Membrane vesicles from Piscirickettsia salmonis induce protective immunity and reduce development of salmonid rickettsial septicemia in an adult zebra ﬁ sh model

Julia Tandberg

^a^,^b

, Cristian Oliver

^c^,^d^,^e

, Leidy Lagos

^a^,^b^,¹

, Mona Gaarder

^b

, Alejandro J. Y a~ nez

^c^,^e^,^f

, Erik Ropstad

^g

, Hanne C. Winther-Larsen

^a^,^b^,^*

aCenter of Integrative Microbiology and Evolution, University of Oslo, Oslo, Norway

bDepartment of Pharmaceutical Biosciences, School of Pharmacy, University of Oslo, Oslo, Norway

cInstitute of Biochemistry and Microbiology, Faculty of Science, Universidad Austral de Chile, Valdivia, Chile

dDepartment of Biological Science, Faculty of Biological Science, Universidad Andres Bello, Santiago, Chile

eInterdisciplinary Center for Aquaculture Research (INCAR), Concepcion, Chile

fAustral-OMICS, Faculty of Science, Universidad Austral de Chile, Valdivia, Chile

gDepartment of Production Animal Clinical Sciences, Faculty of Veterinary Medicine and Biosciences, Norwegian University of Life Sciences, Oslo, Norway

a r t i c l e i n f o

Article history:

Received 14 March 2017 Received in revised form 1 June 2017

Accepted 5 June 2017 Available online 13 June 2017

Keywords:

Piscirickettsia salmonis MVs

Vaccine SRS Zebraﬁsh Immune response

a b s t r a c t

Infections caused by the facultative intracellular bacterial pathogenPiscirickettsia salmonisremains an unsolved problem for the aquaculture as no efficient treatments have been developed. As a result, substantial amounts of antibiotic have been used to limit salmonid rickettsial septicemia (SRS) disease outbreaks. The antibiotic usage has not reduced the occurrence, but lead to an increase in resistant strains, underlining the need for new treatment strategies. P. salmonis produce membrane vesicles (MVs); small spherical structures know to contain a variety of bacterial components, including proteins, lipopolysaccharides (LPS), DNA and RNA. MVs mimics' in many aspects their mother cell, and has been reported as alternative vaccine candidates. Here, MVs fromP. salmoniswas isolated and evaluated as a vaccine candidate against SRS in an adult zebrafish infection model. When zebrafish was immunized with MVs they were protected from subsequent challenge with a lethal dose ofP. salmonis. Histological analysis showed a reduced bacterial load upon challenge in the MV immunized group, and the mRNA expression levels of several immune related genes altered, includingmpeg1.1, tnfa^,^{il1b, il10}ând^{il6. The} MVs induced the secretion of IgM upon immunization, indicating an immunogenic effect of the vesicles.

Taken together, the data demonstrate a vaccine potential of MVs againstP. salmonis.

1. Introduction

The Chilean salmon production is one of the largest aquaculture industries worldwide, with a production rate of 605.800 tons of Atlantic salmon in 2016 and a calculated exportation value of US$2.3 million [1,2]. The continuous expansion of the Chilean salmon industry has, however, not been without difﬁculties, as the introduction of new farming areas and species have led to the

development of infectious diseases[3,4]. One of the most important pathogen found in seawater in Chile is the intracellular bacterial pathogen Piscirickettsia salmonis, the etiologic agent of salmonid rickettsial septicaemia (SRS), a chronic and often fatal disease in salmonid[5,6].P. salmoniswas isolated and characterized from Coho salmon (Oncorhyncus kisutch) in 1989 after a devastating epizootic in the Chilean aquaculture industry[5]. Since then, the bacteria have been recognized as an emerging problem with outbreaks of SRS reported across the world[7e9].P. salmonishas been identiﬁed in salmon net-pens in Norway, Canada, Ireland and Scotland, but with a reduced virulence compared to the Chilean strains[10]. Continuous outbreaks of SRS have had a devastating impact on the Chilean aquaculture, with losses exceeding US$ 100 mill a year[11,12], despite the availability of several vaccine options on the marked[4].

*Corresponding author. Centre for Integrative Microbial Evolution (CIME), Department of Pharmaceutical Bioscience, School of Pharmacy, University of Oslo, PO Box 1068 Blindern, 0316, Oslo, Norway.

E-mail address:[email protected](H.C. Winther-Larsen).

1 Present address: Department of Animal and Aquacultural Sciences, Norwegian University of Life Sciences, Ås, Norway.

Contents lists available atScienceDirect

Fish & Shell ﬁ sh Immunology

j o u r n a l h o m e p a g e : w w w . e l s e v i e r . c o m / l o c a t e /f s i

http://dx.doi.org/10.1016/j.fsi.2017.06.015

).

(2)

After the release of theﬁrst commercial vaccine against SRS in 1999, over 50% of the salmon in Chile was vaccinated against P. salmonis, but by 2003 the number had dropped to 17%, indicating that the initial vaccines provided unsatisfactory protection [11].

Nowadays, there are 33 different licensed vaccines against SRS available in Chile, where the majority are composed ofP. salmonis pre-treated with either heat or formalin, known as bacterin based vaccines [4]. The use of bacterins for immunization of ﬁsh has provided substantial protection against a range of pathogens, including Edwardsiella ictaluri, Flavobacterium columnare, Vibrio anguillarumandYersinia ruckerii[13,14]. There are, however, cases where the use of bacterins provides a limited protection against bacterial pathogens, which includes P. salmonis [10,13]. As a consequence, the Chilean aquaculture industry continues to use large amounts of antibiotics to control aquatic diseases, which in 2014 represented 70% of the total antibiotic use in the entire country [4]. The use of antibiotic treatment against SRS has, nonetheless, had little success in regards to disease control, but led to the emergence of antibiotic resistant strains of P. salmonis [15e17]. Thus, outbreaks of SRS are still an escalating problem for the aquaculture industry[4].

The development of new vaccines againstP. salmonisis, however, challenging due to the intracellular nature of the bacteria.

P. salmonishas been shown to infect, replicate and survive within macrophages as a part of its infection strategy. The infection process includes the formation of vacuoles within the host cells, enabling the bacterium to avoid thefish's primary immune defense [8,18e20]. Thus, vaccination against SRS depends on an activation of both the antibody- and cellular-mediated immune system to provide a sufficient protection[21]. Immunization activating both immune systems is, on the other hand, difficult as it require antigens to be represented through MHC receptors of specialized cells of the immune system[22]. Live attenuated vaccines have suc- ceeded in activating both systems, as they in many ways mimic a natural infection upon immunization. There is, however, a risk of the attenuated bacterium reverting back to a virulent state, which can pose potential environmental, industrial and economical hazards[23]. This is particularly problematic for aquaculture, due to the potential release of a virulent strain into the fish's natural habitat[24]. An alternative would be a non-replicating version of the bacteria, like membrane vesicles (MVs), sharing many characteristics with live attenuated bacteria.

Membrane vesicles are 50e250 nm spherical structures, secreted from the surface of many bacteria during all stages of growth[25e27]. Bacterial MV secretion has been associated with several phenotypes including biofilm formation [28], bacterial survival[29], toxin delivery[30], cell-to-cell communication[31], and host-pathogen interactions [32]. Proteomic and biochemical characterization has revealed that the vesicles contain a variety of bacterial components, including proteins as well as lipopolysaccharides (LPS), DNA and RNA[33e36]. MVs have also been reported to contain several important immunogenic factors, such as toxins [37], chaperons [38], and active enzymes [34]. Together they represent several aspects of the bacteria, but in a non-replicative form. The mechanisms of the MV formation and their biological role have, however, yet to be clearly defined. Bacterial MVs have successfully been used for epidemic control against serogroup B meningococcal disease in Cuba, Norway, Brazil, and New Zealand [39e42]. MVs used in vaccination offish have also been reported to provide protection against Edwardsiella tarda in olive flounder (Paralichthys olivaceus) [43], Flavobacterium psychrophilum in rainbow trout (Oncorhynchus mykiss)[44], andFrancisella noatu- nensisin zebrafish(Danio rerio)[45]. MVs fromP. salmonishave been shown to be internalized byfish cell cultures, express toxicity in adult zebrafish and contain several immunogenic proteins, such

as TolC, GroEL and DnaK[46,47]. Thus, the main aim of this study was to evaluate the potential of MVs as a vaccine candidate against SRS using an adult zebraﬁsh model.

2. Materials and methods

2.1. Bacteria, media and growth conditions

Cultivation of P. salmonis LF-89 (type-strain ATCC VR 1361) isolated from Coho salmon (Oncorhyncus kisutch) in Chile[5]were routinely grown at 20C on Eugon Chocolate Agar (ECA), containing 30.4 g/L BD Bacto TM Eugon Broth (Becton, Dickinson and Company), 15 g/L Agar Bacteriological (Thermo Fisher Scientiﬁc) and 5% bovine blood (Håtunalab AB)[48]or in EBFC containing BD Bacto TM Eugon Broth supplemented with 2 mM FeCl3 (Sigma- Aldrich) and 1% Casamino Acids (BD) with agitation (100 rpm) for 7e10 days. The bacterial stocks were frozen in autoclaved 10%

skimmed milk (BD Difco) or in BD Bacto TM Eugon Broth supplemented with 20% glycerol (Sigma-Aldrich) and stored at80C.

2.2. Isolation of membrane vesicles

10 mL of exponential-growth phase cultures ofP. salmoniswas used to inoculate 200 mL of EBFC. The cells were grown at 20C with agitation, and growth curves were measured by using optical density reading at 600 nm until the isolates reached late exponential-phase. OMVs were isolated as described[46]. Briefly, the bacterial cells were removed by centrifugation (10 min, 15 000 g, 4C), and the supernatantfiltered sequentially through a 0.45- and 0.22m^m/porefilter in order to remove the remaining bacterial cells. Thefiltrate was then ultra-centrifuged sequentially at 125 000 g at 4C for 2 h and 125 000 g at 4C for 30 min to eliminate cell debris and aggregates. The MVs were resuspended in 100mL 5 mM phosphate buffer (1:2 monobasic dihydrogen phosphate and dibasic monohydrogen phosphate) pH 6, and protein concentration determined by a Picodrop spectrophotometer (Picodrop Limited, UK). MV aliquots (10mL) were spread onto ECA plates to check for sterility, and the remaining sample was stored at80C until use.

2.3. Adult zebraﬁsh rearing

10-11 months old male and female Zebrafish (Danio rerio) wild type strain AB was obtained from the modelfish unit at the Nor- wegian University of Life Science. The fish were acclimatized to room temperature (20±2C) two weeks prior to the experimental setup. Thefish were fed every morning with brine shrimp (Scanbur AS) and SDS 400 Scientific Fish Food (Scanbur AS) in the afternoon.

The water was provided by the modelfish unit at the Norwegian University of Life Science and was supplemented with 0.55 g/L Instant Ocean sea salt, 0.053 g/L Sodium Bicarbonate and 0.015 g/L Calcium Chloride. The tanks were housed in a water-system with a controlled temperature (20C) and with a cycle consisting of 14 h of light and 10 h of darkness. Thefish were closely monitored, and the animal's health recorded twice a day. Moribundfish that clearly showed deviant behavior and clinical symptoms not consistent with good animal welfare (greatly reduced level of activity, response to environment and appetite), were euthanized with an overdose of 250 mg/mL tricaine methanesulfonate (MS-222, Sigma Aldrich). Water parameters were monitored every third day using commercial test kits (TetraTest kit): pH, NO2, NO32, NH3/NH4þand water hardness. All zebrafish experiment was approved by NARA (The Norwegian Animal Research Authority) and waste water decontaminated by chlorination and tested for sterility before disposal.

(3)

2.4. MV immunization and P. salmonis challenge in zebraﬁsh

For the immunization experiment 65 ﬁsh per group were anesthetized by immersion in water containing 100 mg/mL tricaine methanesulfonate buffered with bicarbonate to pH 7e7.5 and immunized once with either 20 mg MV in phosphate buffer or phosphate buffer pH 6 by i.p. injection, using a 27 g needle[45,49].

After injection, the fish were immediately returned to recovery tanks. Immunized and controlfish were held in static 15 L poly- carbonate tanks (Pentair), with groups of up to 35fish per tank, in which 50% of the water was manually changed daily. Fish that did not resume normal behavior after the injections were removed from the experiment and euthanized with an overdose of 250 mg/

mL tricaine methanesulfonate. Theﬁsh were challenge by i.p. injection after an immunization period of 28 days with a lethal dose of 10^8 CFUP. salmonis. The challenge dose selected for the vaccine experiment was chosen according our dose-response results and as described in the literature[46,50]. Blood and organ sampling was performed at 24 h, 14 and 28 days' post immunization (dpi) and at 24 h, 3, 7 and 28 days' post challenge (dpc). Fish for histology was sampled at 28 days' post-immunization and 3 and 7 days' post- challenge.

2.5. Histology

For histological preparation, two randomly chosenfish from each experimental group were sacrificed by an overdose of tricaine methanesulfonate (250 mg/mL) after selected time points. The tail was removed to facilitate infiltration before thefish were transferred to glass bottles containingfixing solution (60% methanol, 30% chloroform and 10% acetic acid) and stored at 4C. The pre- fixedfish was dehydrated in a graded ethanol series at 70%, 80%, 90%, 95% and 3 100% for 60 min at room temperature with 100 rpm on a rotating table. The ethanol was then replaced with Preparation Solution (Technovit^®7100 with hardener I, according to manufacturer protocol Heraeus Kulzer Technique) and incubated on a rotating table at room temperature for two days. Fish were then transferred to separate silicone moulds and 50mL hardener II/

mL Preparation Solution was mixed and added toﬁll the moulds.

The resin was left to harden at room temperature for 1e2 h before samples were incubated over night at 37C. Technovit Universal Liquid was mixed with Technovit 3040 (Heraeus Kulzer Technique) according to manufacturer protocol and poured into the Histoblock placed on top of each sample and allowed to harden for 15 min before the samples were taken out of the moulds. Sectioning to a section thickness of 3 mm was performed with a Leica RM2245 microtome before sections were transferred to a water bath and placed upon glass slides (TC 65 Leica disposal blades). The sections were dried at 50C on a HP-3 kunz instruments heating plate before staining using hematoxylin, Schiff's reagent and an Indirect Fluorescent Antibody Test (IFAT) (SRS-Fluorotest indirect, BiosChile S.A). For the hematoxylin and Schiff's reagent staining, the samples were washed in tap water for 1 min, incubated in 1% Periodic acid (Merck Millipore) for 10 min at room temperature. Washed 3 times in MQ water for 1 min, incubated in the dark at room temperature for 20 min with Shiffs's reagent (Merck Millipore) and washed in running tap water for 10 min. The samples were then stained with hematoxylin (Merck Millipore) for 14 min at room temperature, washed in running tap water for 10 min and in MQ water for 1 min in before left to dry at room temperature. The IFAT staining was preformed according to the manufactory's instructions. The sections were mounted with xylene and pertex before analysis using a Leicaﬂuorescent Microscope DM2500 and a Leica DFC425C camera.

Images were acquired using LAS version 4.1. Histological samples of non-infectedﬁsh were stained and used as a negative control and

P. salmonis cells from a liquid culture used as a positive control.

Selected histological samples from infectedﬁsh were also stained with only the secondary antibody to evaluate potential background noise. The number of IFAT stained bacteria was determined using Image J version 1.47 automatic particle counting of two images from each group.

2.6. RNA isolation and quantitative real-time PCR

For RNA isolation, four randomly chosenfish from each experimental group were sacrificed by an overdose of tricaine methanesulfonate (250 mg/mL) at selected time points, and kidney and spleen harvested. The organs were kept in RNAlater (Ambion) and stored at 4C until further processing. The tissue was homogenized in 600 mL with buffer RLT (supplemented in RNeasy Mini Kit, QIAGEN) using a mortar and pestle (Sigma-Aldrich), followed by passing the lysate through a blunt 20 gauge needlefitted to a small 1 mL syringe (BD). Total RNA was extracted using the QIAGEN RNeasy kit according to the manufactures instructions, including a 15 min on-column DNase treatment using an RNase-free DNase set (QIAGEN). The RNA was diluted in 30mL RNase-free H₂O (QIAGEN).

RNA quantity and quality was measured with a Picodrop spectrophotometer. Reverse transcription reaction was performed by using High Capacity RNA to cDNA kit (Applied Biosystems). Quantitative real-time PCR(RT-qPCR) was carried out for each of the sampling points for a deﬁned set of genes. These included major histocom- patibility complex II (zgc:10370), cluster of differentiation 40 (cd40), tumor necrosis factor alpha (tnfa), suppressors of cytokine signaling 3b (socs3b), immunoglobulin M (ighm), macrophage expressed gene 1, tandem duplicate 1 (mpeg1.1), myeloperoxidase expression (mpx) and the four interleukins:il1b, il6, il8 andil10.

QuantiTec bioinformatically validated primers were obtained from QIAGEN for most of the genes used; the remaining primers were obtained from Life Technologies Inc. Primers are listed inTable S1.

RT-qPCR was performed in triplicates using a Lightcycler^® 480 (Roche) as previously described [48]. 18S ribosomal RNA (zgc:158463) and Elongation factor-1 alpha (eef1a111) were used as reference genes for the normalization of the relative transcription levels of each gene. The normalized immune response data of MV injected fish was standardized against the transcription levels of phosphate buffer injectedfish prior to challenge. After challenge the immune response data for both the MV and phosphate buffer group were standardized against the transcription levels of phosphate buffer injectedfish the day before challenge.

2.7. Serum isolation

For serum isolation, four randomly chosen fish from each experimental group were sacrificed by an overdose of tricaine methanesulfonate (250 mg/mL) atselected time points, and blood harvested as previously described prior to organ harvest [51]. In short, the caudalfin was removed using a scalpel, and eachfish transferred with the wound point down, to a 0.5 mL Eppendorf tube that had been perforated with a sharp needle. The 0.5 mL tube was then placed in a new 1.5 mL tube and centrifuged at 500 rpm for 3 min, followed by re-cutting the tail in order to remove coag- ulated blood and the sample centrifuged one more time. The blood was then left to coagulate at room temperature for 1 h, followed by a 10 min centrifugation at 3000 rpm in order to separate the cells and plasma. The serum was then collected and stored at - 20C until further processing.

2.8. Immunoblot analysis of zebraﬁsh serum

Immunoblot analysis was used to detect the presence of the

(4)

heavy chain of zebrafish IgM in serum from both MV immunized and phosphate buffer injectedfish. Prior to immunoblot analysis the protein concentration of the serum samples was measured using a Picodrop spectrophotometer. The samples where then diluted to ~5m^{g of zebra}fish serum protein before a standard SDS- PAGE procedure was used[52]. Briefly, 20mL of diluted serum was separated on a 4e15% Mini-PROTEAN gel (Bio-Rad). Proteins were transferred to a nitrocellulose membrane and unbound sites were blocked with 5% dry skimmed milk in TBS-T (Tris buffered saline with 0.1% Tween-20) for a minimum of 1 h. The blots were then incubated at room temperature with 1000-fold diluted rabbit anti- CH4 zebrafish IgM (kindly given by the Dr. Julio Coll) for 24 h before three wash cycles with TBS-T. The membrane was then incubated with 5000-fold diluted anti-rabbit horseradish peroxidase- conjugated IgG (Santa Cruz) for 1 h at room temperature and washed three times with TBS-T. Finally, the bands were visualized by chemiluminescence with a Luminata Crescendo Western HRP substrate (Millipore) in a CHEMI Genius Bio Imaging System (SYNGENE). Control of protein load for western blot analysis was preformed using Ponceau S (Fig. S1).

2.9. Statistical analysis

Statistical analysis of the data sets was performed using Graphpad Prism 7 (GraphPad Software Inc., La Jolla, CA, USA).

Kaplan Meier survival curves were used for analyzing percent survival and differences between groups were deemed statistically signiﬁcant if p-value < 0.05 using Gehan-Breslow-Wilcoxon test and Log-rank test. Differences in transcription between groups were deemed statistically signiﬁcant if p < 0.05 after using unpaired two-tailed Student's t-test assuming unequal variance.

3. Results

3.1. Outer membrane vesicles protect adult zebraﬁsh challenged with Piscirickettsia salmonis

To evaluate the ability of the MVs isolated fromP. salmonisto protect zebrafish from SRS, adult zebrafish was immunized with a dose of 20m^{g MV or 20}mL phosphate buffer. Four weeks after immunization both groups were challenged withP. salmonisLF-89 of 110⁸CFU. In the MV immunized group a significantly reduced mortality was seen after challenge compared to the phosphate buffer injected group (Fig. 1A). The MV immunized group had an 84.2% survival at the end of the experiment (28 dpc), in contrast to 21.42% survival in the phosphate buffer group. However, the formation of granuloma-like structures was observed in both phosphate buffer injected and MV immunized fish at 3 and 7 dpc (Fig. 1B, III-VI). The granuloma-like structures were mainly found in the liver, located adjacent to the intestine. Pathologic processes were not found in control or immunizedfish the day before challenge, 28 dpi, suggesting that the granulomas revealed in histology sections at 3 and 7 dpc are derived from the challenge dose. The anatomy of non-infected zebrafish is shown inFig. 1B, I and II. The bacterial load after challenge was investigated by IFAT staining of histological sections (Fig. 2). Image analysis of IFAT stained sections showed that theP. salmoniswas able to migrate from the initial injection site at the peritoneum and survive within the infected fish. Fish processed for histology 3 days after challenge (dpc) displayed positive staining for the bacterium in close proximity to the intestine, near the peritoneum (Fig. 2A, I and II). The bacterial load were similar in both MV immunized and phosphate buffer injected fish at 3 dpc (Fig. 2B). Analysis of histology section 7 dpc, did however, display a difference in bacterial load between the MV and phosphate buffer group, based on the IFAT staining (Fig. 2A, III and

IV). The majority of the bacterium were in both cases still strongly associated with organs in close proximity to the intestine, but a larger number of bacterium were positive for the IFAT staining in the phosphate buffer injectedﬁsh compared to the MV immunized ﬁsh at 7 dpc (Fig. 2B).

3.2. Immune gene response upon vaccination with P. salmonis membrane vesicles

When investigating the immune gene response, the main al- terations in the gene transcription levels were observed in kidney, while the transcription level was in general lower in spleen for the genes investigated. However, both kidney and spleen transcription levels of the pro-inflammatory cytokine il6 were significantly higher in the phosphate buffer injectedfish compared to the MVs immunizedfish at 3 and 7 dpc (Fig. 3). The MV immunizedfish, on the other hand, had a significant upregulation ofil6at 1, 14 and 28 dpi in spleen, and at 1 dpi in kidney compared to the phosphate buffer injected fish. The anti-inflammatory cytokine il10 was upregulated at 1 and 3 dpc in kidney of phosphate buffer injected fish, and at day 14 dpi and day 1 dpc in spleen of MV immunized fish. A similar il1b transcription response were shown in both phosphate buffer injected and MV immunizedfish after challenge, but a significant upregulation was seen at 1dpi in kidney and at 3 dpi in spleen for the MV immunizedfish. In spleen, only a minor but significant upregulation oftnfawas observed at 14 dpi for the MV immunizedfish. The transcription level oftnfawas, on the other hand, increased in kidney for both groups. For the MV immunized fish tnfa was upregulated at all time points except 1 dpi, and significantly higher than the phosphate buffer injectedfish at 14 and 28 dpi, in addition to 3 dpc. At 7 and 28 dpc thetnfatran- scription level was significantly higher in phosphate buffer injected fish. Thempeg1.1 transcription levels in the spleen were, as with tnfa,low for both groups through the experiment. Interestingly the MV immunizedfish had a significantly higher transcription level of mpeg1.1in kidney at all time points compared to the phosphate buffer injectedfish. The transcription level ofmpeg1.1in the kidney of phosphate buffer injectedfish was in general shown to be low through the experiment, and only a small upregulation was observed after infection. No significant difference was observed in either kidney or spleen for the remaining genes analyzed (il8,ighm, mpx,socs3b, cd40andzgc:10370). Thet-test results of immune gene transcription between phosphate injected and MV immunizedfish before and after challenge are shown inTable S1.

3.3. Detection of zebraﬁsh immunoglobulin M in serum

In order to study the humoral response againstP. salmonis,a polyclonal rabbit antibody against the zebrafish IgM heavy chain was used to detect the corresponding IgM in serum from zebrafish at different time points (Fig. 4). The antibody confirmed the presence of IgM by immunoblot analysis in pooled serum from zebrafish (n¼4) both before or after challenge. Based on this analysis, there is an increased IgM secretion in the MV immunized fish compared to the phosphate buffer injectedfish at 1, 14 and 28 dpi.

After challenge the phosphate buffer injectedfish did, on the other hand, display an increased secretion of IgM. Thus, ELISA analysis was preformed to detect the specific response againstP. salmonis (Fig. S2). Based on the ELISA analysis, no difference were observed between the two groups after immunization, but for day 1, 3 and 7 after challenge the MV immunizedfish displayed a higher degree of P. salmonisspecific IgM compared to the phosphate buffer injected fish. The difference was, however, non-apparent at 28 days after challenge. Due to welfare reasons and a limited serum volume, it is important to notice that the IgM data only represent a pool of four

(5)

ﬁsh for each time point and the analysis, is thus, restricted to a single replicate.

4. Discussion

The use of MVs for immunization against SRS has not previously been reported. In order to evaluate MVs as a potential vaccinate

candidate against P. salmonis adult zebrafish was used as an infection model. Zebrafish has over the last decades become an important model for vertebrate development, and in recent years the model of choice for studies of both infectious diseases and immunology[53,54]. Due it's to short breeding time, small size and available genetic tools, the zebrafish offers an important bridge between cell lines and higher vertebrates[55]. In the present study, Fig. 1. Adult zebrafish immunized with membrane vesicles and subsequently challenged withPiscirickettsia salmonis.(A) Cumulative survival (%) of adult zebrafish immunized with 20mg of MVs isolated from LF-89 or injected with phosphate buffer before challenged withP. salmonis110⁸CFU (n¼65). (B) Histological sections from non- infectedfish (I-II),fish injected with phosphate buffer (III-IV) andfish immunized with MVs (V-VI) at 3 and 7 days' post challenge (dpc), 10magnifications, hematoxylin and Periodic acid Schiff's staining. Int: intestines, L. liver, arrows indicate the formation of granuloma-like structures.

(6)

we show that MVs isolated from P. salmonisare able to protect zebraﬁsh from subsequent challenge with a lethal dose of the bacterium. The overall survival of the zebraﬁsh increased with

62.8% when fish were immunized with MVs compared to fish injected with phosphate buffer. Analysis of immune related genes in thefish, did however, display an increased il1bexpression in kidney and spleen samples at 1 and 14 days post immunization with MVs, respectively. Interleukin 1bis one of the most powerful pro-inflammatory cytokines and its expression is regulated together with il18 though the activation of inflammasomes, including NLRP3[56]. We have preciously shown that MVs from P. salmonisis associated with zebrafish leucocytes, thus they could potentially be taken up by macrophages during immunization of zebrafish, leading to theil1b gene expression[46]. The internalization of MVs can also trigger an immune response important for subset protection against SRS as il-1bis an important mediator of neutrophil recruitment, cytokines and chemokines induction, and the stimulation of adaptive immunity like the Th17 response[57].

However, no significant difference was observed between theil1b expression of MVs immunized and phosphate buffer injectedfish after challenge. A similar upregulation was also shown fortnfa^, having an increased gene expression at 14 and 28 dpi in the kidney of MV immunizedfish, but only a limited difference between the MV immunized and the phosphate buffer injectedfish were iden- tified at 1, 3 and 7 dpc. TNFais an important pro-inflammatory cytokine involved in both early and acquired immune response, and is secreted by activated immune cells[58]. The release of TNFa has been shown to promote increased respiratory activity, macrophage activity, phagocytosis and nitric oxide production infish[59].

Thus, an upregulation oftnfaafter immunization with MVs might promote increased macrophage activity resulting in a reduction of the bacterial infection[60].

Several of the genes investigated displayed significant difference between MV immunized and phosphate buffer injected fish, includingil10,il6andmpeg1.1. The expression ofil10was recently shown to be upregulated in a RTS-11 monocyte/macrophage cell line from Oncorhynchus mykiss upon P. salmonis infection, promoting the bacterial survival inside the cell through macrophage inactivation[61]. Furthermore, an upregulation ofil10 has been shown to promote the intracellular survival of several pathogens, including Mycobacterium tuberculosis and Francisella tularensis [62,63]. MV immunizedfish displayed a significant loweril10gene expression in kidney at 1 and 3 dpc compared tofish injected with phosphate buffer, which could indicate a reduced survival of the bacterium in the MV immunizedfish. A reduced bacterial load was also shown in MV immunizedfish compared to phosphate buffer injectedfish by histological analysis. Interleukin 10 is an important anti-inflammatory cytokine known to regulate the immune response by blocking chemokine receptors, minimizing damage caused by an excessive release of pro-inflammatory cytokines [64,65]. In the present study,il10were shown to be upregulated at 1 dpc in MV immunizedfish, followed by a decrease of the pro- inflammatory genes tnfa and il1b from 3 to 28 dpc. This could indicate a quick protective response in immunizedfish, leading to a reduction of the inflammatory response and the bacterial infection, as proposed by others [65,66]. In contrast, an increased gene expression was observed at the same time for tnfaand il1b in phosphate buffer injected fish, indicating reduced inflammatory regulation potentially caused by the bacterial infection. The gene expression ofil6was shown to be significantly higher in the kidney of phosphate buffer injectedfish at 3, 7 and 28 dpc compared to MV immunizedfish. Increased gene expression ofil6has, as withil10, been shown to promote bacterial survival inside cells, but though iron regulation[67]. Increased secretion ofil6has been reported to recruit Hepcidin, a protein known to bind to the exporter ferro- portin (Fpn), leading to the internalization and degradation of Fpn.

The loss of cell surface Fpn also leads to increased intracellular iron, particularly in macrophages that are continuously obtaining iron Fig. 2. Indirect Fluorescent Antibody Test of histological sections from adult

zebrafish immunized with membrane vesicles and subsequently challenged with Piscirickettsia salmonis. (A) Identification of P. salmonis by Indirect Fluorescent Antibody Test (IFAT; green) at 3 (I-II) and 7 dpc (III-IV). Bacterial cells positive for IFAT staining are marked with arrowhead, 100magnifications. (B) Image analysis using Image J automatic particle count of histological sections stained with IFAT at 3 and 7 dpc for quantification of the bacterial load. Results are presented as meanþ/-SD.

Asterisk indicate signiﬁcant difference in particle count p< 0.05, two tailed unpaired Student's t-test (n¼2).

(7)

Fig. 3. Immune gene transcription in adult zebraﬁsh immunized with membrane vesicles and subsequently challenged withPiscirickettsia salmonisanalyzed by RT-qPCR.

Immune gene expression of kidney and spleen isolated 1, 14 and 28 days' post immunization (dpi) and 1, 3, 7 and 28 days' post challenge (dpc) fromﬁsh immunized with either 20mg OMVs isolated from LF-89 or injected with phosphate buffer (control) and challenged withP. salmonis110⁸CFU. Results are presented as meanþ/-SD. Asterisk indicate signiﬁcantly upregulated genes compared to the non-challenged control p<0.05, two tailed unpaired Student's t-test (n¼4).

(8)

from senescent red blood cells[68]. Iron acquisition has, furthermore, been shown to be important for the intercellular growth and survival ofP. salmonis, and studies of infected Atlantic salmon reported an increased resistance to SRS in ﬁsh able to limit iron availability to the bacterium [69,70]. Thus, a decreased gene expression ofil6in MV immunizedﬁsh could limit the bacterium's iron availability, thereby also limiting the infection.

Interestingly the biggest difference in gene expression level between phosphate buffer injected and MV immunizedfish was observed formpeg1.1, being significantly higher in the MV immunized fish at all time points investigated. Mpeg is in general considered an important macrophage marker in zebrafish, used for bothfluorescent labeling and gene expression studies[71,72]. The mpeg1.1 gene encodes a perforin-like protein, suggested to be a pore-forming protein involved in the clearance of intracellular pathogens by promoting the phagosome-lysosome fusion[73]. The Mpeg1.1 protein has also been shown to have antimicrobial activity in zebrafish, andmpeg1.1knock down zebrafish mutants reported to display increased bacterial burden upon challenge withMyco- bacterium marinum[74]. Thus, an upregulation of thempeg1.1gene in MV immunizedfish indicates an increased macrophage response to both the MVs and the bacterium. In contrast, a low expression of thempeg1.1gene in phosphate buffer injectedfish upon challenge might be a result of the bacterium's intracellular lifestyle, avoiding the phagosome-lysosome fusion. Moreover, zebrafish infected with M. marinumhave been shown to display a decreased expression of mpeg1.1, indicating that thempeg1.1gene expression levels could be affected by bacterial infections[74,75]. However, as the infection mechanism of P. salmonisis yet to be fully investigated, further studies are needed to confirm the indications given by the immune gene expression observed in zebrafish upon immunization and challenge. The immune gene expression in combination with the histology data, do however, indicate a reduced degree ofP. salmonis infection in zebrafish after immunization with MVs as compared to fish injected with phosphate buffer.

Moreover, serum analysis from the fish did show an IgM response to both the MV immunization and the subsequent challenge. IgM is in general considered as thefirst line of defense during microbial infections as well as thefirst antibody produced upon immunization in mammals[76]. IgM has been recognized as an important antibody in the teleost immune system, being the most ancient and only isotype conserved in all jawed vertebrates. IgM is

manly found in teleost blood and serum, and are in adultfish the dominant isotype expressed by both primary and secondary lymphoid organs [77e79]. A specific immune response upon vaccination or challenge can also be measured based on the IgM response infish, and IgM antibody titers has been shown to increase significantly following immersion vaccination against enteric redmouth disease[79,80]. Thus, the specific IgM production againstP. salmonisdetected by ELISA analysis of serum fromfish immunized with MVs might indicate a protective effect induced by the vesicles. However, asP. salmonisis an intracellular pathogen, and IgM a part of the humoral immune system, it can be discussed to what degree IgM promotes a protective effect[78]. Nonetheless, it has been shown that IgM might be an important factor in vaccination in mammals, and that the synergy between antibodies, cytokines and phagocytes are an important part in clearing bacterial infections [76,81]. Due to the miniscule amount of serum possible to obtain from zebrafish it is important to notice that the ELISA data is based on one replicate only and it would be of high interest to evaluate the response in a salmon host.

In the present study, several immunological components were shown to be activated upon immunization with MV derived from P. salmonis, indicating a potential use of bacterial derived vesicles for vaccination in aquaculture. It has previously been described that adult zebrafish is susceptible toP. salmonisouter membrane vesicles [46]. However, as P. salmonis is an intracellular pathogen, residing within the host's immune cells upon infection, the bacterium has a limited availability for antibody recognition by the immune system[82]. Thus, vaccination can be problematic as is relies on memory T-cells, which upon encounters with specific antigens will activate a defense system[83]. The activation of memory T- cells was not investigated in the present study, and will be interesting to examine in the future. However, asP. salmonisMVs has been shown to be internalized by leukocytes and in many ways is a small non-replicating copy of the bacteria, they could mimic a natural infection upon immunization[46]. Thus, MVs represents an interesting alternative for immunization against SRS, potentially activating the antibody- and cellular-mediated immune system. As P. salmonishas been shown to secret MVs when residing inside cells, the vesicles could potentially be broken down and represented by the cell though MHC class I. Thus, successful immunization using MVs could lead to a CD8^þT cell mediated destruction of the P. salmonis infected cells [22, 84, 85]. However, further Fig. 4. IgM secretion in zebrafish immunized with membrane vesicles and subsequently challenged withPiscirickettsia salmonis.Detection of zebrafish IgM in serum of zebrafish immunized with 20mg of MVs isolated from LF-89 or injected with phosphate buffer (PB) before challenged withP. salmonis110⁸CFU at 1, 14 and 28 days' post immunization (dpi) and 1, 3, 7 and 28 days' post challenge (dpc).Immunoblot analysis of IgM heavy chain (84e86 kDa), M: molecular weight marker in kilo Daltons (kDa).

(9)

studies are needed to evaluate the vaccine potential of the MVs and their mechanism of action. AsP. salmonismainly infect salmon, the protective effect should also be investigated using the bacterium's natural host.

5. Conclusion

In summary, MV isolated fromP. salmoniswas shown to induce a protective effect against SRS in an adult zebraﬁsh infection model, and several immune related genes were upregulates after immunization. Thus, MVs for vaccination represents an interesting candidate for immunization againstP. salmonis.

Ethics statement

All animal experiments were approved by the Norwegian Ani- mal Research Authority, approval no. 16/36352, FOTS ID 8507 and treated according to institutional guidelines.

Contributors

JIT planned and preformed most of the experiments and participated in the writing of the paper. MG planned and preformed some of the experiments. CO and LL planned and preformed some of the experiments and participated in the writing of the paper. AJY, ER and HCWL planned some of the experiments and participated in writing of the paper. All authors have approved the ﬁnal manuscript.

Acknowledgement

The work wasﬁnancially supported by the University of Oslo (JIT, LL, MG and HCWL), Universidad Austral de Chile (AJY and CO), The Research Council of Norway; Biotek2021 Program Grant no#

233849 (JIT, LL and HWL) and Havbruksprogrammet Program Grant no# 268201 (JIT, HCWL, AJY and CO), Fondecyt Postdoctoral Grant no# 3160849 (CO) and Interdisciplinary Center for Aquaculture Research (INCAR) Grants CONICYT/FONDAP no# 15110027 (CO and AJY), and DID-UACh from Universidad Austral de Chile, and The Norwegian PhD school of Pharmacy travel grant (JIT) whom we express our gratitude. We thank Dr. J. M. Coll (SIGT-INIA, Depart- ment of Biotechnology, Madrid, Spain) for providing us with the antibody against IgM for zebrafish, Petter Langlete (School of Pharmacy, University of Oslo, Oslo, Norway) for assisting with the zebrafish injections and Ana CS Tevara (Department of Production Animal Clinical Sciences, Norwegian University of Life Sciences, Oslo, Norway) for help with zebrafish supply and housing.

Appendix A. Supplementary data

Supplementary data related to this article can be found athttp://

dx.doi.org/10.1016/j.fsi.2017.06.015.

References

[1] S. Bravo, Environmental impacts and management of veterinary medicines in aquaculture: the case of salmon aquaculture in Chile, Improv. Biosecurity Through Prudent Responsible Use Veterinary Med. Aquatic Food Prod. (2012) 11.

[2] J. Mikalsen, O. Skjærvik, J. Wiik-Nielsen, M.A. Wasmuth, D.J. Colquhoun, Agar culture ofPiscirickettsia salmonis, a serious pathogen of farmed salmonid and marineﬁsh, FEMS Microbiol. Lett. 278 (1) (2008) 43e47.

[3] A.G. Murray, E.J. Peeler, A framework for understanding the potential for emerging diseases in aquaculture, Prev. Veterinary Med. 67 (2e3) (2005) 223e235.

[4] K. Maisey, R. Montero, M. Christodoulides, Vaccines for Piscirickettsiosis (salmonid rickettsial septicaemia, SRS): the Chile perspective, Expert Rev.

vaccines 16 (3) (2016) 215e228.

[5] J.L. Fryer, C.N. Lannan, S.J. Giovannoni, N.D. Wood,Piscirickettsia salmonis gen.

nov., sp. nov., the causative agent of an epizootic disease in salmonidﬁshes, Int. J. Syst. Bacteriol. 42 (1) (1992) 120e126.

[6] J.L. Fryer, R.P. Hedrick,Piscirickettsia salmonis: a Gram-negative intracellular bacterial pathogen ofﬁsh, J.ﬁsh Dis. 26 (5) (2003) 251e262.

[7] M.J. Mauel, D.L. Miller, Piscirickettsiosis and piscirickettsiosis-like infections in ﬁsh: a review, Veterinary Microbiol. 87 (4) (2002) 279e289.

[8] U.M. McCarthy, J.E. Bron, L. Brown, F. Pourahmad, I.R. Bricknell, K.D. Thompson, et al., Survival and replication ofPiscirickettsia salmonisin rainbow trout head kidney macrophages, Fish. Shellﬁsh Immunol. 25 (5) (2008) 477e484.

[9] J.L. Fryer, C.N. Lannan, Rickettsial infections ofﬁsh, Annu. Rev. Fish Dis. 6 (1996) 3e13.

[10] M. Rozas, R. Enríquez, Piscirickettsiosis andPiscirickettsia salmonisinﬁsh: a review, J.ﬁsh Dis. 37 (3) (2014) 163e188.

[11] S. Bravo, P.J. Midtlyng, The use ofﬁsh vaccines in the Chilean salmon industry 1999-2003, Aquaculture 270 (1e4) (2007) 36e42.

[12] P.A. Smith, J.R. Contreras, J.J. Larenas, J.C. Aguillon, L.H. Garces, B. Perez, et al., Immunization with bacterial antigens: piscirickettsiosis, Dev. Biol. Stand. 90 (1997) 161e166.

[13] I. Sommerset, B. Krossøy, E. Biering, P. Frost, Vaccines forﬁsh in aquaculture, Expert Rev. Vaccines 4 (1) (2005) 89e101.

[14] R. Gudding, A. Lillehaug, O. Evensen, Recent developments inﬁsh vaccinology, Veterinary Immunol. Immunopathol. 72 (1e2) (1999) 203e212.

[15] P. Henríquez, H. Bohle, F. Bustamante, P. Bustos, M. Mancilla, Polymorphism in gyrA is associated to quinolones resistance in ChileanPiscirickettsia salmonis ﬁeld isolates, J.ﬁsh Dis. 38 (4) (2015) 415e418.

[16] A.J. Yanez, K. Valenzuela, C. Matzner, V. Olavarria, J. Figueroa, R. Avendano- Herrera, et al., Broth microdilution protocol for minimum inhibitory concentration (MIC) determinations of the intracellular salmonid pathogenPis- cirickettsia salmonistoﬂorfenicol and oxytetracycline, J.ﬁsh Dis. 37 (5) (2014) 505e509.

[17] R. Sandoval, C. Oliver, S. Valdivia, K. Valenzuela, R.E. Haro, P. Sanchez, et al., Resistance-nodulation-division efflux pump acrAB is modulated byflorfenicol and contributes to drug resistance in thefish pathogenPiscirickettsia salmonis, FEMS Microbiol. Lett. (11) (2016) 363.

[18] R. Ramirez, F.A. Gomez, S.H. Marshall, The infection process ofPiscirickettsia salmonisinﬁsh macrophages is dependent upon interaction with host-cell clathrin and actin, FEMS Microbiol. Lett. 362 (1) (2015) 1e8.

[19] V. Rojas, N. Galanti, N.C. Bols, S.H. Marshall, Productive infection ofPiscirick- ettsia salmonisin macrophages and monocyte-like cells from rainbow trout, a possible survival strategy, J. Cell. Biochem. 108 (3) (2009) 631e637.

[20] V. Rojas, N. Galanti, N.C. Bols, V. Jimenez, R. Paredes, S.H. Marshall,Piscirick- ettsia salmonisinduces apoptosis in macrophages and monocyte-like cells from rainbow trout, J. Cell. Biochem. 110 (2) (2010) 468e476.

[21] R.W. Titball, Vaccines against intracellular bacterial pathogens, Drug Discov.

today 13 (13e14) (2008) 596e600.

[22] R.A. Seder, A.V.S. Hill, Vaccines against intracellular infections requiring cellular immunity, Nature 406 (6797) (2000) 793e798.

[23] A. Detmer, J. Glenting, Live bacterial vaccinesea review and identiﬁcation of potential hazards, Microb. Cell Factories 5 (1) (2006) 1.

[24] C.A. Shoemaker, P.H. Klesius, J.J. Evans, C.R. Arias, Use of modiﬁed live vaccines in aquaculture, J. World Aquac. Soc. 40 (5) (2009) 573e585.

[25] T.N. Ellis, M.J. Kuehn, Virulence and immunomodulatory roles of bacterial outer membrane vesicles, Microbiol. Mol. Biol. Rev. 74 (1) (2010) 81e94.

[26] A. Kulp, M.J. Kuehn, Biological functions and biogenesis of secreted bacterial outer membrane vesicles, Annu. Rev. Microbiol. 64 (2010) 163e184.

[27] C. Perez-Cruz, L. Delgado, C. Lopez-Iglesias, E. Mercade, Outer-inner membrane vesicles naturally secreted by Gram-negative pathogenic bacteria, PLoS One 10 (1) (2015) e0116896.

[28] S.R. Schooling, T.J. Beveridge, Membrane vesicles: an overlooked component of the matrices of bioﬁlms, J. Bacteriol. 188 (16) (2006) 5945e5957.

[29] A.J. McBroom, M.J. Kuehn, Release of outer membrane vesicles by Gram- negative bacteria is a novel envelope stress response, Mol. Microbiol. 63 (2) (2007) 545e558.

[30] N.C. Kesty, K.M. Mason, M. Reedy, S.E. Miller, M.J. Kuehn, Enterotoxigenic Escherichia colivesicles target toxin delivery into mammalian cells, EMBO J. 23 (23) (2004) 4538e4549.

[31] L. Mashburn-Warren, J. Howe, P. Garidel, W. Richter, F. Steiniger, M. Roessle, et al., Interaction of quorum signals with outer membrane lipids: insights into prokaryotic membrane vesicle formation, Mol. Microbiol. 69 (2) (2008) 491e502.

[32] M.J. Kuehn, N.C. Kesty, Bacterial outer membrane vesicles and the hostepathogen interaction, Genes&Dev. 19 (22) (2005) 2645e2655.

[33] E.-Y. Lee, D.-S. Choi, K.-P. Kim, Y.S. Gho, Proteomics in Gram-negative bacterial outer membrane vesicles, Mass Spectrom. Rev. 27 (6) (2008) 535e555.

[34] T. Pierson, D. Matrakas, Y.U. Taylor, G. Manyam, V.N. Morozov, W. Zhou, et al., Proteomic characterization and functional analysis of outer membrane vesicles ofFrancisella novicidasuggests possible role in virulence and use as a vaccine, J. Proteome Res. 10 (3) (2011) 954e967.

[35] M. Kaparakis-Liaskos, R.L. Ferrero, Immune modulation by bacterial outer membrane vesicles, Nat. Rev. Immunol. 15 (6) (2015) 375e387.

[36] A.L. Horstman, M.J. Kuehn, EnterotoxigenicEscherichia colisecretes active heat-labile enterotoxin via outer membrane vesicles, J. Biol. Chem. 275 (17) (2000) 12489e12496.

(10)

[37] D. Chatterjee, K. Chaudhuri, Association of cholera toxin withVibrio cholerae outer membrane vesicles which are internalized by human intestinal epithelial cells, FEBS Lett. 585 (9) (2011) 1357e1362.

[38] H. Alzahrani, J. Winter, D. Boocock, L. De Girolamo, S.J. Forsythe, Character- ization of outer membrane vesicles from a neonatal meningitic strain of Cronobacter sakazakii, FEMS Microbiol. Lett. 362 (12) (2015) fnv085.

[39] L. Danzig,Meningococcal vaccines, Pediatr. Infect. Dis. J. 23 (12) (2004).

S285eS92.

[40] D.M. Granoff, Review of Meningococcal group B vaccines, Clin. Infect. Dis.

Ofﬁcial Publ. Infect. Dis. Soc. Am. 50 (S2) (2010) S54.

[41] J. Holst, P. Oster, R. Arnold, M.V. Tatley, L.M. Naess, I.S. Aaberge, et al., Vaccines against meningococcal serogroup B disease containing outer membrane vesicles (OMV): lessons from past programs and implications for the future, Hum. Vaccines Immunother. 9 (6) (2013) 1241e1253.

[42] B.S. Collins, Gram-negative outer membrane vesicles in vaccine development, Discov. Med. 12 (62) (2011) 7e15.

[43] S.B. Park, H.B. Jang, S.W. Nho, I.S. Cha, J. Hikima, M. Ohtani, et al., Outer membrane vesicles as a candidate vaccine against edwardsiellosis, PloS One 6 (3) (2011) e17629.

[44] M. Aoki, M. Kondo, Y. Nakatsuka, K. Kawai, S.-I. Oshima, Stationary phase culture supernatant containing membrane vesicles induced immunity to rainbow troutOncorhynchus mykissfry syndrome, Vaccine 25 (3) (2007) 561e569.

[45] E. Brudal, E.O. Lampe, L. Reubsaet, N. Roos, I.K. Hegna, I.M. Thrane, et al., Vaccination with outer membrane vesicles fromFrancisella noatunensisre- duces development of francisellosis in a zebraﬁsh model, Fish shellﬁsh Immunol. 42 (1) (2015) 50e57.

[46] J.I. Tandberg, L.X. Lagos, P. Langlete, E. Berger, A.L. Rishovd, N. Roos, et al., Comparative analysis of membrane vesicles from threePiscirickettsia salmonis isolates reveals differences in vesicle characteristics, PLoS One 11 (10) (2016) e0165099.

[47] C. Oliver, K. Valenzuela, M. Hernandez, R. Sandoval, R.E. Haro, R. Avenda~no- Herrera, et al., Characterization and pathogenic role of outer membrane vesicles produced by theﬁsh pathogenPiscirickettsia salmonisunder in vitro conditions, Veterinary Microbiol. 184 (2016) 94e101.

[48] E. Brudal, L.S. Ulanova, O.L. E, A.L. Rishovd, G. Grifﬁths, H.C. Winther-Larsen, Establishment of three Francisella infections in zebraﬁsh embryos at different temperatures, Infect. Immun. 82 (6) (2014) 2180e2194.

[49] C.L. Cosma, L.E. Swaim, H. Volkman, L. Ramakrishnan, J.M. Davis, Zebraﬁsh and frog models ofMycobacterium marinuminfection, Curr. Protoc. Microbiol. 3 (10B.2) (2006), 10B.2.1e10B.2.33.

[50] L.N. Vojtech, G.E. Sanders, C. Conway, V. Ostland, J.D. Hansen, Host immune response and acute disease in a zebraﬁsh model of Francisella pathogenesis, Infect. Immun. 77 (2) (2009) 914e925.

[51] F. Babaei, R. Ramalingam, A. Tavendale, Y. Liang, L.S.K. Yan, P. Ajuh, et al., Novel blood collection method allows plasma proteome analysis from single zebraﬁsh, J. Proteome Res. 12 (4) (2013) 1580e1590.

[52] U.K. Laemmli, Cleavage of structural proteins during the assembly of the head of bacteriophage T4, Nature 227 (5259) (1970) 680e685.

[53] S.A. Renshaw, N.S. Trede, A model 450 million years in the making: zebraﬁsh and vertebrate immunity, Dis. Models Mech. 5 (1) (2012) 38e47.

[54] C.I.M. Fenero, A.A.C. Flores, N.O.S. Câmara, Inflammatory diseases modelling in zebrafish, World J. Exp. Med. 6 (1) (2016) 9.

[55] A.M. van der Sar, B.J. Appelmelk, C.M.J.E. Vandenbroucke-Grauls, W. Bitter, A star with stripes: zebraﬁsh as an infection model, Trends Microbiol. 12 (10) (2004) 451e457.

[56] M. Sahoo, I. Ceballos-Olvera, L. del Barrio, F. Re, Role of the inﬂammasome, IL- 1b, and IL-18 in bacterial infections, TheScientiﬁcWorldJournal 11 (2011) 2037e2050.

[57] M.G. Netea, A. Simon, F. van de Veerdonk, B.-J. Kullberg, J.W.M. Van der Meer, L.A.B. Joosten, IL-1bprocessing in host defense: beyond the inﬂammasomes, PLoS Pathog. 6 (2) (2010) e1000661.

[58] M.M. Rahman, G. McFadden, Modulation of tumor necrosis factor by microbial pathogens, PLoS Pathog. 2 (2) (2006) e4.

[59] C. Uribe, H. Folch, R. Enriquez, G. Moran, Innate and adaptive immunity in teleostﬁsh: a review, Veterinarni Med. 56 (10) (2011) 486e503.

[60] S.K. Whyte, The innate immune response of finfishea review of current knowledge, Fish Shellfish Immunol. 23 (6) (2007) 1127e1151.

[61] C.A.Alvarez, F.A. Gomez, L. Mercado, R. Ramírez, S.H. Marshall, Piscirickettsia salmonisimbalances the innate immune response to succeed in a productive infection in a salmonid cell line model, PLoS One 11 (10) (2016) e0163943.

[62] G.L. Beamer, D.K. Flaherty, B.D. Assogba, P. Stromberg, M. Gonzalez-Juarrero, R. de Waal Malefyt, et al., Interleukin-10 promotesMycobacterium tuberculosis disease progression in CBA/J mice, J. Immunol. Baltim. Md 1950) 181 (8)

(2008) 5545e5550.

[63] D. Hunt, J.E. Wilson, K.A. Weih, S. Ishido, J.A. Harton, P.A. Roche, et al.,Fran- cisella tularensiselicits IL-10 via a PGE(2)-inducible factor, to drive macrophage MARCH1 expression and class II down-regulation, PloS One 7 (5) (2012) e37330.

[64] G. D'amico, G. Frascaroli, G. Bianchi, P. Transidico, A. Doni, A. Vecchi, et al., Uncoupling of inﬂammatory chemokine receptors by IL-10: generation of functional decoys, Nat. Immunol. 1 (5) (2000) 387e391.

[65] M.K. Raida, K. Buchmann, Development of adaptive immunity in rainbow trout,Oncorhynchus mykiss(Walbaum) surviving an infection withYersinia ruckeri, Fish Shellﬁsh Immunol. 25 (5) (2008) 533e541.

[66] N.O. Harun, T. Wang, C.J. Secombes, Gene expression proﬁling in naïve and vaccinated rainbow trout afterYersinia ruckeri infection: insights into the mechanisms of protection seen in vaccinatedﬁsh, Vaccine 29 (26) (2011) 4388e4399.

[67] B.J. Cherayil, The role of iron in the immune response to bacterial infection, Immunol. Res. 50 (1) (2011) 1e9.

[68] P.N. Paradkar, I. De Domenico, N. Durchfort, I. Zohn, J. Kaplan, D.M. Ward, Iron depletion limits intracellular bacterial growth in macrophages, Blood 112 (3) (2008) 866e874.

[69] A. Machuca, V. Martinez, Transcriptome analysis of the intracellular facultative pathogenPiscirickettsia salmonis: expression of putative groups of genes associated with virulence and iron metabolism, PLoS One 11 (12) (2016) e0168855.

[70] R. Pulgar, C. H€odar, D. Travisany, A. Zu~niga, C. Domínguez, A. Maass, et al., Transcriptional response of Atlantic salmon families toPiscirickettsia salmonis infection highlights the relevance of the iron-deprivation defence system, BMC Genomics 16 (1) (2015) 495.

[71] F. Ellett, L. Pase, J.W. Hayman, A. Andrianopoulos, G.J. Lieschke, mpeg1 promoter transgenes direct macrophage-lineage expression in zebraﬁsh, Blood 117 (4) (2011) e49.

[72] A. Zakrzewska, C. Cui, O.W. Stockhammer, E.L. Benard, H.P. Spaink, A.H. Meijer, Macrophage-speciﬁc gene functions in Spi1-directed innate immunity, Blood 116 (3) (2010) e1.

[73] R. McCormack, L.R. de Armas, M. Shiratsuchi, J. Ramos, E.R. Podack, Inhibition of intracellular bacterial replication in ﬁbroblasts is dependent on the perforin-like protein (Perforin-2) encoded by macrophage expressed gene 1, J. Innate Immun. 5 (2) (2013) 185e194.

[74] E.L. Benard, P.I. Racz, J. Rougeot, A.E. Nezhinsky, F.J. Verbeek, H.P. Spaink, et al., Macrophage-expressed perforins Mpeg1 and Mpeg1.2 have an anti-bacterial function in zebraﬁsh, J. Innate Immun. 7 (2) (2015) 136e152.

[75] E.M. Walton, M.R. Cronan, R.W. Beerman, D.M. Tobin, The macrophage- speciﬁc promoter mfap4 allows live, long-term analysis of macrophage behavior during mycobacterial infection in zebraﬁsh, PLoS One 10 (10) (2015) e0138949.

[76] R. Racine, G.M. Winslow, IgM in microbial infections: taken for granted?

Immunol. Lett. 125 (2) (2009) 79e85.

[77] J.O. Sunyer, Fishing for mammalian paradigms in the teleost immune system, Nat. Immunol. 14 (4) (2013) 320e326.

[78] S.T. Solem, J. Stenvik, Antibody repertoire development in teleostsda review with emphasis on salmonids and Gadus morhua L, Dev. Comp. Immunol. 30 (1e2) (2006) 57e76.

[79] C. Secombes, T. Wang, The innate and adaptive immune system ofﬁsh, In- fectious disease in Aquaculture: Prev. Control 231 (2012) 3e68.

[80] M.K. Raida, J. Nylen, L. Holten-Andersen, K. Buchmann, Association between plasma antibody response and protection in rainbow trout Oncorhynchus mykissimmersion vaccinated against Yersinia ruckeri, PLoS One 6 (6) (2011) e18832.

[81] G.S. Kirimanjeswara, S. Olmos, C.S. Bakshi, D.W. Metzger, Humoral and cell- mediated immunity to the intracellular pathogen Francisella tularensis, Immunol. Rev. 225 (2008) 244e255.

[82] A. Casadevall, Antibody-mediated immunity against intracellular pathogens:

two-dimensional thinking comes full circle, Infect. Immun. 71 (8) (2003) 4225e4228.

[83] M.T. Esser, R.D. Marchese, L.S. Kierstead, L.G. Tussey, F. Wang, N. Chirmule, et al., Memory T cells and vaccines, Vaccine 21 (5e6) (2003) 419e430.

[84] P.K. Giri, J.S. Schorey, Exosomes derived from M. Bovis BCG infected macrophages activate Antigen-speciﬁc CD4(þ) and CD8(þ) T cells in vitro and in Vivo, PLoS One 3 (6) (2008) e2461.

[85] K. Vanaja Sivapriya, J. Russo Ashley, B. Behl, I. Banerjee, M. Yankova, D. Deshmukh Sachin, et al., Bacterial outer membrane vesicles mediate cytosolic localization of LPS and Caspase-11 activation, Cell 165 (5) (2016) 1106e1119.
