Condensation heat transfer of CO2 on Cu based hierarchical and nanostructured surfaces

(1)

ContentslistsavailableatScienceDirect

International Journal of Heat and Mass Transfer

journalhomepage:www.elsevier.com/locate/hmt

Condensation heat transfer of CO ₂ on Cu based hierarchical and nanostructured surfaces

Ingrid Snustad

^a^,^∗

, Lene Hollund

^a

, ˚Asmund Ervik

^b

, Anders Austegard

^b

, Amy Brunsvold

^b

, Jianying He

^a

, Zhiliang Zhang

^a

aFaculty of Engineering, Department of Structural Engineering, Norwegian University of Science and Technology, Richard Birkelands vei 1A, Trondheim 7491, Norway

bSINTEF Energy Research, Sem Sæ lands vei 11, Trondheim 7034, Norway

a rt i c l e i nf o

Article history:

Received 20 January 2021 Revised 26 March 2021 Accepted 11 April 2021 Available online 5 May 2021 Keywords:

Condensation heat transfer CO 2 liquefaction

Micro- and nanostructured surfaces Cu based surfaces

a b s t r a c t

Phase-changeprocessessuchascondensationareefficientmeansofheattransfer.However,condensation isalsoanenergy-intensiveprocessandextensiveresearchisconductedtoincreasetheheattransfereffi- ciency.Increasingtheeffectiveheattransferareaintermsofsurfacestructuresonmacroormicroscaleis onesuchtechniqueofheattransferenhancement.Inthiswork,wehavestudiedmicro-andnanostruc- turedsurfacesfortheirpotentialsinincreasingheattransferduringcondensationofCO₂.ThreeCu-based surfaces onwhichCuO nanoneedleshave been grown, have beeninvestigated. We hypothesizethree competingmechanismsgoverntheoverallheattransferonstructuredsurfaces:(1)increasedheattrans- ferarea,(2)lowerthermalconductivityofoxides,and(3)condensatefloodingofthestructures.Ourstudy hasshownthatinsomecases,theeffectofthesemechanismscanbeneutralized.Moreimportantly,the resultsshowthatsuperiorheattransfercanbeachievedbyoptimizingthesurfacestructure.Thebestof thestructuredsurfacesresultedinaheattransfercoefficient66%higherthanthatoftheunstructured surface.

ThisisanopenaccessarticleundertheCCBYlicense(http://creativecommons.org/licenses/by/4.0/)

1. Introduction

Condensation heat transfer performance influences severalin- dustrial processes and isespecially important forheat exchanger technology. CO₂ is identified as an alternative for reducing the usage of fluorine based refrigerants in heat exchangers andheat pumpsduetotheirnegativeenvironmentalimpact[1–3].CO₂ has a high triple point and low critical point, andhas therefore the potential tobe anefficientrefrigerant[4].Increasedcondensation heattransferefficiencywillreducetheenergyconsumptionofthe liquefaction process andreduce the costs ofheat exchangers and heat pumps. Liquefaction of CO₂ is also a part of Carbon Cap- ture andStorage (CCS), especially asa preprocessforship transport [5,6].Increasedliquefactionefficiencywillreduce theenergy consumption andthe costoftheCCSsystems,whichisnecessary toscaleupthenumberofCCSprojectsworldwide[7].

In the literature,there are severalexamples of studies onthe increaseofheattransfereﬃciencybytheuseofmicro-andnanos-

∗Corresponding author.

E-mail address: [email protected] (I. Snustad).

tructuresonthesurface[8,9].Hendricksetal.[10]fabricatedZnO flower-like nanostructures on Al and Cu and reported increased criticalheat flux(CHF) forbothsurfaces.An increasedCHF isre- latedto a higherpossible operational limit, andtherefore a bet- ter heattransferperformance. Thesamephenomenon isreported byNametal.[11]andbySaediandAlemrajabi[12].Thefirstre- portedanincreaseinCHFatwickingstructuresofCuOnanostruc- turesontopofCu micropostsandthelatterreportedan increase inbothCHFandheattransfercoefficient(HTC)onanodizedAlsur- faces.In poolboiling,an increasednumberofnucleation siteson thestructuredsurfaceshasprovenbeneficial forheattransfer.For example Lietal. [13]studied nucleation boiling on Cu nanorods deposited on a Cu surface, and found that there were 30 times asmanybubble nucleationsites onthe structured surfaces.They also found that the nanorod surfaceexhibited a higher wettability towards water, which reduced the size of the bubble diame- ter and increases the release frequencyof the bubbles. By these mechanisms theCHF, andhence theheat transfer efficiency,was increased.Chenetal.[14]reportedanincreasedHTCforpoolboil- ing on nanowires of both Cu and Si. The improved HTCs were causedbytheincreasednumberofbubblenucleationsitesinthe microscale cavities inbetween thenanowires. The boiling curves

https://doi.org/10.1016/j.ijheatmasstransfer.2021.121367

(2)

I. Snustad, L. Hollund, A. Ervik et al. International Journal of Heat and Mass Transfer 175 (2021) 121367

measured on bothCu andSinanowires are similar toeach other eventhoughthethermalconductivityofthetwomaterialsarevery different.Theaboveresultsindicatethattheheattransferisdomi- natedbythenucleationandbubbledynamics,notbytheheatcon- duction,andthesurfacemorphologyisthedeterminingfactor.

Forcondensation,thenumberofnucleationsiteshavealsobeen shown to increase on nanostructured surfaces. In the work by BoreykoandChen,ahierarchicalsurfaceofSimicropillarscovered with carbonnanotubes wasinvestigatedand thenucleation sites increased significantly along with a decrease in wettability [15]. Thefabrication ofthemicro-andnanostructuresresultedinasu- perhydrophobicsurfaceonwhichthecondensationoccurredinthe dropwise mode. Dropwisecondensation resultsin HTCsup to an orderofmagnitudehigherthantheconventionalfilmwiseconden- sation.OnthesurfacebyBoreykoetal.,thedropletsspontaneously jumpedoff atadropletsizemuchsmallerthanforahydrophobic surface wherethe droplets are removedby gravity. Onthe other hand, not all superhydrophobic surfaces promotes dropwise condensation, but could actually cause a degradation of heat transfer [16]. The surface structures could in this case be flooded by thecondensate,whichisthenstronglypinnedtothesurfaceeven thoughtheappliedmodelspredictthatthesurfaceisnon-wetting.

Dropwisecondensationisadynamicprocessandthedropletscan nucleateandgrowinbetweenthestructures,andconsequently,be pinnedtoasuperhydrophobicsurface[8].Forthisreason,superhy- drophobicsurfacesdonotnecessarilypromotedropwisecondensa- tion.

Both the above mentioned studies, and others examining micro-andnanostructuresforenhanced condensationheattrans- fer [17,18], haveexplored thebeneficial performance ofdropwise condensation. For low surface tension fluids, however, it is ex- tremelychallengingtoobtaindropwisecondensationasmostcon- densates willflood thenanostructures.Ailietal.[19]studiedthe filmwise condensationheattransferofalow surfacetensionfluid onmicrostructuresonaluminium.Theyfoundthattheheattrans- fer wasunaffected by themicrostructures.Theyalsostudiedhow nanostructuresonamini-finCusurfaceinfluencedtheheattrans- ferperformance.Inthiscase,theheattransferwasreducedonthe nanostructured surfacedue to solid-liquid friction, which results in a thickercondensatefilmon thesurface. The heat transferon a pure mini-fin Cu surfacewas, however,higher than on an un- structuredsurface,showingthatincreasingtheeffectivecondensa- tionarea wasbeneficial.Theincrease inheattransferduetoaug- mented surfacesiswell-establishedandmodelsdescribingtheef- fectofdifferentaugmentationgeometrieshavebeendevelopedby Ali [20] andAli andBriggs [21]. The models includegeometrical parameters in addition tothe effectof theratio betweensurface tension andgravity. The latter has a large impact on the flooding ofthesurfacestructures, revealingthat alow surfacetension fluidislesslikelytofloodthestructures.Forsuchfluids,asurface augmentationwithsmallpitchesbetweenthestructureswouldbe morebeneficialthanforahighsurfacetensionfluid,suchaswater.

Even though there are examples of studies on dropwise condensation of low surfacetension fluids, no such studies exist for CO2.Eventhough therefrigerantR134-a hasproventohavesim- ilar flow behaviorto CO₂ [22],the specificheat transferbehavior offilmwise CO₂ condensationis lacking.Inprevious work, using moleculardynamicssimulations,wehaveinvestigatedtheconden- sationmechanismofCO₂ onCulikesurfaces[23,24].Still,experimental studies havenot yet been publishedfor condensation of CO₂ onstructuredsurfaces.Toaddressthis,wehaveinthiswork investigated CO₂ condensation on one untreatedCu surface and threemicro-andnanostructuredCubasedsurfaces.Theuntreated surfaceservesasthebaselineforthecomparisonoftheheattrans- ferbehaviorofthemodifiedsurfaces.Ofthose,twoarehierarchical in scale, with an underlyingmicrostructure covered with nanos-

tructures. Thethird substrate ispurely nanostructured,with ran- domlyorientednanoneedlescoveringtheentiresurface.The heat transferperformanceofthefoursubstratesareevaluatedandcom- pared.Theaimofthestudyistodetermineifandhowmicro-and nanostructuresinfluencetheheattransferduringfilmwiseconden- sationofalowsurfacetensionfluid.

Themainﬁndingsoftheworkisthattheheattransferisdeter- minedbythecompetingeffectofnanostructuresandthereduced thermalconductivityofCuO.Thenanostructuresinducesawicking condensationmode,whichincreasestheheattransfercomparedto ﬁlmwise mode, butthe reducedthermal conductivity ofCuO re- ducesthepotentialheattransferincrease andtheheattransferis thereforeunalteredwhenthenanostructuredensityishigh.

This paper is organizedas follows. First, we describe the experimental methodapplied formeasuring the condensation heat transferfollowed by detailson thefabrication of thethreestruc- turedsurfaces.Second,theresultsarepresentedalongwithadis- cussionoftheir meaningandsigniﬁcance.Finally,conclusionsare drawnandsome furtherworkisstipulated.Theresultsofastudy ofthemechanicaldurabilityofthenanostructuresasaresponseto CO₂ condensationisincludedintheSupplementaryInformation.

2. Methodandmaterials

The experimental method used for measuring heat ﬂux and HTCsinthisworkisdescribedindetailinourpreviouswork[25]. A summary of the method and a description of the fabrication methodsforthehierarchicalandnanostructuredsurfacesaregiven inthissection.

2.1. Experimentalmethod

Theexperimentalmethodreliesononedimensionalheattrans- portthroughaninsulatedCucylinder,whereacoolingelementis attachedtooneend,andtheinvestigatedsurfacetotheother.Four type Kthermocouples(Omega Engineering)areembeddedin the centerofthecylinderto obtaintheaxial temperaturegradientin thecylinder,whichinturnisused tocalculatetheheat ﬂux.The uncertaintyofthethermocouplesprovidedbythemanufactureris 1K.To reduce theuncertainty, thethermocouples arecold junc- tioncompensatedin awatercooling bath(Julabo) andcalibrated onsiteinanicebath.Bythisproceduretheuncertaintyisreduced andtakento be equal tothe standard deviationofthe measure- mentsintheicebathcalibration,whichwas0.02K.

Thecooling elementattachedto theCu cylinderisa Cublock with narrow channels. Within the channels, two phase CO₂ is ﬂowedthroughandevaporated,withaback-pressureregulatoren- suringthatthe pressureinsidethe coolingelementis thesatura- tionpressureforthedesiredtemperature.Inthisway,theCO₂ is kept atthe boilingcurve andtwo phase ﬂow is keptthroughout thecooling element.The temperatureonthe surfaceofthecool- ing element is thus uniform andaccurately controlled by a back pressureregulator(AlicatPC3).Theavailabletemperaturerangeis 55 to 20 ^◦C, corresponding to a saturation pressure from 5.7 to 19.7bar.

TheinvestigatedsubstrateisattachedtotheCucylinderwitha thermalinterface material(TIM(AldrichChemistry,Silverconduc- tivepaste,735825-25G)).Priortoattachment,thebaselineCusur- faceis cleanedwithacetone,isopropanol andethanol(VWR, 99%

reagentgrade),inthatorder.Thestructuredsurfaceswerecleaned priorto structurefabrication andkept inclosedcompartmentsto avoiddeteriorationofthemicro-andnanostructurespriortoheat transferexperiments.

Thecoolingelement withthe attachedcylinderandsubstrates areplacedinapressurechamberconsistingofasteelpipeclosed off byﬂangesandbolts. Asight glassisembeddedin oneﬂange

(3)

Fig. 1. Photograph of the investigated substrate as seen through the glass in the end ﬂange of the pressure chamber. The embedded thermocouples are also seen.

The Cu cylinder is enclosed in the teﬂon insulation and is hidden behind the substrate. A LED strip enlightening the substrate is also shown.

andahighspeedcamera(Phantom9.1)isplacedclosetotheglass forinsituobservationofthecondensationprocess.Specifically,the onset of the condensation is observed. The pressure chamber is builtforpressuresupto20barandisfilledbypureCO₂(5.2,AGA Scientific Grade) during experiments.A pressureregulator (Alicat PCD) maintains a constant pressure in the chamber, also during condensation.Theendflangewiththeseeglassandthesubstrate withinthechamberisshowninFig.1.

ThetemperatureintheCucylinderiscontrolled,monitoredand acquired withaLabView^TM interface. Inaddition,the pressure in the chamber, the temperatureof the gasand inthe cooling ele- mentiscontrolledandmonitoredbythesoftware.

2.2. Materialfabricationandsurfacedescription

Four substrates have been investigated in this work: (a) an untreated Cu plate, (b) a nanostructured Cu surface, (c) and(d) micro- andnanostructured surfaces with variation in nanostruc- ture density. Allsubstrates were initially 0.5mm thick quadratic (2.5×2.5 cm) Cu plates(99.9% purity, Sigma-Aldrich). The base- line Cu is untreated and hasa low intrinsicroughness. The root meansquare(RMS)roughnessismeasuredinaVeelcoDektak150 proﬁlometertobe73nm.

The nanostructured surface is fabricated with an adaption of the solutionimmersion techniquedevelopedby He etal.[26,27]. The Cu substrate is cleanedwith acetone andisopropanol, dried withnitrogenandimmersedinto asolutionof 0.1Mammonium persulfate and 2.5 M sodium hydroxide for 3 M. The surface is then dried at 120 ^◦C to fully dehydrate the structures, resulting inasurfacewithstableCuOnanoneedles,seeFig.2.Thewidthof the nanoneedlesis onaverage 175nm andthe average lengthis 3μm.Thenanoneedlesinitiallygrowatnucleationsiteswithhigh surfaceenergy suchasspikes andhills onthe surface. Therefore, the underlying surfacestructureof theCu surface isobserved as lines withhighernanoneedle density.Thenanostructured surface ishenceforthnamedNS.Noteherethatthenanoneedlesaremade oftheoxidecorrespondingtothesubstratemetal,i.e.CuO,apoint whichwillprovetobeimportantforthesubsequentcondensation heattransferanalysis.

For fabricating the hierarchical structures, the ﬁrst step is to etch micropillars into the Cu substrate by photolithography and chemical assisted ion beam etch (CAIBE). Photolithography is a process for transferring a patternontoa surface byexposing the

surface covered in a photoreactive material (photoresist) with a laser ina predefinedpattern. The photoresisthardens andworks as a mask for the following etching process. CAIBE is an etching method for physical sputtering of unprotected material on a surface. In thiswork, photoresistmicropillars with a diameterof 10 μm were deposited onto the Cu surface. These micropillars protectedthe underlyingCu inthe CAIBEprocess, andthemate- rialaround thephotoresistwasetched.Theresultingsurfacepat- tern after photolithgraphy andCAIBE are Cu micropillars, shown inFig. 3.The micropillarsare onaverage 10 μmindiameterand 1 μm in height. For the two hierarchical surfaces, the exposure doses in the photolithography process were the only fabrication difference. One surface, Fig. 3(a), was exposed with a laser with 1700 mJcm⁻² energy flux, andthe other, Fig.3(b) was exposed with1900mJcm⁻²energyflux.Thisdifferenceaffecttheresulting nanostructuredensityasdescribedbelow.

Followingthemicropillarfabrication,thenanostructuresontop of the microstructures are fabricated in the solution immersion processdescribedabove,withan immersiontimeof5M.There- sulting nanoneedles are approximately 10 μm long for both surfaces. The morphology is different on the surface exposed with 1700mJ cm⁻² andthe one exposed with1900 mJcm⁻². Hence- forth the ﬁrst is calledS17 andthe latter iscalled S19. The two surfacesareshowninFigs.4and5,respectively.Itisobservedthat the nanoneedles grow more uniformly on the S19 surface com- paredtotheS17surface.OntheS17surface,thereisalargevaria- tioninthenanoneedledensityacrossthesurfaceandthenanonee- dlesgrowboth onthesidesandontopofthemicropillars.How- ever, the nanoneedles grown on the top of the micropillars are shorter. Aroundthe majority ofthe micropillars the nanoneedles havegrown inthehorizontaldirection, normalto themicropillar circumference.Attherestofthemicropillarsthenanoneedleshave growninalldirectionscausingdenseclustersonthesidesandtop ofthemicropillars.OntheS19surface,thenanoneedlesgrow,toa largedegree,onlyonthesidesofthemicropillarsandwithamore uniformandhigherdensitythanonS17.OntheS17 surfaceclus- tersof nanoneedlesare observedboth on topof andinbetween some micropillars.Themaindifference ingrowthonS17andS19 iscausedbytherobustnessofthephotoresistthatispresentatthe topofthemicropillars,seeFig.3.We proposethat thedifference inrobustnessiscausedby thedifferencein exposuredoseinthe photolithography step. At the S17 surfacethe nanoneedlesocca- sionallygrowfromunderneaththephotoresistandthephotoresist isliftedoff theCumicropillar.ThiscanbeseeninFig.4(b).Onthe S19thisbehaviorisnotobserved,andasaresult,thenanoneedles onlygrowfromthesidesofthemicropillar.

Thetopography andtheappearance ofthestructured surfaces havebeeninvestigatedwiththeuseofaScanningElectronMicro- scope(SEM,FEIApreo).Thesecondaryelectronsweredetectedand abeamcurrentof0.2nAandanaccelerationvoltageof10kVwere applied(detailsonSEMtheorycanbefoundinAkhtaretal.[28]).

Afterpreparationinacleanroom,thethreefabricatedsurfaces are carefully handled in closed boxes to ensure that the struc- turesarenotdamagedbeforetheheattransferexperiments.When thesubstratesareattachedtotheCucylinderintheheattransfer setup,theyarehandledwithglovesandonlytouchedintwocor- ners.Asthewidthofthesubstratesarehigherthanthediameter ofthecylinder,thesurfaceatwhichthecondensationwilloccuris leftuntouched andthesurfacestructures arethesameunderthe heattransferexperimentsasdescribedinthissection. Toconﬁrm thestabilityofthestructures,SEMimageswererecordedbothbe- foreandafterthecondensationexperiments. Theresultsare pre- sentedintheSupplementaryInformation.

(4)

Fig. 2. Scanning Electron Microscope image of CuO nanoneedles on Cu substrate fabricated by solution immersion for 3 min. This surface is called NS.

Fig. 3. Cu surface with micropillars after deposition of photoresist and 2 times etching by CAIBE. The exposure doses in the photolithography step are (a) 1700 mJ cm ⁻²(S17) and (b) 1900 mJ cm ⁻² (S19). The micropillars’ height is approximately 1 μm. The width of the base of micropillars in (a) is approx. 10 μm, and in (b) the base width is approx. 13 μm. The dark color of the surfaces of the micropillars is caused by photoresist residue. In (b) some redeposited Cu is visible between the micropillars.

2.3. Datareduction

The dataacquiredinthe experimentsare the temperaturesin thefourthermocouplesembeddedintheCucylinder.Theheatﬂux andtheHTCsthat arepresentedinthiswork arecalculatedwith theequationsinthissection.

The temperaturemeasurements are ﬁttedwith a linearequa- tion relatingthe temperatures to the location of thethermocouples withintheCu cylinder.The regressiongivesthetemperature gradient,

∇

^T,throughtheCucylinderandthesurfacetemperature oftheinvestigatedsubstrate,T_{sur f},byextrapolation.

∇

^T ^is^used^to

calculatethetotalheatﬂuxqtot throughthecylinder,accordingto Eq.(1),wherekisthethermalconductivityofCu.

qtot=−k

∇

^T ⁽¹⁾

The condensation heat flux, which is the portion ofthe heat flux that we are interestedin,is not equal tothe total heat flux throughthecylinder.Someheatistransportedthroughtheinsula- tion,some goesto coolingthe gasinthepressure chamber prior to condensation, and some heat is lost internally in the investi- gatedsubstratecausedby thegeometricalmismatchbetweenthe sphericalCucylindersurfaceandthequadraticsubstrates.Weas- sume that the heat loss is independent of the subcoolingof the surfaceversus thesaturation temperature.The condensation heat fluxisthereforefoundbylinearlyextrapolatingtheheatfluxdata to zero subcooling, and subtracting the resulting constant value fromeach data series. Inthis way,the condensation heat flux is zeroforzerosubcooling, asrequired.Eachexperimentisrepeated 3-6times.Theexactnumberisdeterminedbythedeviationinthe datafromexperimenttoexperiment.After3experimentsweeval- uatedtheconsistencyintheresultsanddeterminedifanotherse- rieswasnecessary.

ThecondensationHTC,h_cond,isdeﬁnedbyEq.(2),whereTsat is thetemperatureatthe givensaturationpressure,T_{sur f} isthesur- facetemperature,givingthesubcoolingofthesubstrateTsat−T_{sur f}. Tsat isfoundbyusingtheSpanWagnerequationofstate[29]with thepressure inthechamber asinput. TheNIST Webbook isused

(5)

Fig. 4. SEM images of the hierarchical Cu/CuO structures for which the micro structures are fabricated with photolithography with exposure dose of 1700 mJ cm ⁻², named S17. In (a), an overview of the surface is shown with a 1200 times mag- niﬁcation. In (b), one of the Cu cylinders covered in CuO ﬂakes and nanoneedles is shown. The nanoneedles grow primarily on the top and on the sides of the mi- crostructure, however the length of the nanoneedles are much shorter when grow- ing on the top of the cylinder and the microscale of the Cu cylinders is intact.

Smaller nanostructures, as ﬂakes and needles, are grown at the ﬂat surfaces between the micropillars.

Table 1

Table with the estimated uncertainties used for calculating the overall uncertainties in heat ﬂux and subcooling.

Parameter Uncertainty T C1 , T C2 , T C3 , T C4 ±0.0337 K P sat ±0.0875 bar T sat ±0.2 K t T IM ±0.05 mm

T sur f ±0–0.35 K (depending on heat ﬂux)

k Cu ±0.013% [31]

x 4 −x 1 ±0.04 mm

forthecalculation[30]. hcond= q_cond

Tsat−Tsur f

(2)

2.4. Uncertaintyanalysis

Anuncertaintyanalysisbasedonthepropagationoferrorshave beenperformed.Theresultingexpressionforthetotalerrorinheat ﬂux, Eq,is presentedinEq.(3), andthetotal errorinsubcooling isshowninEq.(4).The valuesusedforcalculatingtheerrorsare showninTable1.

Eq=

_T₄₋_T₁

d1−4

²

E²_k+2

k

d1−4

2

E_T²+

T4−T1

d₁²₋₄

2

E²_d (3)

Fig. 5. SEM images of the hierarchical Cu/CuO structures for which the microstructures are fabricated with photolithography with exposure dose of 1900 mJ cm ⁻², named S19. (a) shows an overview of the surface with 1200 times magniﬁcation, where the high density of nanoneedles is evident. (b) shows one of the micro- cylinders covered in nanoneedles, 6500 times magniﬁcation. The nanoneedles grow mainly on the sides of the cylinders and in all directions partly covering the Cu surface between the cylinders with horizontal nanoneedles.

ET=

E_T²

sat+E_T²

sur f (4)

Here,E_kistheestimatederrorinCuthermalconductivity,ET is theerrorinthetemperaturemeasurements,andE_d istheerrorin thedistancebetweenthethermocouples.

Theerrorintemperaturemeasurements,E_T,isestimatedbased on the icebath calibration of the thermocouples, using the stan- darddeviationoftheestimatedcalibrationvalueasaconstanter- rorinthemeasurements.Wehaveestimatedthetemperaturede- pendentthermalconductivityofCufromthecorrelationpresented by Abu-Eishah [31]. The placement of the thermocouples inside the Cu cylinder hasbeen measured with a caliper andthe error isthereforeassumedtobewithin0.02mm,relatingtothesmall- est measurablevalues witha caliper. The errorin the saturation temperature, E_T_sat,is based onthe givenuncertainty ofthepres- surecontroller used to control the pressure inthe chamber. The errorinthesurfacetemperature,E_T

sur f,iscalculatedfromtheun-

certaintyinthethicknessofthethermalinterfacematerial,t_T_IM. 3. Results

Fig.6 showsthe temperature measurements inthe four ther- mocouplesembeddedintheCu cylinderduringcondensationex- periments on the ﬂat Cu at 15 bar. T1 is situatedclosest to the cylindersurfaceandT4isclosesttothecoolingelement.Thetem-

(6)

Fig. 6. Temperature measurements in the cylinder during the condensation of CO 2 on ﬂat Cu when varying the surface temperature at 15 bar. T1–T4 are the thermocouples embedded in the cylinder, with T1 closest to the cooling element and T4 closest to the investigated surface. The jumps in time are the time it takes for a new temperature level to stabilize. Each temperature is kept for 180s.

peraturegradientgraduallyincreaseswithdecreasingtemperature inthecylinder.Thejumpsintimearethetimeittakesforanew stabletemperatureleveltobereached.Thestabletemperaturesare recorded for3 min for each level of subcooling, and the result- ingaveragetemperaturegradientisusedtocalculatetheheatﬂux throughthecylinderwithEq.(1).

The condensation heat flux of CO₂ on Cu, S17, S19, and NS as functions of subcooling are shown in Fig. 7, with chamber pressures of 10, 15, and20 bar. Forall saturation pressures, the CO₂ condensationheat flux on the S17 substrateis significantly higherthanon thethreeothersubstrates.Theheat fluxiswithin theerrorestimateforCu,S19andNS,andnosignificantdifference betweentheheattransferbehavior onthesesurfacesisobserved.

Forallsurfacesandpressurestheheatﬂuxincreaseswithincreas- ingsubcoolingbetweensurfaceandsaturatedgas,asexpected.

The condensation HTCs calculated from the heat flux data in Fig. 7withEq.(2),are showninFig.8.Forsubcoolingabove 1K, the condensation HTCis nearly independent ofsubcoolingon all substrates. Thereisa slightdecreasein thecondensationHTCon S17 for increasing subcooling at saturation pressures of 15 and 20bar,whilefor10bartheHTCisapproximatelyconstant forall levels ofsubcooling. The condensationHTCis significantly higher onS17comparedtotheothersurfaces.Atmaximumdeviation,the HTC is66% higheron S17 thanthe flat Cu, S19 andNS surfaces.

This occursfor20bar saturationpressure andapproximately1 K subcooling.

AlongwiththemuchhighervaluesofcondensationHTConS17, thepressuredependenceisalsomorepronouncedforthissurface, asshowninFig.9.TheincreaseinHTCis30%whenincreasingthe saturation pressurefrom10to 15bar,whileitis10% forS19, the structurewiththesmallestpressuredependence.Whenincreasing the pressure from15 to 20 bar, theHTC on Cu, S17and S19 increases withbetween1.6and4.2%.The HTCon theNS substrate decreaseswith2.2%between15and20bar.

4. Discussion

Condensation heattransferisacomplexprocess andtheexact physical mechanisms ofthe condensation on nanostructured and hierarchical structures cannot be proved atthismoment. Never-

Fig. 7. Condensation heat ﬂux data for the four investigated substrates at 10, 15, and 20 bar. Each data point is the average of repeated experiments and the errors bars are the results of the uncertainty analysis.

theless,thereare resultsfromliteraturethatcan belooked atfor anindicationoftheheattransferbehavioronthefoursubstrates.

Asseen intheresults,the HTCandtheheatﬂux ontheunstruc- turedCu, theS19 andtheNSsurfacesare within theuncertainty rangeofeachother,andthereforeconsideredequal.Thisisanin- triguingresult, andwe suggest thatthis iscausedby threecom-

(7)

Fig. 8. Condensation HTC for Cu, S17, S19 and NS at saturation pressure of 10 bar, 15 bar, and 20 bar. Refer to Fig. 7 for uncertainty of experiments.

10 15 20

Saturation pressure,bar 2.0

2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0

CondensationHTChc,kW/m2K

Tsat-Tsurf=1.7K S17

NS

S19 Cu

Fig. 9. The condensation HTC as a function of saturation pressure for the four in- vestigated materials: ﬂat Cu, S17, S19 and NS. The subcooling is 1.7 K in all cases.

peting effects: (1) lower thermal conductivity of CuO compared with Cu, (2) increase in surface area due to the nanostructures and(3)ﬂoodingofthenanostructures.Anoxidizedmetallicsurface generally has a lower thermal conductivitythan the pure metal.

This is indeed the case for Cu and CuO, for which the thermal conductivity decreases from typical values of 400 Wm⁻¹ K⁻¹ to 33Wm⁻¹ K⁻¹ fortheoxidizedmetal[32].Ifthethermalconduc- tivityalonewouldhavebeenthedeterminingfactor,asinHoenig etal.[33],theHTCshouldhavebeenlower onthestructuredsur- faces. It isthereforeapparent that thesurfacestructures increase the heattransferinsucha waythat theybalancethe decreasein thermalconductivitycausedbytheoxidation.Anincreaseinheat transfer due to surface structures is attributed to the increased

Cu

CuO nanoneedles CO2condensate

Cu Cu

Cu microstructures

Fig. 10. Sketch of the ﬂooding of the high density nanostructured surfaces, S17 and NS.

heattransferarea.Thisiswell-knownforaugmentedsurfacessuch asfins on tubes [34] andpin-fins on tubes [35]. However, ifthe spacing between the surfacestructures is small, the heat transfer increase dueto augmented surface area can be counteracted by surfaceflooding. Ali et al.[36] showed that by lowering the spacingbetweenthesurfacestructures,theeffectofincreasedheat transfer area is balanced by a heat transfer reduction caused by flooding.OnboththeS19andtheNSsurfacesthenanoneedleden- sityishighandtheentirestructuresonthesurfacesaretherefore likelycompletelyfloodedduringcondensation.TheresultingHTCs arewithin theuncertainty rangeofeachother andindistinguish- ablefromthe HTCson theunstructuredCu. The increasein heat transfercausedbythehigherareaonthesurfacesarehencecom- pletely balanced byflooding andthe low thermalconductivityof theCuOnanoneedles.Asaconsequence,theheattransfertheS19, NS anduntreated Cu resembles conventional filmwise condensa- tiononflatsurfacesaselucidatedinFig.10.Thefilmthicknesson theS19andNSsurfacesarehigherthanonthebareCusurfacedue to liquidretention in the floodedareas, butthe increase in heat transferareabalancestheincreasedthermalresistancethroughthe film.

The S17 surface clearly exhibits a different thermal behavior thantheothersurfaces.TheheatfluxandtheHTCaresignificantly higherforthissurface.Thelowernanoneedledensityincreasesthe hierarchical nature of the surface, and reduces the likelihood of complete flooding. The surface area between the micropillars is not filled with nanoneedles, as on the S19 surface, and the flat area is beneficial for the heat transfer. The proposed condensation mechanismisthat the nucleation andspreadingof thecon- densatefilmoccursonthe non-structuredareasbetweenthemi- cropillarsandthatthenanoneedlesandthemicropillarsreducethe filmthickness.Theunstructuredareasbetweenthemicropillarsare notcompletelyflat,andspikesandgroovesareavailablenucleation sites. The reduced film thickness is a result of a more efficient drainage ofthe CO₂ liquid along the space betweenthe micro- andnanostructures,comparedtothepinnedliquidontheS19and NS surfaces. Efficient drainagewill lead to a thinner CO₂ liquid film,whichagainincreasestheHTC.

AccordingtothemodelbyAlietal.[36],floodingislesslikely tooccurontheS17surfaceduetothelargerspacingbetweenthe structures. Returning to theeffect ofthe threecompeting factors 1),2) and3) above,where thelatterwasrelatedtoflooding, the resulting the HTC is higher on S17 compared to S19 and NS. In contrasttotheworkbyAilietal.[19],wehereshowthat anop- timal combination of micro- andnanostructures is beneficial for

(8)

heattransportincertaincases,andespeciallywhenthehierarchi- calnatureofthesurfaceispronounced,suchasforS17.

The influence of pressure on the heat transfer is highest for the NS andthe S17 surface, whichboth show a high increase in the HTC between10 and15 bar, seeFig. 9. The S17surface also exhibit aslight increase inHTCwhen reaching 20 barsaturation pressure,whiletheHTContheNSstructuredecreasesbetween15 and20 barsaturation pressure.According toPreston etal.flooding of the nanostructures will occur in wicking condensation at high valuesof subcoolingdueto the highamountof condensate as the subcooling is increased [37].When increasing the saturationpressure,ontheotherhand,thecondensatefilmthicknessde- creasesandtheHTCincreases.Floodingisthereforenot thelikely explanation oftheapparentsaturation ofthe HTC.The plateauin theHTCisthereforeexplainedbythefluidpropertiesofCO₂ and howthesearealteredwithpressure.Especially,theviscosityisde- creasedwithincreasingpressureandtheresultcouldbea higher downwardflowrateoftheliquid.Thiswouldagainleadtoathin- ner liquidfilmandan increasedheat transfer.Onecould imagine that theliquid flowdown thesurfacedeterioratesthenanostruc- tures, and that this could influence the pressure dependence of the heat transfer. The nanoneedles could be bent orbroken and flusheddownalongwiththecondensate.Wehave,however,investigated the surfacesbefore and aftercondensation, andfind that both the micropillars and nanoneedles are intact after repeated condensationexperiments.DetailscanbefoundinSupplementary Information.

5. Conclusionsandoutlook

We have in this work experimentally investigated the heat transferbehavior ofCu basedsurfacesduringthecondensationof CO₂.Threedifferentmicro-andnanostructuredsurfaceshavebeen fabricated andcompared in terms ofheat ﬂux andheat transfer coeﬃcient duringthecondensation. Thesurfaces are(1)a purely nanostructured surface where CuO nanoneedles are grown on a Cusubstrate,(2)ahierarchicalsurfacewithCumicropillarsunder- neath CuOnanoneedleswithhighdensity,and(3)asurfacesimi- lartothesecond,butwherethenanoneedlesaremuchlessdense.

We have shownthat when theright balance betweenstructured andunstructuredsurfaceareaisfound,theoutcomeisanincrease inthecondensationheattransfer.Onsurfaceswithahighdensity ofCuOnanoneedles,thereducedheattransferduetolowerther- malconductivityoftheoxidizedsurfaceandincreasedheattrans- fer duetothe highereffectivesurfacearea neutralizeeach other.

The HTCsare thereforesimilar onthe purelynanostructured surface, themicro-andnanostructuredsurfacewithhighnanostruc- ture density, and the ﬂat untreated surface. However, when the densityofthenanostructuresislower,suchthatthetruehierarchi- calnatureofthesurfaceismorepronounced,theHTCisincreased withmaximum66%comparedtotheuntreatedsurface.Thework showthatsurfacestructureshaveapotentialofincreasingconden- sation heat transfer of CO₂ ifdesigned and fabricated properly.

Theoptimaldesigncriteriahaveyettobedeveloped,butthepath of hierarchicalsurfacesisvery promisingandshould befollowed infuturework.

DeclarationofCompetingInterest

Authorsdeclarethattheyhavenoconﬂictofinterest.

CRediTauthorshipcontributionstatement

IngridSnustad:Conceptualization,Methodology,Software,Val- idation, Formal analysis, Investigation, Data curation, Writing -

originaldraft,Writing -review &editing,Visualization. LeneHol- lund:Validation, Investigation, Data curation, Writing -review &

editing. ˚AsmundErvik:Conceptualization,Methodology,Software, Validation, Formal analysis, Writing - review & editing, Supervi- sion. AndersAustegard: Methodology, Formal analysis, Writing - review & editing. Amy Brunsvold: Conceptualization, Methodol- ogy,Writing-review&editing,Supervision.JianyingHe:Writing- review &editing,Supervision.ZhiliangZhang:Conceptualization, Methodology,Formalanalysis,Writing-review&editing.

Acknowledgments

This publication has been produced with the support of the Research Council of Norway through the CLIMIT funding pro- gram (254813 ), and through the Norwegian Micro- and Nano- FabricationFacility,NorFab(245963/F50).

Supplementarymaterial

Supplementary material associated with this article can be found, in the online version, at 10.1016/j.ijheatmasstransfer.2021.

121367
