Hydrogen Leaks in Partially Confined

Spaces - Dispersion and Explosions

(2)

A PhD dissertation in

Process, Energy and Automation Engineering

Hydrogen Leaks in Partially

Confined Spaces - Dispersion

and Explosions

(3)

Faculty of Technology, Natural Sciences and Maritime Sciences University College of Southeast Norway

Kongsberg, 2017
