SINTEF Building and Infrastructure Stefan Jacobsen, Jon Håvard Mork, Siaw Foon Lee , Lars Haugan
Pumping of concrete and mortar – State of the art
COIN Project report 5 - 2008
Stefan Jacobsen (NTNU), Jon Håvard Mork (maxit Group), Siaw Foon Lee (NTNU), Lars Haugan (SINTEF)
Pumping of concrete and mortar – State of the art
