Rollouts of Fine Ware Pottery using High Resolution 3D Meshes

(1)

A. Artusi, M. Joly-Parvex, G. Lucet, A. Ribes, and D. Pitzalis (Editors)

Rollouts of Fine Ware Pottery using High Resolution 3D Meshes

S. Bechtold¹and S. Krömker¹and H. Mara¹and B. Kratzmüller²
