Ship speed power performance under relative wind profiles in relation to sensor fault detection

JournalofOceanEngineeringandScience3(2018)355–366

www.elsevier.com/locate/joes

Ship speed power performance under relative wind profiles in relation to sensor fault detection

Lokukaluge P. Perera

, B. Mo

aUiTTheArcticUniversityofNorway,Tromso,Norway

bSINTEFOcean,Trondheim,Norway

Received25June2018;receivedinrevisedform31October2018;accepted1November2018 Availableonline19November2018

Abstract

Statistical data analysisand visualizationapproaches to identify ship speedpowerperformance underrelativewind(i.e. apparent wind) profiles areconsideredin thisstudy.Shipperformanceandnavigationdata ofaselectedvesselareanalyzed, wherevariousdataanomalies, i.e.sensorrelatederroneousdataconditions,areidentified.Thoseerroneousdataconditionsareinvestigatedandseveralapproachestoisolate suchsituationsare alsopresentedby consideringappropriate data visualizationmethods.Then,the cleaned data areusedto derive various relationshipsamongshipperformanceandnavigationparametersthathavebeenvisualizedinthisstudy,appropriately.Theresultsshowthat the windprofiles along ship routes can beused to evaluate vessel performanceand navigation conditions by assuming the respective sea statesrelatetotheirwindconditions.Hence,theresultsareusefultoderiveappropriatemathematicalmodelsthatrepresentshipperformance and navigation conditions. Suchmathematical models canbe usedforweather routingtype applications (i.e.voyage planning), where the respectiveweatherforecastcanbeusedtoderiveoptimalshiproutestoimprovevesselperformanceandreducefuelconsumption.Thisstudy presentsnot onlyanoverviewofstatisticaldata analysisof shipperformanceand navigationdata butalsotherespectivechallengesin data anomalies (i.e. erroneousdata intervals and sensor faults) due to onboard sensors and data handling systems. Furthermore, the respective solutionstosuchchallengesin dataquality havealsobeen presentedby consideringdatavisualizationapproaches.

© 2018Shanghai JiaotongUniversity.Publishedby ElsevierB.V.

Thisisanopenaccess articleunderthe CCBY-NC-NDlicense.(http://creativecommons.org/licenses/by-nc-nd/4.0/)

Keywords:Speedpowerperformance;Dataanomalydetection;Sensorfaultidentification;Weatherrouting;Statisticaldataanalysis;Shipwindprofile.

1. Introduction

The international MaritimeOrganization (IMO) andother relatedauthoritieshaveenforcedtoimplementenergyefficient ship operational conditions under various emission control measures [1,2] in the shipping industry. The main objective of theseemission control basedenergy efficiency approaches is to reduce aconsiderable amount of bunker fuel usage by improving vessel performance [3].That caneventually mini- mizeshipemissionsandrelatedenvironmentalpollutantsdue to the shipping industry. Pre-planned ship routing with re- specttoweather forecast playsan importantrole inreducing therespectivefuelconsumptionofvessels(IMO,1999),often

∗Correspondingauthor.

E-mail addresses: prasad.perera@uit.no (L.P. Perera), brage.mo@

sintef.no(B.Mo).

categorizedas "Weatherrouting"[4].Thathasalsobeencon- sidered as another emission control based energy efficiency measure. Weather routing is often planned in modern elec- tronic chat display and information systems (ECDISs) un- der integratedbridge systems (IBSs) withrespect toweather forecast, i.e. decision support systems [5–7]. In general, the weather forecast used bysuch systems consists of predicting the state of the atmosphere for a given location at a given period (i.e. 6 to 16 days). Such weather predictions are cal- culated by various atmospheric mathematical models associ- ated with meteorologicalstatistical analyses [8]. As the first step of this process, the past and present atmospheric pres- sure data that are collected by various satellites and global weather observation centers are used toderive the respective globalwind maps.Asthe second step,the sameglobal wind mapsareusedtoderivetherequiredweatherforecastbycon- sidering the respective mathematical models of wave, ocean

https://doi.org/10.1016/j.joes.2018.11.001

2468-0133/© 2018ShanghaiJiaotongUniversity.PublishedbyElsevierB.V.ThisisanopenaccessarticleundertheCCBY-NC-NDlicense.

(http://creativecommons.org/licenses/by-nc-nd/4.0/)

modelstocalculate optimalship routesunderestimated time of departure (ETD) andestimated time of arrival (ETA) val- ues.One should note that the global wind distribution plays the most important role in forecasting such weather param- eters and that can influence on pre-planned ship routes (i.e.

weatherrouting).

2. Ship performanceand navigationconditions 2.1.Ship performance quantification

Several important ship performance measures that relate to weather routing type applications are considered in this section. Not only hull and superstructure resistance but also undesirablevesselmotions duetovariousweatherconditions degradeshipperformance.Hence,weatherroutingfocuseson reducingbothshiphullandsuperstructureshipresistanceand undesirable vessel motions. However, many weather routing applicationscanbelimitedtoshipresistancecalculationsdue tothe complexities in capturing un-desirable vessel motions under various mathematical models. In general, ship resis- tanceconsistsof four maincomponents: frictionalandresid- ualresistance,encounterwaveresistanceandwindresistance.

Frictional and residual resistance relates to the underwater section and air resistance relates to the overwater section of thevessel. Furthermore, ship resistancefurtherincreases due toencounterwaveconditionsandundesirablevesselmotions.

Wind resistance contributes 2–10% of total ship resistance [10]andrelates toshipspeed,superstructureareaofthe ves- sel, relative wind (i.e. apparent wind) speed and direction [11,12]. Even though windresistance calculations havebeen considered under weather routing type applications, the re- spective effects on ship resistancecan be minimalcompared to wave resistance. There is less attention on wind profiles underweather routingtype applicationsduetothe samerea- sons.

Wind profiles (i.e. global wind maps) are used to create the environmental models of wave, ocean and tidal current, ice,atmosphericpressureandtemperatureconditionsas men- tioned before. Therefore,this study also proposes touse the relative wind profile along a ship route to evaluate vessel speed and power performance under weather routing type applications by assuming the respective sea states relate to relative wind conditions. These weather routing type appli- cations use various optimization algorithms, which estimate the required speed power profile under weather forecast in

power/thrustlevelsforaselectedrangeofshipspeedsarecal- culated.Thesameexperimentresultscanbeextrapolatedinto roughweathersituations,wheretherespectivevesselspeedre- ductionsduetothevariationsinshipresistance,power/thrust conditions and propulsion efficiency can be calculated. Fur- thermore, the same results can be verified under actual sea trail results and that consist of measuring the required ship speedandpower valuesundervariouswave andwind condi- tions.Ship navigationunderwind andwave conditionsis of- tenidentifiedasseakeeping,wherevariousinteractionsamong shippower,speed,motionandweatherconditionsareencoun- tered. Ship performance and navigation data under various weatherconditions arecollectedbyonboardsensorsanddata acquisition systems to observe the actual sea keeping capa- bilitiesof vessels [14,15].

The respective weather effects in ship speed and power performance can be identified realistically by these sea trial data. Windand wave conditions are the primary factors that influence on ship speed power variations as mentioned be- fore. In general,head wind andwave conditionsreduce ship speed and following wind andwave conditions can improve ship speed slightly in some navigation situations. However, highabsolute windandwave conditions around avessel can reduce the propeller thrust andincrease the dragfrom steer- ing corrections. Therefore, waveand wind forecast around a shipisanessential partinpredictingaccurateshipspeedand motionconditions (i.e.heave,pitchandrollmotions)alonga voyage. Such situationsare furtherinvestigated in thisstudy.

2.2. Recentstudies

Manychallengescanbeencounteredinhandlingshipper- formance and navigation data that are collected under on- boardsensors anddata acquisitionsystems. Thesechallenges are oftenpresentedinthe recent literatureundervariousdata analyses. Data analysis for an inland river ship in relation to its operational energy efficiency is presented in [16]. A performance evaluation approach for asteam-propelled mer- chant ship by collecting the respective data is presented by [17].In addition,several studiesondata analysesof fuel us- age for ship operations are presented by [18–20]. A study on statistical analysis performed on the data sets collected fromseatrialsof asmalltraining shipispresentedin[21].A studyonfull-scaledataanalysisforapassengerferrytoeval- uate itsperformance ispresented in [22].Furthermore, these studies are integrated with port performance evaluation sys-

tems in some situations [23]. However, these studies ignore the challenges that are associated withthe respectivesensors and data handling approaches. e.g. the scattering effects and otherdataanomaliesduetoroughweatherconditions [24].If theseissues(i.e.erroneousdataconditions)inthesensorsand data handling approaches have not been identified properly, that can degrade the results of ship performance and navi- gation dataanalysis. Hence, this study not only presents the outcome of statistical data analysis of ship performance and navigation data but also the issues that are associated with sensors and data handling approaches. Furthermore, the so- lutions to such situations, i.e. data anomalies, in vessels are also proposed, where various methodologiesto overcome er- roneous data conditions are illustrated. That can be done by introducing appropriatedatavisualization methodstocapture proper and abnormal data regions. The proper data regions can be used to identify the respective ship performance and navigation conditions and the abnormal data regions can be used to identify variousdataanomalies.

2.3. Data visualization

A considerable amount of work in this study focuses on various visualization methodsdue tothe same reason.There are several contributions that can be observed from data vi- sualization approaches [25].The maincontribution is the in- formation extraction that can capture proper and abnormal regionsfrom shipperformance andnavigationdata sets.One shouldnotethataconsiderableamountofdomainknowledge in shipping mayrequire to dothis dataclassification: proper and abnormal data regions. The proper and abnormal data regionscanbeused toidentifyshipperformance andnaviga- tion conditions andvariousdata anomalies, respectively. The maincontributionof thisstudy istovisualizeproperdata re- gionsandextract relevantinformationtoquantifyshipperfor- mance and navigation conditions [26,27]. Furthermore, data anomalydetectioncanalsobeconsideredasanothercontribu- tion in thisstudy andsuch anomalies canfurther be divided intosensorfaultsandsystemabnormalevents[28,29].There- fore,thisstudyfocusestodevelopdatavisualizationmethods for shipperformance andnavigation datasets tosupport the required analyses. The outcomes of such data analyses can be used to evaluate ship performance and reduce respective emissions.

2.4. Shipemission considerations

Chemical energy in bunker fuel is converted to mechani- cal energy by marine engines (i.e. marine power plant) that drive ship propellersto generaterequiredship speeds.These marine engines consist of various mechanical and electrical energy losses, thereforeenergy recoveryandemission reduc- tion approaches (i.e. exhaust recirculationandheatrecovery) have been considered to improve ship performance. Exhaust emissionsistheoutcomeofthecombustionprocessofmarine engines, wherevariousexternalexhaust gascleaningsystems are used.In general,these externalexhaust gascleaningsys-

tems can be categorized as scrubber technology to reduce SOxemissions andselective catalytic reduction (SCR) tech- nology for NOx emissions. Exhaust gas recirculation (EGR) andheatrecoveryapplicationsimprove shipperformance and lowtemperaturecombustion processeswithmulti-fuelengine technology (i.e. various fuel types) have also been consid- eredto reduce exhaust emissions. Multi-fuel engine technol- ogy (i.e. with liquefied natural gas (LNG), heavy fuel oil (HFO)or marinedieseloil(MDO))canalsobeaflexibleso- lutionthatextensivelyusestosatisfyvariousemissioncontrol requirementsin shipping [30–34].

Mechanical energy generated by marine engines transfers toshippropellerstocreaterequiredshipspeeds.However,ad- ditional mechanical energy losses can occur due to the pro- peller efficiency because of its fouling and cavitation con- ditions. The propulsion thrust generates the required ship speeds. Ship resistance can be categorized as the net force opposing to this propulsion thrust and that relates to vessel speed,draftandtrimsvaluesandwind,wave,oceanandtidal currentconditions.Furthermore,additionalenvironmentalfac- tors (i.e. water depth and river banks) can also influence on thisship resistance especially inconfined waters. Therefore, shipresistanceinsuchsituationscanalsointroduceadditional energy lossesinvessels andthe samealong avessel naviga- tion path should be considered to develop appropriate data drivenmodels [35], where that can be used towardsweather routingtypeapplications.Itisbelievedthatdatavisualization can be the first step that should be implemented to develop such models. Furthermore, the classification between proper andabnormal data regions can also play an importance role indeveloping such models, where the quality of the respec- tive data sets can influence the model accuracy [36]. The properdataregionscanbeusedtoderivevariousrelationships amongship performance andnavigation parameters andthat canmakethebasicfoundationforsuchmodelsthatoftenhave beencategorizedasdigitalmodelsduetotheirdiscretenessin systemstates [35].However,the maturityof suchdatadriven models to capture energy efficient vessel operational condi- tions isyet tobe achieved in the future. Vessel performance andnavigationparametersalonganavigationpath thatrelate toship speed power conditions withrespect to relative wind profilesareconsideredinthisstudy andthat canbeaninitial step towards such data driven models. These parametersare statistically analyzed, andthe results are presented appropri- atelytoevaluatevesselperformance, evenundervariousdata anomalies, i.e. erroneousdata conditions.

3. Data analysis 3.1. Vesselinformation

A data set of ship performance and navigation parame- ters from a selected vessel is analyzed in this study. The vessel is a bulk carrier with following approximate partic- ulars:ship length: 230 (m), beam: 30(m), grosstonnage: 40 (tons),deadweightatmaxdraft:73(tons).Thevesselispow- eredby2-strokemainengine(ME)withmaximumcontinuous

Fig.1. Relativewindprofileoftheship.

rating (MCR) of 7600 (kW) at the shaft rotational speed of 100(rpm).Furthermore, thevesselhasafixedpitchpropeller diameter 6 (m) with 4 blades. The data points are collected with15(min) sampling intervalswith instancevalues.

3.2.Relative wind distribution

To consider ship speed power performance with respect to relative wind conditions, the following vessel parameters are considered [37,38]: speed through water (STW), speed over ground (SOG), main engine (ME) power and relative wind speed and direction. It is assumed that the respective relativewindprofiles(i.e.speedsanddirections)relatetothe encounteredseaconditionsofthevesselas mentionedbefore, thereforeaddedshipresistanceincreasesduetohighwindand waveconditionsinsuchsituations. Therelative windprofiles relate to the encountered sea states as described in Beaufort scale[39].These highwindconditions canoften createhigh waves,therefore the winddistributionalong ashiproute can be used to evaluate vessel speed power performance. How- ever, the respective data should be visualized, appropriately toextract the respectiveinformationinshipperformance and navigation conditions. Firstly, statistical data analysis of the relative winddistribution of the vessel is visualized. The re- spective histograms for relative wind speeds and directions are presented in the top two plots of Fig. 1. The relative wind speed and direction profiles vary from 0 (m/s) to 25 (m/s)and0°and360°,respectively.The combinedhistogram (i.e.two dimensional)of thesameparametersispresented in the bottom plot of the same figure. One should note that a two-dimensionalhistogramapproachoftherelativewind(i.e.

apparentwind)profileofthisvesselimprovestheinformation visibility,considerably. Such approach has not been used by

the shipping industry, previously to the author’s knowledge.

The starboardandportrelative winddirections are presented from 0° to 180° and 0° to −180°, respectively. One should notethat 0° representsmean head winds. Several data peaks are notedespecially around 0°relative windangle inthisvi- sualizationapproachandthathasbeencategorizedaspossible dataanomaly regions. Furtherdetailsonsuch dataanomalies havebeen presented inthe future sectionsof this study.

The topviews of the sameplot withrespect toshipSTW and SOG values are presented in the left and right plots of Fig.2.Amajorityof highSTWandSOGvaluesare located near the zero relative wind angle, i.e. head-wind conditions, duetorelative motionsof thevessel.Therespectivecontours are also presented inthese plots,where the samedata peaks that are categorized as possible data anomalies can also be noted.One shouldnotethat thesedata peaksmayalso relate to data scattering effects that are discussed, previously. As the next step of this study, the respective reasons for these data peaks are investigated. The sensor data of the relative winddirectionrangefrom(0°to2°)withtherespectivewind speed values (i.e. with respect to the number data points) are presented in top and bottom plots of Fig. 3. The results show that the relative wind speed values are often repeat- ing within this wind direction range. In general, the wind speed values should not repeat for such long time periods due to the sensor noise. One should note that sensor noise can introduce small parameter variations into the respective measurementsandthat caneliminatethepossibilityof having repeated values. It is believed that highvibration conditions encountered by the wind sensor may have resulted in these repeated data points. Therefore, the wind speed values may have been frozen in such situations and the digital data ac- quisition systemhas repeatedthe samevalues.

Fig.2. RelativewindprofilewithSTWandSOG.

Fig.3. Erroneousdatawindsensordata.

However, the wind sensor is the only sensor that has en- countered thistypeof data anomalies. Theserepeatedvalues are noted as data anomaly regions and those data intervals are removedfrom therespectivedataset,where analgorithm is developed toremove such dataintervals. One shouldnote that combined histograms can be used to observe such sen- sor relateddataanomaliesandthat cannotbeobservedunder single parameter histograms. Therefore, the identification of such sensor related anomaliesis onecontribution of data vi- sualization, asmentionedbefore.Itisassumed thatthevessel is symmetricalaround the centerline,thereforethe windpro- filedatawithoutdataanomaliesfrombothstarboardandport side are combined in the following step. The resulted com- bined histogram for relative wind speeds and directions is presented inFig. 4. Aspresented inthe figurethe respective data peaks disappeared andasmooth surface compared with

theperviousplotcanbenoted.Furthermore,ahighergirdsize in the data plot is also selected to improve the information visibility.Thetopview(i.e. contourplot)for thesamefigure with the respective STW is presented inFig. 5. One should note that high and low relative wind speed values are allo- catedtowardshead(i.e. 0°)andfollowing(i.e. 180°) relative wind directions of the vessel, respectively. Since this study evaluates ship speed power performance under relative wind profiles,vesselslowmoving situations (i.e.maneuvering)are ignored from the data analysis. E.g. ship speed values less than3 (knots) are considered as maneuveringsituations, and those values are removed from this data set to improve the information visibility. Hence, the same data plot with ship speed values greater than 3 (knots) is presented in Fig. 6. Thesamesituation as acombined histogramofrelative wind directions and speeds is presented in Fig. 7. A smooth data

Fig.4. Onesidedrelativewindprofile(cleaneddata).

Fig.5. OnesidedrelativewindprofilewithSTW.

surface compared with Fig. 4 is noted in this figure and a considerable number of data points are allocated near ship heading(i.e.0°)relativewinddirection.Furthermore,relative wind speeds approximately 5 (knots) or above are encoun- tered by the vessel (i.e. encounter angle is less than 90°) in anumberofship navigationsituations.Therefore,thisvessel feelsheadwindconditionsinsuch shipnavigationsituations.

3.3.Ship speedpower performance

Thenextstepinthisstatisticaldataanalysisstartswithship speedpowerperformanceparameters[40].Thehistogramsfor STWand SOG for the samevessel are presented in the top

Fig.6. Onesidedrelativewindprofile(cleaneddata).

and middle plots of Fig. 8. Considerable variations among STW and SOG data distributions are noted in these results and tidal and ocean currents may influence on these ship speed variations. The histogramfor the respective speeddif- ferences (i.e. STW - SOG) is presented in the bottom plot of Fig. 8. The result shows two continuous statistical distri- butions approximately from −8 (knots) to −5.5 (knots) as a minor distribution and −5.5 (knots) to 6 (knots) as a major distributioninthesamefigure.In general,the mainstatistical distribution from −5.5 (knots) to 6 (knots) (i,e, window P) is a reasonabledistribution, if the vessel is navigation under tidaland oceans current conditions. However, the minorsta- tisticaldistributionfrom−8(knots) to−5.5(knots)isapos-

Fig.7. Onesidedrelativewindprofile(cleaneddata).

Fig.8. Shipspeeds:STW,SOGandSTW-SOG.

Fig.9. SpeedpowerprofilewithRel.Windspeedandangle.

sible buthighly improbablesituation, where tidalandoceans currents mayhave influenced.It is concluded that either this ship was navigating under high tidal current conditions or the STW sensor was creating a data anomaly region in this situation.

The combined histogram for STW and ME power values is presented in Fig. 9. A general speed power profile for a

vesselisnotedinthisfigurewithseveralunusualdataregions.

It is observed that the unusual data region P relates to the minorstatistical distribution (approximately from−8 (knots) to−5.5(knots)) inthebottom plot of Fig.8.Therefore,this regionisalsomarkedasdatawindowPinFig.9.Oneshould note that the vessel is navigating relatively slow STW with highME power conditions inthisdata region.

Fig.10. STW-SOGvs.Rel.Windspeedanddirection.

The speed differences between STWand SOG valuesvs.

respect to relative (Rel.) wind direction with respect to rel- ative (Rel.) wind speed are presented in Fig. 10. This data plot is created to further investigate data region P (i.e.−8 (knots)<STW-SOG<−5.5 (knots)).The results show that a majority of data points, located in region P, appears under starboard beam relative wind conditions (i.e. moderate rela- tivewindspeeds).Thisisanunusual situation, thereforethat iscategorizedasasensorfaultsituation,wheretheshipspeed sensorisreadingsomeerroneousvaluesduetospecificwind conditions. One should note that such wind conditions can alsorelate tospecificwaveconditionsandthatmayhavecre- ated such sensor fault situations. Therefore, this data region (i.e.window P) isconsidered as an erroneousdata condition andremovedfromtheselecteddataset.Thiserroneousregion is ignored from the general speed power calculations, i.e. a reasonableapproximation.

The respective top view (i.e. contour plot) for the same distributionwithrelativewind speedsispresentedinFig.11. The top view of the same plot as a modified data set (i.e.

without data anomaly region, window P) with relative wind speedsispresented inFig.12.Aspresented inthe figure,the unusualdata region(i.e.data windowP)is disappearedfrom this data set. Both plots consist with relative wind speeds.

Theresultsshow that vesselspeedsdecrease duetohighrel- ative wind speeds for the same ME power levels, i.e. due tothe increased ship resistance inrough seaconditions. The samefigurewithahighergridscalefor STWandME power valuesis presented in Fig. 13.A smooth data surface is ob- servedinthisfigurecomparedtoFig.9 duetotheremovalof dataanomaly regions. Therefore,this wind profile along the voyage can be used to identify engine power requirements and evaluate the performance of the vessel. This is based on appropriate data visualization approaches, where the re- spective ship performance and navigation parameterscan be observed with respective the relative wind conditions. Fur- thermore,suchwind conditions canbeagood representation forthe respectiveweather conditions encounteredby vessels.

Furthermore, favorable weather conditions along ship routes canbeselectedinvoyageplanning typeapplications bycon- sideringthe same information.

A comparison between STW and SOG values is consid- ered in Fig. 14. A combined histogram for STW and SOG

Fig.11. Shipspeedpowerprofilewithrelativewindspeed.

values is presented in the bottom plot. The respective con- tour plot andthe same withME power are presented in the topleft andrightplots of thesame figure.DatawindowP is alsonoted intheseplotsandoneshouldnotethathigher ME power valuesare associated withthe same region. Similarly, thisdataregion(i.e.datawindowP) isassociated withlower STW values for higher SOG values. Therefore, thisdata re- gionisobservedas asensorfaultsituation, i.e.data anomaly regionand it is further confirmed since the same region is associated with higher fuel consumption. An approximately linear relationship between STW and SOG values is noted until 12 (knots) of STW values in the same figure. An ap- proximatelyconstantSOGvaluesforSTWfrom12(knots)to 14(knots)isalsoobservedinthesameplot.Anotherapprox- imately linear relationshipbetween STWand SOGvalues is

Fig. 12. Ship speed power profile with relative wind speed |STW – SOG|<5.5(knots).

notedfrom14(knots)to20(knots)ofSTWvalues.TheSOG values arelowerthan therespective STWvaluesinthese re- gions, where the vessel is navigating against oceanand tidal currentconditionswithhigherenginepower.Oneshouldnote that higher STW/SOG valuesare associated with higher ME power values for this vessel (see top right plot of the same figure). These SOG and STW discreate linear relationships are marked as line segments inthe top left plot of the same figure and that can be a representation of the respective pa- rametercorrelations.Suchparametercorrelationscanbeused

to develop an appropriate mathematical model for ship per- formance monitoring, as discussed before[41].

Finally,the modifieddataset(i.e. erroneousdata intervals (dataanomalies) are removed)of ship performance andnav- igation parameters ispresented inFig. 15.The totalnumber of data pointsis divided into four plots to improve data vi- sualization, where adequateinformationon shipperformance andnavigationconditions can be observedandthe same ob- servations, i.e. parameter relationships, can be used to de- velop appropriate mathematical models. The figure consists of the following ship speed power parameters: STW, SOG, rel.wind speedandME power(i.e.scaled). Oneshouldnote that lessdata scatteringsituations areobservedin theseplots duetotheproposeddataanomalyidentificationandisolation, i.e. data cleaning, approaches. Therefore, a better overview of ship speed-power performance can be visualized in these results.The vessel is maintaining constant ME power values for these voyage segments resulted in constantSTW values.

Hence, the vessel is also maintaining constant SOG values due to the same reason in some navigation situations. The results show possible relationships among the respective pa- rameters at the selected datawindows (A,B, C,and D)and suchrelationships arefurtherelaboratedinthe followingsec- tion.

Thefirst part ofdata windowArepresentsaconstantME power situation withrespect toSTW andSOG values under low relative wind speeds. Hence, the STW values are lower than the SOG values in this situation due to calm weather conditions. The second part of the same data window has relatively low ME power values, where reduced STW and SOG values are noted. However, the STWand SOG values forthe sameME powerlevel arereducedconsiderably inthe lastpart of the same data window dueto highwind speeds, i.e. rough weather conditions. The first part of data window Brepresentsanapproximately constanthighME powerlevel withrespecttothe STWandSOGvaluesunder highrelative wind speeds. Reduced relative wind speeds are noted inthe lastpartof the samewindow,wherethe respectiveSTWand SOG values are also improved, considerably due to calm weather conditions. A considerable increase inrelative wind

Fig.13. ModifiedSpeedpowerprofile.

Fig.14. SOGandSTWprofiles.

Fig.15. Shipperformancedata.

speedsisobservedindatawindowC,thereforetherespective STWandSOGvaluesare decreasedduetothe relatedrough weather conditions. However, the ME power level has also been increased by the vessel in this situation to improve shipspeeds.Similarly, datawindow Drepresentsasituation, where the relative wind speed values are changed from low

tohighvalues,thereforetherespectiveSTWandSOGvalues arealsodecreased.Hence,thefiguresummarizestheparame- terrelationships amongSTW, SOG,rel.windspeedand ME powervaluesandtheresultscanbeused todevelopappropri- atemathematical models.Suchmodelwilleventuallysupport weather routing type applications, where the wind profiles

along ship routes can be used to identify the engine power requirementsandevaluatethe performanceofthevessel [42].

4. Conclusions

In general,the parameter of ME power is proportional to the cube of the ship speed, i.e. STW and SOG values. The STW and SOG values decrease, significantly for the same ME powerunderhighrelativewindspeedsandthatmayfur- ther complicate ship speed-power relationships as visualized intheresults.Suchcomplexrelationshipsamongshipperfor- manceandnavigationparameters(i.e.STW,SOG,MEpower and relative wind speeds) are observed in thisdata analysis.

Furthermore, data anomaly detection and isolation, i.e. sen- sor fault detection and data cleaning, have also been imple- mented during the same analysis toimprove the information visibility. Therefore, those approaches can be considered as the maincontributionofthisstudy.Even though variousdata analysesarepresentedinthe literaturewithrespectivetoship navigation under ocean wind and wave conditions [43], the combined approach (i.e. statistical data analysis and sensor fault identification) has not been illustrated in those studies, adequately. Itisalsobelieved thatsuch acombinedapproach canbeused todetecttherespectiveanomaly conditions,spe- cially.

Thisstudy hasinvestigated therelationships amongvessel performance and navigation parameter andthe relative wind profilebyassumingrelativewindconditionsrepresentthesea state in the respective ship navigation area. Relative wind speed influences on the ship speed power requirement and such relationships can be used to develop appropriate math- ematical models, as mentioned previously, to evaluate vessel performance.Furthermore,associateddataanomaliescanalso be identified and removed from the respective ship perfor- mance andnavigation datasets and that canfurther improve therespectivemathematicalmodels[44].Suchmodelscanbe usedinweatherroutingtypeapplications[45,46]andthatmay simplifythecomputational complexityintheoptimizational- gorithms. Oneshould notethat the vessel windprofile along therespectiveshiproutecanbeusedtoestimaterequiredship STW, SOGand ME powervalues, approximately inweather routingtypeapproach.Similarly, thesameresultscanalsobe used todetermine optimalship routes,orientations, and suit- able engine power configurations by consideringship design characteristics underforecasted andactualweatherconditions in thesame applications [47,48].

Acknowledgements

This work has been conducted under the project of “SFI Smart Maritime (237917/O30) - Norwegian Centre for im- provedenergy-efficiencyandreducedemissionsfromthemar- itime sector” that is partly funded by the Research Council of Norway. An initial version of this paper is presented at the3rdInternationalConferenceonMaritimeTechnologyand Engineering(MARTECH2016),Lisbon,Portugal, July2016.
