ganten, D.; Dzau, V.J.; Lander, E.S. Genetic mapping of a gene causing hypertension in the stroke-prone spontaneously hypertensive rat.Cell1991,67, 213–224. [CrossRef]

78. Akkaya, M.S.; Bhagwat, A.A.; Cregan, P.B. Lengh polymorphisms of simple sequence repeat DNA in soybean.Genetics1992,132, 1131–1139. [CrossRef]

79. Wang, B.; Li, J.-W.; Zhang, Z.-B.; Wang, R.-R.; Ma, Y.-L.; Blystad, D.-R.; Keller, E.R.J.; Wang, Q.-C. Three vitrification-based cryopreservation procedures cause different cryo-injuries to potato shoot tips while all maintain genetic integrity in regenerants.

J. Biotechnol.2014,184, 47–55. [CrossRef]

80. Kulus, D.; Rewers, M.; Serocka, M. Cryopreservation by encapsulation-dehydration affects the vegetative growth of chrysanthemum but does not disturb its chimeric structure.Plant Cell Tissue Org. Cult.2019,138, 153–166. [CrossRef]

81. Liu, X.-X.; Wen, Y.-B.; Cheng, Z.-H.; Mou, S.-W. Establishment of a garlic cryopreservation protocol for shoot apices from adventitious buds in vitro.Sci. Hortic.2017,226, 10–18. [CrossRef]

82. Wang, R.-R.; Gao, X.-X.; Chen, L.; Huo, L.-Q.; Li, M.-F.; Wang, Q.-C. Shoot recovery and genetic integrity ofChrysanthemum morifoliumshoot tips following cryopreservation by droplet-vitrification.Sci. Hortic.2014,176, 330–339. [CrossRef]

83. Kraj ˇnáková, J.; Sutela, S.; Aronen, T.; Gömöry, D.; Vianello, A.; Häggman, H. Long-term cryopreservation of Greek fir embryogenic cell lines: Recovery, maturation and genetic fidelity.Cryobiology2011,63, 17–25. [CrossRef]

84. Pence, V.C.; Philpott, M.; Culley, T.M.; Plair, B.; Yorke, S.R.; Lindsey, K.; Vanhove, A.C.; Ballesteros, D. Survival and genetic stability of shoot tips ofHedeoma todseniiR.S. Irving after long-term cryostorage.In Vitro Cell. Dev. Biol.-Plant2017,53, 28–338.

85. Martín, C.; Cervera, M.T.; González-Benito, M.E. Genetic stability analysis of chrysanthemum (Chrysanthemum x morifolium Ramat) after different stages of an encapsulation–dehydration cryopreservation protocol.J. Plant Physiol. 2011,168, 158–166.

[CrossRef] [PubMed]

86. Martín, C.; Kremer, C.; González, I.; González-Benito, M.E. Influence of the cryopreservation technique, recovery medium and genotype on genetic stability of mint cryopreserved shoot tips.Plant Cell Tissue Org. Cult.2015,122, 185–195. [CrossRef]

87. González-Benito, M.E.; Kremer, C.; Ibáñez, M.A.; Martín, C. Effect of antioxidants on the genetic stability of cryopreserved mint shoot tips by encapsulation–dehydration.Plant Cell Tissue Org. Cult.2016,127, 359–368. [CrossRef]

88. Castillo, N.R.F.; Bassil, N.V.; Wada, S.; Reed, B.M. Genetic stability of cryopreserved shoot tips ofRubusgermplasm.In Vitro Cell.

Dev. Biol.-Plant2010,46, 246–256. [CrossRef]

89. Aronen, T.S.; Krajnakov, J.; Häggman, H.M.; Ryynänen, L.A. Genetic fidelity of cryopreserved embryogenic cultures of open- pollinatedAbies cephalonica.Plant Sci.1999,142, 163–172. [CrossRef]

90. Merhy, T.S.M.; Vianna, M.G.; Garcia, R.O.; Pacheco, G.; Mansur, E. Cryopreservation ofPassiflora pohliinodal segments and assessment of gentic stability of regenerated plants.CryoLetters2014,35, 204–215.

91. Li, J.-W.; Chen, H.-Y.; Li, X.-Y.; Zhang, Z.; Blystad, D.-R.; Wang, Q.-C. Cryopreservation and evaluations of vegetative growth, microtuber production and genetic stability in regenerants of purple-fleshed potato.Plant Cell Tissue Org. Cult.2017,128, 641–653.

[CrossRef]

92. Galdiano, R.F., Jr.; de Macedo Lemos, E.G.; Vendrame, W.A. Cryopreservation, early seedling development, and genetic stability ofOncidium flexuosumSims.Plant Cell Tissue Org. Cult.2013,114, 139–148. [CrossRef]

93. Bi, W.-L.; Pan, C.; Liu, J.; Wang, Q.-C. Greenhouse performance, genetic stability and biochemical compounds inChrysanthemum morifolium‘Hangju’ plants regenerated from cryopreserved shoot tips.Acta Physiol. Plant.2016,38, 268. [CrossRef]

94. Zhang, Z.; Skjeseth, G.; Elameen, A.; Haugslien, S.; Sivertsen, A.; Wang, Q.-C.; Blystad, D.R. Field performance evaluation and genetic integrity assessment inArgyranthemum maderenseplants recovered from cryopreserved shoot tips.In Vitro Cell. Dev. Biol.

-Plant2015,51, 505–513. [CrossRef]

95. Li, J.-W.; Li, H.-H.; Wang, R.-R.; Gao, X.-X.; Wang, Q.-C. Cryopreservation for retaining morphology, genetic integrity, and foreign genes in transgenic plants ofTorenia fournieri.Acta Physiol. Plant.2016,38, 8. [CrossRef]

96. Cheng, W.; Li, H.; Zhou, F.; Zhu, B.; Yu, J.; Ding, Z. Cryopreservation ofPleione bulbocodioides(Franch.) Rolfe protocorm-like bodies by vitrification.Acta Physiol. Plant.2020,42, 82. [CrossRef]

97. Cejas, I.; Vives, K.; Laudat, T.; González-Olmedo, J.; Engelmann, F.; Martínez-Montero, M.E.; Lorenzo, J.C. Effects of cryopreservation ofPhaseolus vulgarisL. seeds on early stages of germination.Plant Cell Rep.2012,31, 2065–2073. [CrossRef]

98. Carmona-Martín, E.; Regalado, J.J.; Perán-Quesada, R. Cryopreservation of rhizome buds ofAsparagus officinalisL. (cv. Morado de Huétor) and evaluation of their genetic stability.Plant Cell Tissue Org. Cult.2018,133, 395–403. [CrossRef]

(18)

99. Wang, M.-R.; Hamborg, Z.; Slimestad, R.; Elameen, A.; Blystad, D.-R.; Haugslien, S.; Skjeseth, G.; Wang, Q.-C. Assessments of rooting, vegetative growth, bulb production, genetic integrity and biochemical compounds in cryopreserved plants of shallot.

100. Agrawal, A.; Sanayaima, R.; Singh, R.; Tandon, R.; Verma, S.; Tyagi, R.K. Phenotypic and molecular studies for genetic stability assessment of cryopreserved banana meristems derived from field and in vitro explant sources.In Vitro Cell. Dev. Biol.-Plant2014, 50, 345–356. [CrossRef]

101. Li, B.-Q.; Feng, C.-H.; Hu, L.-Y.; Wang, M.-R.; Chen, L.; Wang, Q.-C. Shoot regeneration and cryopreservation of shoot tips of apple (Malus) by encapsulation–dehydration.In Vitro Cell. Dev. Biol.-Plant2014,50, 357–368. [CrossRef]

102. Li, B.-Q.; Feng, C.-H.; Wang, M.-R.; Hu, L.-Y.; Volk, G.M.; Wang, Q.-C. Recovery patterns, histological observations and genetic integrity inMalusshoot tips cryopreserved using droplet-vitrification and encapsulation-dehydration procedures.J. Biotechnol.

2015,214, 182–191. [CrossRef] [PubMed]

103. Wang, L.-Y.; Li, Y.-D.; Sun, H.-Y.; Liu, H.-G.; Tang, X.-D.; Wang, Q.-C.; Zhang, Z.-D. An efficient droplet-vitrification cryopreservation for valuable blueberry germplasm.Sci. Hortic.2017,219, 60–69. [CrossRef]

104. Chen, H.-Y.; Liu, J.; Pan, C.; Yu, J.-W.; Wang, Q.-C. In vitro regeneration of adventitious buds from leaf explants and their subsequent cryopreservation in highbush blueberry.Plant Cell Tissue Org. Cult.2018,134, 193–204. [CrossRef]

105. Ai, P.-F.; Lu, L.-P.; Song, J.-J. Cryopreservation of in vitro-grown shoot-tips ofRabdosia rubescensby encapsulation-dehydration and evaluation of their genetic stability.Plant Cell Tissue Org. Cult.2012,108, 381–387. [CrossRef]

106. Sharma, N.; Singh, R.; Pandey, R.; Kaushik, N. Genetic and biochemical stability assessment of plants regenerated from cryopreserved shoot tips of a commercially valuable medicinal herbBacopa monnieri(L.) Wettst.In Vitro Cell. Dev. Biol.-Plant2017, 53, 346–351. [CrossRef]

107. Wang, R.-R.; Mou, H.-Q.; Gao, X.-X.; Chen, L.; Li, M.-F.; Wang, Q.-C. Cryopreservation for eradication of Jujube witches’ broom phytoplasma from Chinese jujube (Ziziphus jujuba).Ann. Appl. Biol.2015,166, 218–228. [CrossRef]

108. Tavazza, R.; Lucioli, A.; Benelli, C.; Giorgi, D.; D’Aloisio, E.; Papacchioli, V. Cryopreservation in artichoke: Towards a phytosani- tary qualified germplasm collection.Ann. Appl. Biol.2013,163, 231–241. [CrossRef]

109. Li, J.-W.; Chen, H.-Y.; Li, J.; Zhang, Z.; Blystad, D.-R.; Wang, Q.-C. Growth, microtuber production and physiological metabolism in virus-free and virus-infected potato in vitro plantlets grown under NaCl-induced salt stress.Eur. J. Plant Pathol. 2018,152, 417–432. [CrossRef]

110. Meijer, E.G.M.; Iren, E.; Schrijnemakers, E.; Hensgens, L.A.M.; van Zijderveld, M.; Schilperoort, R.A. Retention of the capacity to produce plants from protoplasts in cryopreserved cell lines of rice (Oryza sativaL).Plant Cell Rep.1991,10, 171–174. [CrossRef]

111. Cho, J.S.; Hong, S.M.; Joo, S.Y.; Yoo, J.S.; Kim, D.I. Cryopreservation of transgenic rice suspension cells producing recombinant hCTLA4Ig.Appl. Microbiol. Biotechnol.2007,73, 1470–1476. [CrossRef]

112. Van Eck, J.; Keen, P. Continued expression of plant-made vaccines following long-term cryopreservation of antigen-expressing tobacco cell cultures.In Vitro Cell. Dev. Biol.-Plant2009,45, 750–757. [CrossRef]

113. Vendrame, W.A.; Holliday, C.P.; Montello, P.M.; Smith, D.R.; Merkle, S.A. Cryopreservation of yellow-poplar (Liriodendron tulipifera) and sweetgum (Liquidambarspp.) embryogenic cultures.New For.2001,21, 283–292. [CrossRef]

114. Hao, Y.J.; Deng, X.X. GUS gene remains stable in transgenicCitruscallus recovered from cryopreservation.CryoLetters2003,24, 375–380.

115. Ryynänen, L.; Sillanpää, M.; Kontunen-Soppela, S.; Tiimonen, H.; Kangasjärvi, J.; Vapaavuori, E.; Häggman, H. Preservation of transgenic silver birch (Betula pendulaRoth) lines by means of cryopreservation.Mol. Breed.2002,10, 143–152. [CrossRef]

116. Jokipii, S.; Ryynänen, L.; Kallio, P.T.; Aronen, T.; Häggman, H. A cryopreservation method maintaining the genetic fidelity of a model forest tree,Populus tremulaL.×Populus tremuloidesMichx.Plant Sci.2004,166, 799–806. [CrossRef]

117. Schmale, K.; Rademacher, T.H.; Fischer, R.; Hellwig, S. Towards industrial usefulness—Cryocell banking of transgenic BY-2 cell cultures.J. Biotechnol.2006,124, 302–311. [CrossRef]

118. Corredoira, E.; San-Jose, M.C.; Vieitez, A.M.; Ballester, A. Improving genetic transformation of European chestnut and cryopreservation of transgenic lines.Plant Cell Tissue Org. Cult.2007,91, 281–288. [CrossRef]

119. Dolce, N.R.; Faloci, M.M.; Gonzalez, A.M. In vitro plant regeneration and cryopreservation ofArachis glabrata(Fabaceae) using leaflet explants.In Vitro Cell. Dev. Biol.-Plant2018,54, 133–144. [CrossRef]

120. Espasandin, F.D.; Brugnoli, E.A.; Ayala, P.G.; Ayala, L.P.; Ruiz, O.A. Long-term preservation ofLotus tenuisadventitious buds.

121. Martín, C.; Senula, A.; González, E.; Acosta, A.; Keller, E.R.J.; González-Benito, M.E. Genetic identity of three mint accessions stored by different conservation procedures: Field collection, in vitro and cryopreservation.Genet. Resour. Crop Evol.2013,60, 243–249. [CrossRef]

122. Agrawal, A.; Tyagi, R.K.; Goswami, R. Cryobanking of Banana (Musasp.) germplasm in India: Evaluation of agronomic and molecular traits of cryopreserved plants.Acta Hortic.2011,908, 129–138. [CrossRef]

123. Cejas, I.; Méndez, R.; Villalobos, A.; Palau, F.; Aragón, C.; Engelmann, F.; Carputo, D.; Aversano, R.; Martínez, M.E.; Lorenzo, J.C.

Phenotypic and molecular characterization ofPhaseolus vulgarisplants from non-cryopreserved and cryopreserved seeds.Am. J.

Plant Sci.2013,4, 844–849. [CrossRef]
