ORIGINAL ARTICLE

The Effect of Exercise Training in Improving Motor

Performance and Corticomotor Excitability in People With Early Parkinson’s Disease

Beth E. Fisher, PhD, Allan D. Wu, MD, George J. Salem, PhD, Jooeun Song, MS, Chien-Ho (Janice) Lin, PhD, Jeanine Yip, DPT, Steven Cen, PhD, James Gordon, EdD, Michael Jakowec, PhD, Giselle Petzinger, MD

ABSTRACT. Fisher BE, Wu AD, Salem GJ, Song J, Lin C-H, Yip J, Cen S, Gordon J, Jakowec M, Petzinger G. The effect of exercise training in improving motor performance and corticomotor excitability in people with early Parkinson’s disease. Arch Phys Med Rehabil 2008;89:1221-9.

Objectives: To obtain preliminary data on the effects of high-intensity exercise on functional performance in people with Parkinson’s disease (PD) relative to exercise at low and no intensity and to determine whether improved performance is accompanied by alterations in corticomotor excitability as measured through transcranial magnetic stimulation (TMS).

Design: Cohort (prospective), randomized controlled trial.

Setting: University-based clinical and research facilities.

Participants: Thirty people with PD, within 3 years of diagnosis with Hoehn and Yahr stage 1 or 2.

Interventions: Subjects were randomized to high-intensity exercise using body weight–supported treadmill training, low- intensity exercise, or a zero-intensity education group. Subjects in the 2 exercise groups completed 24 exercise sessions over 8 weeks. Subjects in the zero-intensity group completed 6 education classes over 8 weeks.

Main Outcome Measures: Unified Parkinson’s Disease Rating Scales (UPDRS), biomechanic analysis of self-selected and fast walking and sit-to-stand tasks; corticomotor excitability was assessed with cortical silent period (CSP) durations in response to single-pulse TMS.

Results: A small improvement in total and motor UPDRS was observed in all groups. High-intensity group subjects showed postexercise increases in gait speed, step and stride length, and hip and ankle joint excursion during self-selected and fast gait and improved weight distribution during sit-to- stand tasks. Improvements in gait and sit-to-stand measures

were not consistently observed in low- and zero-intensity groups. The high-intensity group showed lengthening in CSP.

Conclusions: The findings suggest the dose-dependent ben- efits of exercise and that high-intensity exercise can normalize corticomotor excitability in early PD.

Key Words: Basal ganglia; Central nervous system; Neu- ronal plasticity; Rehabilitation; Walking.

B

OTH BASIC RESEARCH and clinical studies suggest that high intensity (ie, high repetition, velocity, complexity) is a characteristic of exercise that may be important in promoting activity-dependent neuroplasticity of the injured brain, including the basal ganglia.^1,2Activity-dependent neuroplasticity is defined as alterations within the CNS in response to physical activity that include such processes as neurogenesis, synaptogenesis, and molecular adaptations.³BWSTT is currently being studied as a treatment modality for promoting activity-dependent neuroplasticity and functional recovery in stroke and spinal cord injury in part because it can be used to manipulate intensity of practice.

In the last 7 years, there have been an increasing number of studies^4-10that have examined the effect of treadmill exercise on PD, a debilitating and progressive neurodegenerative disease, characterized by motor slowness, stiffness, tremor, and balance dysfunction.^11,12Improved motor performance has been reported and treadmill speeds have gradually increased from studies^4,6in which subjects trained at self-selected velocities for comfort to speeds above overground walking velocity.

From the Divisions of Biokinesiology and Physical Therapy (Fisher, Salem, Song, Lin, Yip, Cen, Gordon, Jakowec, Petzinger) and Neurology (Fisher, Jakowec, Petz- inger), University of Southern California, Los Angeles, CA; and Department of Neurology, David Geffen School of Medicine, UCLA, Los Angeles, CA (Wu).

Presented in part to the Society for Neuroscience, October 17, 2006, Atlanta, GA;

American Physical Therapy Association Combined Sections, February 1–5, 2006, San Diego, CA; the World Parkinson Congress, February 22–26, 2006, Washington, DC;

and the National Parkinson Foundation Collaboration for Care Leadership Confer- ence, October 20 –22, 2005, San Francisco, CA.

Supported by the Kinetics Foundation and National Institute of Neurological Disorders and Stroke (grant no. K23-NS045764).

No commercial party having a direct financial interest in the results of the research supporting this article has or will confer a benefit on the author(s) or on any organization with which the author(s) is/are associated.

Correspondence to Beth Fisher, PhD, Div of Biokinesiology and Physical Therapy, University of Southern California, 1540 E Alcazar St, CHP 155, Los Angeles, CA 90089-9006, e-mail: bfisher@usc.edu. Reprints are not available from the author.

Published online June 5, 2008 atwww.archives-pmr.org.

0003-9993/08/8907-00919$34.00/0 doi:10.1016/j.apmr.2008.01.013

List of Abbreviations AAMHR age-appropriate maximal heart rate BDNF brain-derived neurotrophic factor BWS body-weight support

BWSTT body weight–supported treadmill training CNS central nervous system

CSP cortical silent period FDI first dorsal interosseous GABA ␥-aminobutyric acid MEP motor evoked potential METS metabolic equivalents MMSE Mini-Mental State Examination PD Parkinson’s disease

PT physical therapy ROM range of motion

TMS transcranial magnetic stimulation UPDRS Unified Parkinson’s Disease Rating Scale USC University of Southern California

(2)

Although there has been a recent attempt to examine functional performance associated with higher training intensities, few studies have used different levels of intensity to examine exercise-induced changes in functional performance and how they may compare.^7-10,13

In addition, thus far exercise studies in PD have not examined for associated CNS changes. TMS is a noninvasive method of stimulating the brain and provides a tool with which to assess the excitability of the corticospinal motor system (corticomotor excitability). Single TMS pulses are applied over the motor cortex while recording surface electromyographic responses over a contralateral target muscle. If the target muscle is preactivated (contracted), the TMS pulse induces a characteristic transient period of electromyographic silence called the CSP. Silent period durations beyond 100ms are thought to reflect long-lasting cortical inhibitory processes. Important for this study, single-pulse TMS studies have shown systematic abnormalities of CSP and other corticomotor excitability measures in people with PD. In general, these abnormalities reflect higher corticomotor excitability in PD compared with controls.^14-17 Because CSP represents inhibitory influences on corticomotor excitability, higher excitability would be evident as ashortenedCSP duration. In fact, shortened CSP durations are among the most consistent and widely reproduced TMS finding among PD patients.¹⁸Further, symptomatic treatment of PD with surgical or pharmacologic interventions is associated with lengthening of the CSP toward levels seen in control subjects.^19-21These studies suggest that corticomotor excitability measures, particularly CSP durations, could underlie symptomatic improvement, such as improved motor performance.

Thus, not only is TMS an excellent tool to measure CSP duration and to examine possible exercise-induced changes in PD, but more importantly TMS may be used to support the existence of CNS changes in response to different exercise parameters including intensity.

The objective of this feasibility study was to obtain preliminary data on the effects of high-intensity exercise on functional performance in people with PD relative to exercise at low and no intensity and to examine whether improved performance is accompanied by lengthening of CSP as measured through TMS.

METHODS Participants

Thirty subjects with early-stage, Hoehn and Yahr stages 1 or 2 PD voluntarily consented to participate in the study.²²Early stages of PD were chosen because (1) people with greater physical capability could engage in higher-intensity exercise and (2) neuroplastic mechanisms may be more robust and amenable to environmental influences.^23,24All subjects were required to sign an informed consent document approved by the institutional review board at USC. Subjects were recruited largely from the USC Department of Neurology Parkinson’s Disease and Movement Disorders Clinic and through newspa- per and radio advertisements delivered to the greater Los Angeles area. Before enrollment the diagnosis of idiopathic PD was confirmed by a fellowship trained PD specialist.

The inclusion criteria for the study were the following: (1) diagnosis of PD within 3 years of study participation, (2) 18 years of age or older, (3) medical clearance from the primary care physician to participate in an exercise program, and (4) ability to walk. Potential participants were excluded if (1) the medical or physical screening examination showed a score of less than 24 on the MMSE,²⁵(2) there were physician-deter- mined major medical problems such as cardiac dysfunction that

would interfere with participation, (3) they had musculoskele- tal impairments or excessive pain in any joint that could limit participation in an exercise program, and (4) they had insuffi- cient endurance and stamina to participate in exercise 3 times a week for a 1-hour session. For all participating subjects, all PD medications were kept stable during the course of the study.

Each subject was randomized into 1 of 3 groups: high- intensity exercise, low-intensity exercise, and zero-intensity (no-exercise) group. With their eyes closed, subjects were randomized by self-selecting a card corresponding to 1 of the 3 groups. Subjects were blinded to existing group assignments.

Subjects in the 2 exercise groups received 24 sessions of exercise over 8 weeks by the same physical therapist. Heart rate and blood pressure were monitored during exercise to assess each subject’s exercise tolerance and exercise intensity level. Level of intensity was defined in accordance with the Centers for Disease Control and Prevention and American College of Sports Medicine guidelines by MET, in which 1 MET is defined as the energy expenditure for sitting quietly.^26,27In this study, low-intensity exercise was any activity that burned less than 3 METS and high-intensity exercise burned greater than 3 METS.

Procedures

High-intensity group. Subjects randomized to the high- intensity group participated in 24 sessions of BWSTT. Partic- ipants were fitted in a harness,^awhich was then connected to an overhead suspension system^bpositioned over a treadmill. The suspension system is an overhead-motorized pneumatic lift with a digital readout displaying the amount of weight support.^bBWS was initially set at 10% of each participant’s body weight (to take up the “slack” in the system). However, if the participant was unable to load and support his/her weight during stance with normal gait kinematics, the BWS was increased. Subjects were trained with the assistance of 1 physical therapist and 1 aide if necessary to assist with maintaining the trunk upright. The goal of each treatment session was to have the participant reach and maintain an MET level greater than 3.0 METS and/or 75% of an AAMHR using proper gait kinematics for stance and swing (upright posture, extending and flexing the hip, knee, and ankle and coordinating limb movements to achieve symmetric limb cadence and equal step length). The end goal (ie, at least by session 24) was that each subject would walk on the treadmill continuously for 45 minutes within the above MET level range. However, subjects were permitted to rest if necessary.

Progression on the BWS treadmill system occurred in a number of different ways. Within the limits of a person being able to walk with observationally normative gait kinematics, the following parameters were scaled up in difficulty: (1) BWS was decreased, (2) treadmill speed increased, (3) physical assistance was decreased, and (4) time on the treadmill was increased.

A physical therapist ran each treadmill session and was responsible for decisions regarding progression; monitoring upright posture, manual or verbal feedback on pelvic position, weight shift, stride characteristics, and cadence.

Low-intensity group. Subjects randomized to the low-intensity group participated in 24 sessions of PT. This group was representative of general or traditional PT for people with PD.

An analysis of exercise studies in PD over a 50-year period showed that overall the physical demand of the exercise pro- tocols for the most part were low to moderate in intensity. In addition, we were able to identify that the activities within the studies could be grouped into 6 categories: (1) passive ROM and stretching, (2) active ROM, (3) balance activities, (4) gait,

(3)

(5) resistance training, and (6) practice of functional activities and transitional movements (ie, sit-to-stand).^28,29 Each 45- minute session consisted of activities within each of these 6 categories. Activities were individualized for each subject based on specific impairments and subject goals and included but were not limited to (1) therapist stretch of hamstrings (passive ROM), (2) active stretch of calf in standing (active ROM), (3) standing on foam and single-limb standing exercises (balance), (4) overground gait training on linoleum floor and grass (gait), (5) rubber tubing exercises and weight lifting (resistance training), and (6) transfer training, sit-to-stand, and supine-to-sit (functional activities). MET levels for each activity were ascertained by either selecting activities that were listed in the Compendium of Physical Activities³⁰or estimating MET levels for those activities that were not listed. For exam- ple, an active ROM activity might be a doorway stretch. The estimated METS for this activity would be 1.2, because it compares with standing quietly, a listed activity in the compendium. The goal of each treatment session was to have participants average 3.0 or fewer METS and/or heart rate of 50% or less of their AAMHR for 45 minutes, an MET level within the low-intensity exercise guidelines. Time spent in each activity was documented, and average MET level was calculated at the end of each session.

Zero-intensity group. The zero-intensity intervention consisted of six 1-hour education classes taken over an 8-week period. The following topics were presented: (1) Quality of Life: What is it? (2) Improving Quality of Life in Chronic Illness and PD; (3) Stress, Appraisal, and Coping; (4) Improv- ing Memory; (5) Nonmotor Features of PD; and (6) Treatment Advances in PD.

Subjects in all groups were allowed to continue their customary exercise routines. They were asked, however, not to change their exercise routines. To monitor outside activity level, all subjects filled out a daily exercise diary that was reviewed by the treating therapist.

Data Collection

Data were collected before intervention and immediately after completion of exercise. Subjects began exercise or education classes within 1 to 2 weeks after the baseline assessment. All subjects took their customary medications at the same time relative to each assessment. All assessors were blinded to group assignment.

Assessments

Baseline clinical characteristics of the 3 groups of subjects were obtained and included age, duration of PD diagnosis, UPDRS score, MMSE score, and PD medications.

UPDRS and Hoehn and Yahr staging. Disease severity was examined preintervention and postintervention using the UPDRS and Hoehn and Yahr staging.^22,31 The UPDRS was completed by a second PD specialist, trained in performing the UPDRS. The side of the body (left vs right) and corresponding contralateral brain hemisphere that was most affected by PD was established using the UPDRS.

Functional assessments. All testing took place at the Mus- culoskeletal Biomechanics Research Laboratory at USC. All tests were performed by a blinded biomechanist. Biomechanic assessments of walking and sit-to-stand were used to better understand the underlying mechanisms by which any potential changes in functional capability occurred. Reflective markers (14-mm spheres) were firmly taped to the following bony landmarks: first toe, first and fifth metatarsal heads, medial and lateral malleoli, medial and lateral epicondyles of femur,

greater trochanters, iliac crests, and L5-S1. In addition, nonco- linear tracking markers were placed on the heel, lateral shank, and lateral thigh. An 8-camera (60-Hz) motion analysis system^crecorded 3-dimensional coordinates of the pelvis, thigh, shank, and foot. Ground reaction forces were obtained from force platforms.^d Three-dimensional marker-coordinate processing software (Workstation)^c and Visual3D Movement Analysis Software^e were used to process the raw coordinate data and compute the bilateral segmental kinematics and kinetics for the lower extremity.

Walking test. All participants were asked to walk at a self-selectedpace and asfast as possiblepace along the 10-m solid surface. For all participants, 3 trials were recorded and averaged for each condition. We computed average gait velocity (in m/s), step length (the distance between 2 successive heel contacts of the opposite feet, in meters), stride length (the distance between 2 successive heel contacts of the same foot, in meters), cadence (in number of steps/min), double-limb support time (in percentage of gait cycle), and ankle, knee, and hip sagittal plane maximum joint excursions (in degrees).

Sit-to-stand test. The sit-to-stand task was performed using a firm, armless, adjustable-height chair. The time from initial sitting position to the final sitting position at the end of 3 repetitions was recorded at a self-selected pace. All participants performed 3 sets. A total of 9 repetitions were recorded and averaged. For biomechanic analysis, ankle, knee, and hip sagittal plane extensor net joint moments (in Nm/kg) and joint power (in W/kg) were calculated. In addition, lower-limb symmetry was calculated as the absolute difference of right and left peak hip, knee, and ankle moments and power as well as ground reaction force during standing up.

Transcranial magnetic stimulation. Corticomotor excitability using TMS was assessed before and after the 8-week intervention. Additional criteria excluded those people in which TMS would be contraindicated such as presence of a pacemaker, metal in head, pregnancy, other neurologic disorders, current use of stimulants or medications known to lower seizure threshold, and personal or family history of seizure disorder.^32,33All subjects participating in TMS signed a sepa- rate informed consent document approved by the institutional review board at USC.

Single-pulse TMS was applied using a figure-of-8 coil (9⫻5cm) with a Cadwell MES-10^fby a blinded assessor cer- tified as an experimenter in the TMS laboratory at USC. All TMS procedures were conducted on the more-affected side first. The TMS coil was held tangentially to the skull, with the handle pointing backward and laterally, perpendicular to the central sulcus.³⁴Single pulses of TMS were delivered over the primary motor cortex while monitoring MEPs from the FDI muscle. The site that evoked the largest and most reliable MEP amplitudes was designated the motor hotspot.

This location was marked on a Lycra cap fitted for each subject to ensure consistent targeting of this hotspot throughout the session. With the coil on the hotspot, stimulator intensity was systematically raised from 40% to 100% maximum stimulator output in 10% increments. At each intensity, 10 single TMS pulses were delivered every 5 to 10 seconds. Intensities were always delivered in ascending order. Electromyographic data were collected during isometric voluntary contraction of the FDI muscle at 10% of maximum voluntary contraction. Both subject and investigator visually monitored the level of muscle contraction, and the TMS pulse was timed to occur within 1 to 2 seconds of onset of the contraction while target level of contraction was maintained. Subjects were trained to maintain contraction after each TMS pulse until instructed to relax by the investigator. Electromyographic signals were acquired us-

(4)

ing surface electrodes in a belly-tendon montage from the FDI contralateral to TMS. The signal was amplified and band-pass filtered between 1 and 1000Hz. Data were stored for later analysis in 600-ms samples, beginning 100ms before TMS onset.^g

TMS Data Analysis

All data were analyzed offline with a customized Matlab software tool^hfor analysis of time-series data (dataWizard).³⁵ Each TMS trial was analyzed for CSP duration. The CSP duration was defined as the time between the TMS pulse and the first return of rectified electromyographic activity of at least 50% of pre-TMS background activity after a period of sus- tained silence.³⁶When no CSP could be discerned, CSP duration was marked as 0ms. For each subject and side, 10 CSP duration values per intensity were averaged. The relation between average CSP data and TMS intensity was fitted to a sigmoid curve.^37,38 Sigmoid curves were summarized by 3 parameters: maximal CSP duration (CSPmax), maximal slope (CSPslope), and a midpoint intensity where CSP duration is half maximum (CSP₅₀).

Statistical Analysis

Because this study was conducted as a preliminary trial to assess the responsiveness of people with early-stage PD to high-intensity exercise and observe for changes in measures of brain and behavior, only descriptive analyses including mean and SD were conducted. Percentage change (mean and SD) were calculated as the (post value – pre value)/pre value⫻100 for each subject. Observed trends are reported for the individ- ual exercise groups.

RESULTS Treatment Groups

All 30 subjects completed the study with no adverse events.

Over the 24 exercise sessions, the high-intensity exercise group worked on average at an MET level of 4.3 with a range between 2.5 and 13.3 METS. In fact, 60% of the high-intensity exercise subjects reached 8.0 to 13.3 METS while running at 0% grade and speeds ranging from 8.0 to 12.8km/h (5.0 – 8.0mph). Heart rate for 7 of the high-intensity subjects ranged between 70% and 75% of AAMHR within and across exercise sessions. For the remaining 3 subjects treated with␤-blockers, heart rate ranged between 50% and 60% of AAMHR. The 10 subjects in the low-intensity exercise group averaged 2.4

METS over 24 sessions. The range of intensity of exercise was between 1.8 and 2.7 METS for the low-intensity exercise group. Heart rate for the low-intensity subjects was consistently at 50% or less of AAMHR across and within exercise sessions.

All subjects in the zero-intensity group attended all education classes. The first 4 subjects randomized to the education arm of the study attended education classes as a group. The remainder of the participants received the same education classes, but they were conducted for each subject.

Clinical Characteristics

The mean baseline clinical characteristics of the 3 groups of subjects are shown intable 1. It can be seen that the groups were similar at baseline in age, Hoehn and Yahr stages, duration of PD, and MMSE. Although there was variability within and between groups regarding PD medications, no PD medications were adjusted during the trial. The baseline and postexercise means and SD in UPDRS total score and UPDRS subscores are shown intable 2for each exercise group. Both UPDRS total and motor scores were slightly lower for each of the 3 groups at the postexercise time point.

Motor Performance

All groups showed improvement in some gait performance measures (tables 3, 4). However, the high-intensity group showed consistent improvement in most gait parameters. Spe- cifically, the high-intensity exercise group showed preexercise to postexercise increases in self-selected gait speed (4.4%), stride length (4.7%) (fig 1A), and step length (5.8%). Hip (fig 1B) and ankle (fig 1C) joint excursion increased by 7.5% and 4.6%, respectively, after 24 sessions of BWSTT. In addition, double-limb support time decreased by 6.3% (ie, increased single-limb support). Similar to the results of the self-selected speed condition, in the fast walking assessment the high- intensity exercise group showed within-group postintervention increases in stride length (4.8%), step length (5.6%), and hip (7.4%) and ankle (8.5%) joint ROM.

The average time to accomplish 3 repetitions of sit-to-stand decreased slightly for all groups. We were unable to detect any pre–post differences in lower-extremity symmetry (left vs right lower extremity) at the hip, knee, and ankle joints during sit-to-stand because of the high variability of these measures.

However, although both the zero- and low-intensity groups showed decreased symmetry of ground reaction force (82.4%

and 5.1%, respectively), the high-intensity group had a 33.3%

Table 1: Clinical Characteristics of PD Subjects at Baseline

Characteristics

Zero Intensity

Low Intensity

High Intensity

Patients (n) 10 10 10

Sex (male/female) 8/2 5/5 6/4

Age (y) 63.1⫾11.5 61.5⫾9.8 64.0⫾14.5 Hoehn and Yahr stage 1.9⫾0.3 1.9⫾0.3 1.9⫾0.5 Duration of PD (mo) 17.7⫾13.3 8.8⫾7.9 14.7⫾9.9 MMSE score 29.6⫾0.7 29.3⫾0.8 28.9⫾1.1 Medications

Levodopa (mg) 90.0⫾202.5 15.0⫾47.4 115.0⫾226.1 Pramipexole (mg) 0.5⫾0.7 0.3⫾0.9 0.5⫾.1.0

Ropinerole (mg) 0 0 1.6⫾5.1

Amantadine 30.0⫾94.9 20.0⫾63.2 30.0⫾94.8 Selegiline 0.5⫾1.6 1.0⫾3.2 1.0⫾2.1 NOTE. Values are mean⫾SD or as otherwise indicated.

Table 2: UPDRS

UPDRS Zero Intensity Low Intensity High Intensity UPDRS total

Baseline 36.1⫾9.5 39.4⫾9.3 35.9⫾13.3 Postexercise 32.9⫾10.6 34.2⫾8.0 33.8⫾14.6 UPDRS mental

Baseline 0.8⫾0.79 1.6⫾1.2 1.4⫾2.1 Postexercise 1.1⫾0.99 1.7⫾1.5 1.4⫾1.8 UPDRS ADLs

Baseline 7.7⫾3.8 7.3⫾2.9 7.0⫾3.3 Postexercise 6.8⫾4.0 5.8⫾2.7 7.6⫾3.9 UPDRS motor

Baseline 27.6⫾7.3 30.5⫾8.7 27.6⫾10.3 Postexercise 24.9⫾8.8 26.7⫾7.5 24.8⫾9.0 NOTE. Values are mean⫾SD.

Abbreviation: ADLs, activities of daily living.

(5)

increase in symmetry, suggesting more equal distribution of body weight between the lower extremities during the sit-to- stand task.

Transcranial Magnetic Stimulation

A subset of subjects from each group participated in TMS testing (4 in zero-intensity, 7 in low-intensity, 5 in high- intensity). Both the more- and less-affected hemispheres were tested. No subject had any side effects from TMS. There was no differential effect of intensity of exercise on CSPslope or CSP₅₀. However, for CSPmax, the high-intensity group had an average increase in maximal CSP duration for the more- affected hemisphere (32ms) compared with a 17-ms decrease for the low-intensity group and no change for the no-exercise group (black lines in fig 2). Increases in CSP duration were seen in all subjects who had undergone high-intensity exercise (mean⫾SD: pre, 175.4⫾35.3ms; post, 207.3⫾27.1ms). The same pattern for the high-intensity group was observed for the less-affected hemisphere with an average 19.4-ms increase in CSP after the exercise intervention. The zero-intensity group showed an average 6.5-ms decrease, and there was no change for the low-intensity group. There was 1 subject each in the zero- and low-intensity groups who showed pronounced shortening of CSPmax. On close inspection, the data from these 2 subjects were deemed valid, and the discernible shortening seen potentially reflects the variability between subjects who are within a 3-year range of PD diagnosis.

DISCUSSION

In this study, we found that people with PD participating in high-intensity BWSTT improve spatiotemporal gait parame-

ters, kinematics of gait performance, and lower-extremity symmetry of ground reaction force in sit-to-stand task. This improvement was not consistently observed across measures in the other exercise intensity groups. In addition, every subject undergoing high-intensity BWSTT showed a lengthening of CSP. Lengthened CSP was not consistently observed in subjects in the zero- and low-intensity groups, suggesting that high-intensity exercise may induce activity-dependent neuroplasticity as measured through changes in corticomotor excitability. Finally, all subjects in the high-intensity group completed the exercise program, showing that subjects with PD can be challenged at and can tolerate a very high-intensity treadmill exercise program.

All subjects showed improvement in gait velocity during both self-selected and fast-paced walking, which was most evident in the high-intensity group. Similar to our results, some improvement in gait velocity during self-selected speed walking has been reported in other studies examining treadmill exercise effects in PD. The modest improvement in gait veloc- ityaftertreadmill exercise reported in all these studies including ours may be related to the fact that subjects were already walking at normal gait velocities before the exercise pro- grams.^39-42Perhaps a more notable observation is that subjects in the high-intensity exercise group showed improved gait performance manifesting as changes in gait strategy. Thus, the high-intensity subjects walked within the range of normal gait speed but did so by taking longer steps and moving forward over their limbs through a larger ROM (seetables 3,4). These changes in gait performance driven by high-intensity practice were not observed to the same degree in the low- and zero-

Table 3: Kinematic Variables During Walking

Outcome Measure Zero Intensity Low Intensity High Intensity Velocity (m/s)

Baseline 1.39⫾0.17 1.40⫾0.18 1.46⫾0.20 Postexercise 1.41⫾0.17 1.42⫾0.17 1.52⫾0.19 Step length (m)

Baseline 0.68⫾0.11 0.71⫾0.08 0.73⫾0.10 Postexercise 0.71⫾0.11 0.72⫾0.07 0.77⫾0.08 Stride length (m)

Baseline 1.37⫾0.23 1.42⫾0.15 1.48⫾0.18 Postexercise 1.41⫾0.23 1.44⫾0.14 1.54⫾0.16 Step width (m)

Baseline 0.12⫾0.02 0.10⫾0.02 0.11⫾0.02 Postexercise 0.11⫾0.02 0.10⫾0.02 0.11⫾0.02 Cadence (steps/min)

Baseline 120.33⫾9.26 120.57⫾11.60 120.66⫾10.40 Postexercise 121.09⫾8.60 118.94⫾10.20 120.85⫾8.50 Double-limb support

time (% of gait cycle)

Baseline 24.04⫾6.17 19.53⫾4.49 21.20⫾3.35 Postexercise 21.22⫾4.03 19.87⫾3.58 19.68⫾2.58 Hip ROM (deg)

Baseline 40.1⫾5.3 39.6⫾4.4 41.22⫾5.5 Postexercise 39.1⫾4.2 41.0⫾4.6 44.25⫾6.2 Knee ROM (deg)

Baseline 64.0⫾4.1 63.4⫾5.1 66.0⫾5.8 Postexercise 64.6⫾4.2 64.5⫾4.5 64.8⫾4.8 Ankle ROM (deg)

Baseline 24.2⫾5.2 27.6⫾2.5 29.0⫾3.4 Postexercise 24.4⫾5.5 28.6⫾3.4 30.3⫾3.3

NOTE. Values are mean⫾SD. Table 4: Kinematic Variables During Fast Walking

Outcome Measure Zero Intensity Low Intensity High Intensity Velocity (m/s)

Baseline 1.96⫾0.38 1.92⫾0.23 1.91⫾0.32 Postexercise 2.04⫾0.40 1.94⫾0.19 2.00⫾0.34 Step length (m)

Baseline 0.81⫾0.17 0.82⫾0.11 0.84⫾0.11 Postexercise 0.82⫾0.13 0.85⫾0.09 0.88⫾0.11 Stride length (m)

Baseline 1.60⫾0.31 1.65⫾0.22 1.66⫾0.21 Postexercise 1.64⫾0.26 1.65⫾0.12 1.74⫾0.24 Step width (m)

Baseline 0.12⫾0.03 0.10⫾0.02 0.10⫾0.03 Postexercise 0.11⫾0.02 0.10⫾0.02 0.11⫾0.02 Cadence (steps/min)

Baseline 147.45⫾18.47 141.37⫾13.91 138.65⫾11.50 Postexercise 151.11⫾20.23 142.12⫾14.26 138.71⫾9.87 Double-limb support

time (% of gait cycle)

Baseline 17.36⫾4.40 16.12⫾4.51 16.27⫾4.14 Postexercise 13.59⫾3.82 15.80⫾3.22 15.48⫾2.87 Hip ROM (deg)

Baseline 45.0⫾5.3 45.2⫾5.9 47.2⫾6.5 Postexercise 44.6⫾4.9 46.7⫾5.0 50.4⫾6.3 Knee ROM (deg)

Baseline 64.0⫾7.8 62.0⫾6.0 67.1⫾6.7 Postexercise 60.2⫾13.4 61.7⫾7.2 66.9⫾5.6 Ankle ROM (deg)

Baseline 26.3⫾4.3 28.3⫾5.3 30.3⫾4.7 Postexercise 26.4⫾4.4 29.5⫾5.7 32.5⫾3.3 NOTE. Values are mean⫾SD.

(6)

intensity groups and represent a pattern that is in notable contrast to the problematic gait pattern of people with PD (ie, short steps and limited advancement forward over the lower limbs). Similar findings were reported by Pohl et al,⁹in which relatively high-intensity treadmill training compared with con- ventional gait therapy was shown to have effects on gait pattern, specifically stride length and double-limb support time.

From our study, we learned that increased gait speed may not be a sufficient measure to determine the success of a treadmill intervention in early stage PD and that use of a wide range of gait parameters may be necessary to observe improvement in essential characteristics of gait. In addition to gait measures used in our study, measures of swing and stance time variability (coefficient of variation) have been shown to be particularly sensitive at detecting abnormalities in early PD.⁴³ Herman et al⁸ recently observed that these measures of variability may be modified by an exercise intervention.

In addition, the high-intensity group showed increased symmetry of ground reaction forces in the sit-to-stand task. This suggests that high-intensity treadmill exercise may lead to improvement in other nongait motor tasks and that the tread-

mill training may assist in the ability to load the lower limbs equally. Although treadmill studies in PD^6,7,10,13 have examined other standing or upright axial tasks in addition to gait performance, to our knowledge this study is the first to report a benefit in another distinct motor task that may be due to intense gait training exercise.

In our study, there did not appear to be detectable postintervention differences in the UPDRS between the exercise groups, which was in contrast to the more consistent improvement in functional performance tests observed in the high- intensity group. Possible reasons for differences in outcome measures may be due to (1) the large degree of variability in the UPDRS among people within 3 years of diagnosis, along with the small sample size, and (2) greater sensitivity of functional and objective measures compared with the more subjective UPDRS in capturing changes in motor performance.

An important objective of this study was to examine if high-intensity exercise may be accompanied by CNS changes.

Using TMS, we found lengthening of maximal CSP in all subjects in the high-intensity exercise group that was not consistently observed in subjects in the zero- and low-intensity groups. This finding suggests that intensity may be an important exercise parameter for facilitating activity-dependent neuroplasticity in association with improved motor performance.

Among TMS studies examining corticomotor excitability in PD patients, CSP durations are among the most consistent abnormalities reported, with generally shorter duration associated with greater parkinsonian symptoms.⁴⁴CSP durations are usually shorter in PD patients compared with controls and, within PD patients, are shorter on the more-affected side compared with the less-affected side.^14,45Both CSP durations and parkinsonian symptoms are sensitive to dopaminergic medica- tion. Similar to the observed effects of high-intensity exercise, CSP durations are prolonged in PD patients after taking levodopa,^45-47 apomorphine,⁴⁸and pergolide,^19,49drugs known to provide effective symptomatic relief of motor symptoms. As clinical improvement accompanies dopaminergic treatment, this clinical improvement therefore corresponds with an increase in CSP duration.⁴⁵

The level of excitability within the motor cortex is a balance between excitation and inhibition. The late part of the silent period duration is thought to reflect long-lasting cortical inhibitory processes.⁵⁰As such, the duration of the CSP has been used as an index of the strength and time course of these processes. Studies have shown a loss of cortical excitation and inhibition balance in PD with higher motor system excitability in patients with PD at rest compared with controls—most likely the result of reduced intracortical inhibition.^14,15,44Under tonic muscle contraction, shortened CSP in PD also suggests an enhanced excitability.¹⁴ Inhibition as measured through CSP may be important for suppressing competing motor networks, thereby facilitating cortical-basal ganglia loops specified for an intended motor action.⁴⁴Loss of inhibition as the result of loss of inhibitory cortical mechanisms (ie, shortened CSP), as seen in PD, may impair the focus of neuronal activity onto the appropriate pathways and enhance unspecific motor program transmission. Therefore, interventions such as intense exercise that lengthens CSP may help restore normal motor processing.

The mechanism underlying the lengthening of the silent period duration in people with PD undergoing high-intensity exercise is unclear. However, it is known that CSP is mainly mediated by GABA-B receptors.⁴⁴GABA is the major inhibitory neurotransmitter in the basal ganglia, and abnormalities of GABAergic transmission are key aspects of the pathophysiol- ogy of movement disorders that involve the basal ganglia.⁵¹In

Fig 1. The percentage change (post- pre-exercise/preexercise ⴛ 100) in motor performance measures are shown for each of the 3 exercise groups: zero, low, and high intensity. (A) Percentage change in stride length (in meters) for each group. Stride length is the distance from right-heel contact to the following right-heel contact. (B) Percentage change in hip angle ROM (in degrees) or hip joint excursion for each group. (C) Percentage change in ankle angle ROM (in degrees) or ankle joint excursion for each group.

(7)

addition, voluntary exercise can increase levels of BDNF.

BDNF has neurotrophic and neuroprotective properties, can enhance brain plasticity, and appears to be a prime candidate for mediating the long-term benefits of exercise on the brain.^52,53 BDNF enhances neuronal function by promoting synaptogenesis and neurogenesis.⁵⁴Evidence has shown that BDNF modulates the level of functional inhibition in an activity-dependent manner by regulating the number of GABAergic interneurons.⁵⁵ Although the role of BDNF in modulating GABA-mediated inhibitory transmission is not fully under- stood, it is possible that the lengthening of CSP in this study is related to an exercise-induced increase in BDNF.⁵⁶

In our study, we found that the increase in CSP duration for the high-intensity group was observed in an intrinsic hand muscle, whereas the intense exercise involved a lower-extremity task, specifically treadmill training. This finding suggests that CSP may serve as a marker for a more generalized change in the CNS as a function of a primarily lower-extremity intervention. This is not the first report of postintervention and, specifically, post–treadmill training effects on corticomotor excitability using TMS in people with neuropathology.

Changes in corticomotor excitability and associated improvements in walking function were found after intensive treadmill

training both in people with spinal cord injury^57,58and stroke.⁵⁹ However, to our knowledge, this is the first demonstration of exercise-induced changes in corticomotor excitability using TMS in people with PD, a progressive neurologic disorder.

Animal models of PD have also supported activity-dependent neuroplasticity after intensive treadmill training as measured through changes in dopamine handling and neurotransmission, including increased dopamine release, decreased uptake, and an increase in the postsynaptic dopamine D2-receptor subtype within the basal ganglia.^2,60

Study Limitations

An important limitation of this study is the small sample size and large variability in disease severity and baseline motor performance. As a result of this variability we were not able to show group differences using inferential statistics. Neverthe- less, we were able to show benefits of high-intensity exercise in motor performance and corticomotor excitability. This trend of changes we observed warrants further study with a larger sample size to allow for a more discerning statistical analysis and determination of the relationship between changes in corticomotor excitability and motor performance.

Fig 2. Pre- and postexercise measures of maximal CSP duration (in milliseconds) for subjects in the (A) zero-intensity, (B) low-intensity, and (C) high-intensity groups. Four subjects within the zero-intensity group participated in the TMS studies compared with 6 subjects in the low-intensity and 5 subjects in the high-intensity exercise groups. The thick black lines represent the average pre-CSP and post-CSP for each group.

(8)

CONCLUSIONS

The interest to promote neuroplasticity in PD as a means for eliciting improvement in motor performance has underscored the importance of identifying those exercise parameters that are essential for promoting activity-dependent neuroplasticity.

Findings from our study suggest a potential role of intensity of exercise in driving activity-dependent neuroplasticity and functional improvement in people with PD and warrants further investigation.

To our knowledge, this is the first study to show that people with PD can engage in very high levels of exercise intensity— up to 13.3 METS—and the first to report improvement in both measures of brain and behavior in people with PD as the result of high-intensity exercise. By understanding the effects of exercise on neuroplasticity, novel nonpharmacologic therapeutic modalities may be designed to delay or reverse disease progression in idiopathic PD.

References

1. Nudo RJ, Milliken GW, Jenkins WM, Merzenich MM. Use- dependent alterations of movement representations in primary motor cortex of adult squirrel monkeys. J Neurosci 1996;16:785- 807.

2. Fisher BE, Petzinger GM, Nixon K, et al. Exercise-induced behavioral recovery and neuroplasticity in the 1-methyl-4-phenyl- 1,2,3,6-tetrahydropyridine-lesioned mouse basal ganglia. J Neu- rosci Res 2004;77:378-90.

3. Adkins DL, Boychuk J, Remple MS, Kleim JA. Motor training induces experience-specific patterns of plasticity across motor cortex and spinal cord. J Appl Physiol 2006;101:1776-82.

4. Miyai I, Fujimoto Y, Ueda Y, et al. Treadmill training with body weight support: its effect on Parkinson’s disease. Arch Phys Med Rehabil 2000;81:849-52.

5. Miyai I, Fujimoto Y, Yamamoto H, et al. Long-term effect of body weight-supported treadmill training in Parkinson’s disease: a randomized controlled trial. Arch Phys Med Rehabil 2002;83:

1370-3.

6. Toole T, Maitland CG, Warren E, Hubmann MF, Panton L. The effects of loading and unloading treadmill walking on balance, gait, fall risk, and daily function in Parkinsonism. NeuroRehabili- tation 2005;2:307-22.

7. Cakit BD, Saracoglu M, Genc H, Erdem HR, Inan L. The effects of incremental speed-dependent treadmill training on postural instability and fear of falling in Parkinson’s disease. Clin Rehabil 2007;21:698-705.

8. Herman T, Giladi N, Gruendlinger L, Hausdorff JM. Six weeks of intensive treadmill training improves gait and quality of life in patients with Parkinson’s disease: a pilot study. Arch Phys Med Rehabil 2007;88:1154-8.

9. Pohl M, Rockstroh G, Ruckriem S, Mrass G, Mehrholz J. Imme- diate effects of speed-dependent treadmill training on gait parameters in early Parkinson’s disease. Arch Phys Med Rehabil 2003;

84:1760-6.

10. Schenkman M, Hall D, Kumar R, Kohrt WM. Endurance exercise training to improve economy of movement of people with Par- kinson disease: three case reports. Phys Ther 2008;88:63-76.

11. Nutt JG, Wooten GF. Diagnosis and initial management of Par- kinson’s disease. N Engl J Med 2005;353:1021-7.

12. Clarke CE. Parkinson’s disease. BMJ 2007;335:441-5.

13. Frenkel-Toledo S, Giladi N, Peretz C, Herman T, Gruendlinger L, Hausdorff J. Effect of gait speed on gait rhythmicity in Parkin- son’s disease: variability of stride time and swing time respond differently. J Neuro Eng Rehabil 2005;2:1-7.

14. Cantello R, Gianelli M, Bettucci D, Civardi C, De Angelis MS, Mutani R. Parkinson’s disease rigidity: magnetic motor evoked potentials in a small hand muscle. Neurology 1991;41:1449-56.

15. Valls-Sole J, Pascual-Leone A, Brasil-Neto JP, Cammarota A, McShane L, Hallett M. Abnormal facilitation of the response to transcranial magnetic stimulation in patients with Parkinson’s disease. Neurology 1994;44:735-41.

16. Cantello R, Gianelli M, Civardi C, Mutani R. Magnetic brain stimulation: the silent period after the motor evoked potential.

Neurology 1992;42:1951-9.

17. Dioszeghy P, Hidasi E, Mechler F. Study of central motor func- tions using magnetic stimulation in Parkinson’s disease. Electro- myogr Clin Neurophysiol 1999;39:101-5.

18. Cantello R, Tarletti R, Civardi C. Transcranial magnetic stimulation and Parkinson’s disease. Brain Res Brain Res Rev 2002;38:

309-27.

19. Strafella AP, Valzania F, Nassetti SA, et al. Effects of chronic levodopa and pergolide treatment on cortical excitability in patients with Parkinson’s disease: a transcranial magnetic stimulation study. Clin Neurophysiol 2000;111:1198-202.

20. Young MS, Triggs WJ, Bowers D, Greer M, Friedman WA.

Stereotactic pallidotomy lengthens the transcranial magnetic cortical stimulation silent period in Parkinson’s disease. Neurology 1997;49:1278-83.

21. Dauper J, Peschel T, Schrader C, et al. Effects of subthalamic nucleus (STN) stimulation on motor cortex excitability. Neurol- ogy 2002;59:700-6.

22. Hoehn MM, Yahr MD. Parkinsonism: onset, progression and mortality. Neurology 1967;17:427-42.

23. Kieburtz K. Designing neuroprotection trials in Parkinson’s disease. Ann Neurol 2003;53:S100-9.

24. Kieburtz K. Issues in neuroprotection clinical trials in Parkinson’s disease. Neurology 2006;66:S50-7.

25. Folstein MF, Folstein SE, McHugh PR. “Mini-mental state”. A practical method for grading the cognitive state of patients for the clinician. J Psychiatr Res 1975;12:189-98.

26. Taylor AH, Cable NT, Faulkner G, Hillsdon M, Narici M, Van Der Bij AK. Physical activity and older adults: a review of health benefits and the effectiveness of interventions. J Sports Sci 2004;

22:703-25.

27. Gibbons RJ, Balady GJ, Bricker JT, et al; American College of Cardiology/American Heart Association Task Force on Practice Guidelines. Committee to Update the 1997 Exercise Testing Guidelines. ACC/AHA 2002 guideline update for exercise testing:

summary article. A report of the American College of Cardiology/

American Heart Association Task Force on Practice Guidelines (Committee to Update the 1997 Exercise Testing Guidelines) [published erratum in: J Am Coll Cardiol 2006;48:17]. J Am Coll Cardiol 2002;40:1531-40.

28. Deane KH, Ellis-Hill C, Jones D, et al. Systematic review of paramedical therapies for Parkinson’s disease. Mov Disord 2002;

17:984-91.

29. Deane KH, Jones D, Ellis-Hill C, Clarke CE, Playford ED, Ben- Shlomo Y. A comparison of physiotherapy techniques for patients with Parkinson’s disease. Cochrane Database Syst Rev 2001;(1):

CD002815.

30. Ainsworth BE, Haskell WL, Leon AS, et al. Compendium of physical activities: classification of energy costs of human physical activities. Med Sci Sports Exerc 1993;25:71-80.

31. Fahn S, Elton RL, Fahn S, Marsden CD, Calne DB, Goldstein M.

Unified Parkinson’s Disease Rating Scale: recent developments in Parkinson’s disease. Florham Park: Macmillan Healthcare Infor- mation; 1987. p 153-63.

32. Wassermann EM. Risk and safety of repetitive transcranial magnetic stimulation: report and suggested guidelines from the Inter- national Workshop on the Safety of Repetitive Transcranial Mag- netic Stimulation, June 5-7, 1996. Electroencephalogr Clin Neurophysiol 1998;108:1-16.

(9)

33. Anand S, Hotson J. Transcranial magnetic stimulation: neurophys- iological applications and safety. Brain Cogn 2002;50:366-86.

34. Brasil-Neto JP, Cohen LG, Panizza M, Nilsson J, Roth BJ, Hallett M. Optimal focal transcranial magnetic activation of the human motor cortex: effects of coil orientation, shape of the induced current pulse, and stimulus intensity. J Clin Neurophysiol 1992;

9:132-6.

35. Koski L, Schrader LM, Wu AD, Stern JM. Normative data on changes in transcranial magnetic stimulation measures over a ten hour period. Clin Neurophysiol 2005;116:2099-109.

36. Daskalakis ZJ, Molnar GF, Christensen BK, Sailer A, Fitzgerald PB, Chen R. An automated method to determine the transcranial magnetic stimulation-induced contralateral silent period. Clin Neurophysiol 2003;114:938-44.

37. Devanne H, Lavoie BA, Capaday C. Input-output properties and gain changes in the human corticospinal pathway. Exp Brain Res 1997;114:329-38.

38. Kimiskidis VK, Papagiannopoulos S, Sotirakoglou K, Kazis DA, Kazis A, Mills KR. Silent period to transcranial magnetic stimulation: construction and properties of stimulus–response curves in healthy volunteers. Exp Brain Res 2005;V163:21-31.

39. Lopopolo RB, Greco M, Sullivan D, Craik RL, Mangione KK.

Effect of therapeutic exercise on gait speed in community- dwelling elderly people: a meta-analysis. Phys Ther 2006;86:

520-40.

40. Kerrigan DC, Todd MK, Della Croce U, Lipsitz LA, Collins JJ.

Biomechanical gait alterations independent of speed in the healthy elderly: evidence for specific limiting impairments. Arch Phys Med Rehabil 1998;79:317-22.

41. Sofuwa O, Nieuwboer A, Desloovere K, Willems AM, Chavret F, Jonkers I. Quantitative gait analysis in Parkinson’s disease: comparison with a healthy control group. Arch Phys Med Rehabil 2005;86:1007-13.

42. Ferrarin M, Rizzone M, Bergamasco B, et al. Effects of bilateral subthalamic stimulation on gait kinematics and kinetics in Parkin- son’s disease. Exp Brain Res 2005;160:517-27.

43. Baltadjieva R, Giladi N, Gruendlinger L, Peretz C, Hausdorff JM.

Marked alterations in the gait timing and rhythmicity of patients with de novo Parkinson’s disease. Eur J Neurosci 2006;24:1815-20.

44. Lefaucheur JP. Motor cortex dysfunction revealed by cortical excitability studies in Parkinson’s disease: influence of antipar- kinsonian treatment and cortical stimulation. Clin Neurophysiol 2005;116:244-53.

45. Priori A, Berardelli A, Inghilleri M, Accornero N, Manfredi M.

Motor cortical inhibition and the dopaminergic system. Pharma- cological changes in the silent period after transcranial brain stimulation in normal subjects, patients with Parkinson’s disease and drug-induced parkinsonism. Brain 1994;117(Pt 2):317-23.

46. Nakashima K, Wang Y, Shimoda M, Sakuma K, Takahashi K.

Shortened silent period produced by magnetic cortical stimulation in patients with Parkinson’s disease. J Neurol Sci 1995;130:209-14.

47. Ridding MC, Inzelberg R, Rothwell JC. Changes in excitability of motor cortical circuitry in patients with Parkinson’s disease. Ann Neurol 1995;37:181-8.

48. Manfredi L, Garavaglia P, Beretta S, Pellegrini G. Increased cortical inhibition induced by apomorphine in patients with Par- kinson’s disease. Neurophysiol Clin 1998;28:31-8.

49. Ziemann U, Bruns D, Paulus W. Enhancement of human motor cortex inhibition by the dopamine receptor agonist pergolide:

evidence from transcranial magnetic stimulation. Neurosci Lett 1996;208:187-90.

50. Brasil-Neto JP, Cammarota A, Valls-Sole J, Pascual-Leone A, Hallett M, Cohen LG. Role of intracortical mechanisms in the late part of the silent period to transcranial stimulation of the human motor cortex. Acta Neurol Scand 1995;92:383-6.

51. Galvan A, Wichmann T. GABAergic circuits in the basal ganglia and movement disorders. Progress Brain Res 2007;160:287-312.

52. Cotman CW, Berchtold NC. Exercise: a behavioral intervention to enhance brain health and plasticity. Trends Neurosci 2002;25:295- 301.

53. Cotman CW, Berchtold NC, Christie LA. Exercise builds brain health: key roles of growth factor cascades and inflammation.

Trends Neurosci 2007;30:464-72.

54. Cotman CW, Engesser-Cesar C. Exercise enhances and protects brain function. Exerc Sport Sci Rev 2002;30(2):75-9.

55. Swanwick CC, Murthy NR, Kapur J. Activity-dependent scaling of GABAergic synapse strength is regulated by brain-derived neurotrophic factor. Mole Cell Neurosci 2006;31:481-92.

56. Bardoni R, Ghirri A, Salio C, Prandini M, Merighi A. BDNF- mediated modulation of GABA and glycine release in dorsal horn lamina II from postnatal rats. Dev Neurobiol 2007;67:960-75.

57. Norton JA, Gorassini MA. Changes in cortically related intermus- cular coherence accompanying improvements in locomotor skills in incomplete spinal cord injury. J Neurophysiol 2006;95:2580-9.

58. Thomas SL, Gorassini MA. Increases in corticospinal tract function by treadmill training after incomplete spinal cord injury.

J Neurophysiol 2005;94:2844-55.

59. Forrester LW, Hanley DF, Macko RF. Effects of treadmill exercise on transcranial magnetic stimulation-induced excitability to quadriceps after stroke. Arch Phys Med Rehabil 2006;87:229-34.

60. Petzinger GM, Walsh JP, Akopian G, et al. Effects of treadmill exercise on dopaminergic transmission in the 1-methyl-4-phenyl- 1,2,3,6-tetrahydropyridine-lesioned mouse model of basal ganglia injury. J Neurosci 2007;27:5291-300.

Suppliers

a. Robertson Harness, PO Box 90086, Henderson, NV 89009-0086.

b. Vigor Equipment Inc, 4915 Advance Way, Stevensville, MI 49127.

c. Vicon, 14 Minns Business Park, West Way, Oxford, Oxfordshire OX2 0JB, UK.

d. Model OR6-6-1; Advanced Mechanical Technology Inc, 176 Waltham St, Watertown, MA 02472-4800.

e. C-motion Inc, 20030 Century Blvd, Ste 104, Germantown, MD 20874.

f. Cadwell Laboratories, 909 N Kellogg St, Kennewick, WA 99336.

g. LabView; National Instruments Corp, 11500 N Mopac Expwy, Austin, TX 78759-3504.

h. The MathWorks Inc, 3 Apple Hill Dr, Natick, MA 01760-2098.
