Orbital motion simulator

Orbital Motion Simulator

Bachelor Thesis

Haytham Ali Kjetil Fjeld

Anders Gunbjørnsen Heidi Kallerud

Martin Sandberg Fredrik Thoresen

May 22, 2016

Høgskolen i Sørøst-Norge

Aim: The aim of the project was to design a system that will support rotation of a remote weapon station (RWS) in isolation, and in parallel axes off-set, to a rotating turret. The project was provided by Kongsberg Protech Systems (KPS), who intend to implement the system in a test simulation laboratory.

Background:KPS have numerous customers that request to have the RWS mounted onto a turret-carrying vehicle. This significantly increases the complexity of integration between the systems. The great level of complexity of design, integration, testing and verification requires a "demo system" that simulates how the system will respond in real operational environments. KPS works on projects aimed at integrating the input from the two rotating systems; the turret and the RWS. Some of the integrated functions can be simulated in software, but simulating accurate data is challenging. The possibility to adjust the centre of the RWS away from the centre of the turret in the Turret Simulator is necessary in order to acquire specific data and develop software that supports the various set-ups required by customers. Getting access to a full turret has proven difficult and costly. Hence, a low-cost physical Turret Simulator that can be adapted to simulate input data from various RWS placements on the turret is therefore needed.

Method:The Project Plan provided guidelines for execution of the project that aimed to ensure satisfactory delivery of the by the set deadline. The CAFCR+ model was used to structure the systems engineering and development process. Through nine iterations a step-wise, well reasoned development process was ensured; from generation of an understanding of the desired system, through conceptual development and feasibility assessment, to final design development. Frequent view hopping in the CAFR+ model ensures that the needs of all the system stakeholders at different stages of the system’s life cycle were considered, ranging from usage to manufacture and service. An extensive Requirements Traceability Matrix was developed to ensure traceability between requirement originator, breakdown of requirements, corresponding tests and status. The complex load scenario that the system will be exposed to includes both rotation of a high load combined with the movement of a motion table involving 6 degrees of freedom, affirmed the need for a structured engineering model to uncover the forces and loads imposed on the system. By starting with a simple Free Body Diagram and progressively expanding the included variables a comprehensive dynamic model of the system was developed in SimuLink, through the use of differential equations and vector analysis. The model uses a custom-made Matlab function block to calculate the torque needed to satisfy the given input conditions. The function block could be changed to calculate different motion and load scenarios, and provided indispensable data for the calculations of total system torque. A "worst case" load scenario was defined, which formed the basis for evaluation and selection of components, as well as structural optimisation of the design. When designing structural components care was taken to ensure that manufacture was feasible, ultimately forming the Production Manual which

any failed test. At termination of the project a system was designed that by verification fulfills more than 94 percent of all the system requirements. This included numerous requirements that were listed asshouldrequirements, which introduce additional functional freedom to the stakeholders. In addition to acquiring in-depth experience in mechanical engineering design, numerous lessons were learnt with regards to project management, including requirement identification methods, goal setting and team work.

Conclusion: A mechanical system that supports parallel axis rotation of the RWS at offsets up to 40 cm was designed. Offset increments of 10 cm intervals is enabled and the assembled system can support rotational speed and acceleration beyond the minimum requirements of the stakeholder. A life span of 5 years is verified, provided that service is ensured as according to the developed user manual for the system. The project team has proved able to rapidly rearrange tasks and schedules when exposure to unexpected challenges occurred, and have acquired experience in mechanical engineering that will prove to be of significant value when entering into a career in engineering.
