R E S E A R C H A R T I C L E Open Access

An evolutionary analysis of genome expansion and pathogenicity in Escherichia coli

Jon Bohlin^1*, Ola B Brynildsrud², Camilla Sekse³and Lars Snipen⁴

Abstract

Background:There are several studies describing loss of genes through reductive evolution in microbes, but how selective forces are associated with genome expansion due to horizontal gene transfer (HGT) has not received similar attention. The aim of this study was therefore to examine how selective pressures influence genome expansion in 53 fully sequenced and assembledEscherichia colistrains. We also explored potential connections between genome expansion and the attainment of virulence factors. This was performed using estimations of several genomic parameters such as AT content, genomic drift (measured using relative entropy), genome size and estimated HGT size, which were subsequently compared to analogous parameters computed from the core genome consisting of 1729 genes common to the 53E. colistrains. Moreover, we analyzed how selective pressures (quantified using relative entropy anddN/dS), acting on theE. colicore genome, influenced lineage and

phylogroup formation.

Results:Hierarchical clustering ofdSanddNestimations from theE. colicore genome resulted in phylogenetic trees with topologies in agreement with knownE. colitaxonomy and phylogroups. High values ofdS, compared to dN, indicate that theE. colicore genome has been subjected to substantial purifying selection over time;

significantly more than the non-core part of the genome (p<0.001). This is further supported by a linear association between strain-wisedSanddNvalues (β=26.94±0.44,R²~0.98,p<0.001). The non-core part of the genome was also significantly more AT-rich (p<0.001) than the core genome andE. coligenome size correlated with estimated HGT size (p<0.001). In addition, genome size (p<0.001), AT content (p<0.001) as well as estimated HGT size (p<0.005) were all associated with the presence of virulence factors, suggesting that pathogenicity traits inE. coliare largely attained through HGT. No associations were found between selective pressures operating on theE. colicore genome, as estimated using relative entropy, and genome size (p~0.98).

Conclusions:On a larger time frame, genome expansion inE. coli, which is significantly associated with the acquisition of virulence factors, appears to be independent of selective forces operating on the core genome.

Background

It has been widely documented that horizontal gene transfer (HGT) can make potentially harmless, even pro- biotic, bacterial species lethal [1,2]. Considerable research has focused on how bacteria can evolve from being nonthreatening, host-independent and free-living organisms to become obligatory intracellular parasites with reduced genomes [3-9]. However, the evolutionary mechanisms explaining genome expansion due to HGT are much less documented. One reason for this is the

need for a large number of fully sequenced and assembled genomes from strains of species that are parti- cularly well suited for such analyses. The recent development of high-throughput sequencing technology has reduced sequencing costs and for many microbial species there are now multiple strains, completely sequenced and assembled, available for analyses in public databases [10]. This allowed us to explore strain-level re- lationships between base composition, genome size and predicted HGT in several microbial species in a recent study [11]. We found that the genome size, compared at strain-level, was predominantly correlated with genomic AT content, contrary to what has been found for prokaryotes in general [12]. Additionally, AT content

* Correspondence:[email protected]

1Division of Epidemiology, Norwegian Institute of Public Health, Marcus Thranes gate 6, P.O. Box 4404, Oslo 0403, Norway

Full list of author information is available at the end of the article

© 2014 Bohlin et al.; licensee BioMed Central Ltd. This is an Open Access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly credited. The Creative Commons Public Domain Dedication waiver (http://creativecommons.org/publicdomain/zero/1.0/) applies to the data made available in this article, unless otherwise stated.

(2)

correlated with predicted HGT size, which again correlated with chromosome size [11]. In this study we also analyzed the influence of selective pressures on microbial genome size using the concept of relative entropy [13,14].

Relative entropy can be used to measure genomic distance and is computed with the Kullback–Leibler measure between observed and expected codon frequencies (see [14] for more details). The expected codon frequencies are calculated from genomic nucleotide frequencies so that decreasing distances between observed and expected codon frequencies imply increased independence between the neighboring nucleotides constituting the codons. This implies more random distributions of codon frequencies presumably due to mutations/genetic drift [13,15]. A negative correlation between relative entropy and AT content has previously been detected in microbial genomes, implying that AT-rich genomes tend to have, on average, a more random base composition than GC-rich genomes [11,13,16]. The greater similarity between AT-rich genomes and random DNA sequences, with similar base compositions, is a consequence of the fact that genomic mutations are in general biased towards AT-richness [17,18].

Horizontally transferred DNA tends to have lower relative entropy than DNA of the host chromosome. Thus, it is likely that the genomes of strains with high levels of horizontally transferred DNA will, on average, have lower relative entropy than the genomes of strains having received less HGT [13]. However, it may also suggest differences in how selective forces operate at the strain level, analogous to the general negative correlation between AT content and genome size, which appears to be largely re- versed at the strain-level of bacterial species [11].

ThedN/dSratio, wheredNdescribes the difference in non-synonymous substitutions between taxa anddSdes- ignates the difference in synonymous substitutions, has also been associated with selective pressures [19]. In- deed, a largedS relative to dNis linked to purifying selection; dN=dS is assumed to indicate neutrality of selection, while a dNgreater than dS is associated with positive selection [19]. Not only doesdS>dNprovide an approximate quantitative measure of the selective pressures involved in purging non-synonymous substitutions resulting in reduced fitness, but the relation may also give clues about the species’ population structure [18].

Additionally, time is a central factor [19]. A recent diver- gence between two or more strains is often indicated by dN>dS, since such mutations are more likely to take place within a short time span [19].

It has previously been shown that purifying selection correlates with genome size for microbes above strain level [20]. In the present study we wanted to examine whether selective forces would leave a base compositional

pattern in the core genomes of bacterial strains undergoing genome expansion, mediated through HGT, since such a pattern has been observed for microbial species undergoing genome reduction [3,13]. We focused our analysis onE. colisince this particular species is renowned for extensive HGT and has many strains sequenced and fully assembled [21,22]. Since pathogenicity has been linked with HGT [1,2] we also wanted to test whether the pathogenic potential of theE. colistrains correlated with genomic properties such as AT content, genome size, genomic drift, and selective pressures, as estimated using relative entropy and dN/dS. To reach our aim we extracted theE. colicore genome, consisting of 1729 genes, from 53 E. coli strains and estimated dS and dN, as well as the other genomic properties mentioned above. We also gen- erated a maximum likelihood tree based on mutations in the mutT gene, which has been associated with hyper- mutable strains [23], and compared the congruency of that tree to the trees resulting from thedS- anddN-based hierarchical cluster analyses.

Results and discussion

Estimation ofdNanddSfrom theE. colicore genome We wanted to explore whether there was a relationship between the selective pressures that theE. coli core genome has been subjected to and genome expansion due to HGT since an association between purifying selection and genome size has previously been identified for microbial species in general [20].

We performed hierarchical cluster analyses based ondS anddNestimations from all 1729 genes belonging to the E. colicore genome. The results can be seen in Figures 1 and 2 for dS and dN estimations, respectively, and the resulting cluster groups (denoted by different colors in both Figures 1 and 2) indicate a strong association with knownE. coliphylogroups [24-26]. Table 1 contains more information on the differentE. colistrains and the corresponding patho-/phylo-groups resulting from the dS and dNbased cluster analyses.

From the heatmaps in Figures 1 and 2 it can be seen thatdSis considerably higher thandNimplying that the E. colicore genome has been subjected to strong purifying selection [27]. Since the core genome consists of all genes common to all the strains discussed here, these genes are presumably important for the species survival and the removal of fitness-reducing mutations appears to have been of considerable importance for the evolution of the different lineages.

The similar topology of the heatmaps in Figures 1 and 2 points to corresponding differences in dS and dNfor each strain and Figure 3 demonstrates that we found a strong linear association between median- dS and dN values with respect to each strain (β=26.94±0.44, R²~ 0.98,p<0.001). From Table 1, as well as Figures 1 and 2,

(3)

it can be seen that group B1, which includes 9 pathogens and 6 non-pathogens, is closest to group A consisting almost exclusively of non-pathogens (one pathogen and 11 non-pathogens). The predominantly pathogenic groups: B2, D and E cluster together and are further away from groups A and B1. The strong correlation be- tweendSanddNobserved in Figure 3 may indicate that the formation of the different lineages may be of a more

ancient origin since both dN and dS based cluster analyses resulted in cluster groups completely congruent with the establishedE. coliphylogroups [24].

As mentioned above, the type of selective pressures af- fecting genomes can be inferred from the dN/dS ratio.

To examine the selective pressures operating on the differentE. colilineages we used thedS/dNratio instead of dN/dS for clarification [19]. The resulting dS/dN

Figure 1dS-based heatmap.The heatmap demonstrates a hierarchical cluster analysis of estimateddS(the rate of synonymous distributions between taxa) of 1729 core genes from the 53E. coligenomes. The differently colored labels designate phylogroups: D (light green), B2 (red), E (green), B1 (blue), and A (dark blue). Groups D, B2 and E consisted predominantly of pathogens; Group A was almost exclusively non-pathogenic, while Group B1 consisted of a mixture of pathogenic and non-pathogenic strains.

(4)

heatmap can be seen in Figure 4 and shows that al- though phylogroups D, B2 and E cluster together, phylogroup A is divided into two cluster groups one of which is flanked by phylogroup B1. Interestingly, a similar tree topology was observed by Didelot et al. [24] in a cluster analysis based on E. coli non-core gene content, as opposed to the core genomedS/dNratios explored in the present study, which may suggest that the lineages

represented by phylogroups A and B1 have been exposed to similar selective pressures. Indeed, Didelot et al. points out that the frequency of HGT between these two phylogroups is higher than that observed between any of the other E. coliphylogroups. Therefore it is conceivable that the strains in phylogroups A and B1 are often found within geographic proximity and in similar environments [24].

Figure 2dN-based heatmap.The heatmap shows a hierarchical cluster analysis of estimateddN(the rate of non-synonymous distributions between taxa) of 1729 core genes from the 53E. coligenomes. The differently colored labels designate phylogroups: D (light green), B2 (red), E (green), B1 (blue), and A (dark blue). Groups D, B2 and E consisted predominantly of pathogens; Group A was almost exclusively non-pathogenic, while Group B1 consisted of a mixture of pathogenic and non-pathogenic strains.

(5)

Table 1 Information about the differentE. colistrains used in the study

Name Pathogroup Phylogroup

Escherichia coliO7:K1 CE10 ExPEC (neonatal meningitis) D

Escherichia coliIAI39 ExPEC (UropathogenicE. coli(UPEC)) D

Escherichia coliSMS 3-5 Multi-resistant D

Escherichia coliUMN026 ExPEC (UPEC) D

Escherichia coli536 ExPEC (UPEC) B2

Escherichia coliED1A Non-pathogenic B2

Escherichia coliO83:H1 NRG 857C AIEC (adherent-invasive E. coli) B2

Escherichia coliLF82 AIEC B2

Escherichia coliclone D i2 ExPEC (UPEC) B2

Escherichia coliclone D i14 ExPEC (UPEC) B2

Escherichia coliCFT073 ExPEC (UPEC) B2

Escherichia coliABU 83972 ExPEC (UPEC) B2

Escherichia coliUTI89 ExPEC (UPEC) B2

Escherichia coliUM146 AIEC B2

Escherichia coliIHE3034 ExPEC (neonatal meningitis) B2

Escherichia coliAPEC O1 Avian pathogenicE. coli(APEC) B2

Escherichia coliS88 ExPEC (neonatal meningitis) B2

Escherichia coliSE15 Non-pathogenic B2

Escherichia coliNA114 ExPEC (multidrug-resistant UPEC) B2

Escherichia coliE2348_69 O127:H6 EnteropathogenicE. coli(EPEC) B2

Escherichia coliO157:H7 TW14359 Shiga toxin-producingE. coli(STEC/EHEC) E

Escherichia coliO157:H7 EC4115 STEC/EHEC E

Escherichia coliO157:H7 Sakai STEC/EHEC E

Escherichia coliXuzhou21 STEC/EHEC E

Escherichia coliO55:H7 RM12579 Atypical EPEC (aEPEC) E

Escherichia coliO55:H7 CB9615 aEPEC E

Escherichia coliUMNK88 EnterotoxigenicE. coli(ETEC) A

Escherichia coliP12b Non-pathogenic A

Escherichia coliHS Non-pathogenic A

Escherichia coliBL21 DE3 Lab strain–Non-pathogenic A

Escherichia coliB REL606 Lab strain–Non-pathogenic A

Escherichia coliBL21 Gold DE3 pLysS AG Lab strain–Non-pathogenic A

Escherichia coliBW2952 Lab strain–Non-pathogenic A

Escherichia coliK12 substr DH10B Lab strain–Non-pathogenic A

Escherichia coliK12 substr MDS42 Lab strain–Non-pathogenic A

Escherichia coliK12 substr W3110 Lab strain–Non-pathogenic A

Escherichia coliDH1 (AP012030.1) Lab strain–Non-pathogenic A

Escherichia coliDH1 (CP001637.1) Lab strain–Non-pathogenic A

Escherichia coliO104:H4 str. 2009EL-2050 Enteroaggregative–EHEC (EAggEC-EHEC) B1

Escherichia coliO104:H4 str. 2009EL-2071 EAggEC-EHEC B1

Escherichia coliO104:H4 str. 2011C-3493 EAggEC-EHEC B1

Escherichia coli55989 EAggEC B1

Escherichia coliW (CP002185.1) Lab strain B1

Escherichia coliW (CP002967.1) Lab strain B1

(6)

Phylogenetic inferences from themutTgene

The topology of the phylogenies resulting from the dS anddNbased cluster analyses (Figures 1 and 2) are congruent with the tree depicted in Figure 5, based on vari- ants of the mutTgene, some of which are known to be associated with hyper-mutableE. colistrains [23]. TheE.

coli ED1a strain, one of two non-pathogens in phylogroup B2 (see Table 1), cluster outside all groups.

Other genes related to the genomic mutation levels such as mutY, mutL and mutM [28] resulted in trees with topologies similar to the one we obtained with themutT gene. However, these alignments were based on rela- tively large sequences with few mutations resulting in a bootstrap support that was too low for any consistent tree-topology to be inferred. Nevertheless, it is interest- ing to note that the mutT based-tree supported thedN and dS based phylogenies obtained above. This could mean that the different phylogroups have distinct vari- ants of the mutT gene that coincide with both non-

synonymous and synonymous substitution rates in the E. coli core genome. However, our data does not allow any conclusive statements with respect to potential ef- fects ofmutTgenotypes ondN/dSvalues.

Examination of the base composition in theE. colicore genome

As previously mentioned, the selective pressures that the E. colicore genome has been exposed to can be analyzed using relative entropy [13]. The genomic frequencies of codons subjected to strong selective pressures are assumed to be substantially different than the corresponding products of nucleotide frequencies. Conversely, codons exposed to weak selective pressures will presumably have more similar frequencies to the corresponding product of nucleotide frequencies due to mutational bias [13,29]. The relative entropy measure cannot separate between positive- and negative selective pressures associated with dN/dS-based methods. Therefore, with Table 1 Information about the differentE. colistrains used in the study(Continued)

Escherichia coliKO11FL_162099 (CP002516.1) Lab strain B1

Escherichia coliKO11FL_162099 (CP002970.1) Lab strain B1

Escherichia coliSE11 Non pathogenic B1

Escherichia coliIAI1 Non pathogenic B1

Escherichia coliE24377A ETEC B1

Escherichia coliO103:H2 str. 12009 STEC/EHEC B1

Escherichia coliO111:H- str. 11128 STEC/EHEC B1

Escherichia coliO26:H11 str. 11368 STEC/EHEC B1

Escherichia coliAPEC O78 APEC B1

0.0022 0.0024 0.0026 0.0028 0.0030 0.0032

0.0500.0550.0600.0650.0700.075

Strain-wise median dN

Strain-wise median dS

Figure 3Regression plot of strain-wise mediandSanddN.The figure shows mediandSestimates plotted against mediandNestimates for theE. colistrains in the study. The diagonal line designates the estimated regression line. All similar and clonal strains were removed for the regression analysis resulting in a sample size of 36 strains.

(7)

regards to relative entropy, selective pressures will de- note both positive- and negative selective pressures.

We wanted to examine whether we could find base compositional differences between core- and whole genomes and whether properties deduced from the core-genomic base composition could be associated with corresponding whole genome properties. For the following

statistical analyses we removed all strains that are known to be modified clones, or otherwise genetically very similar, to reduce bias. Details about the specific isolates included in these analyses can be found in Additional file 1.

From Figure 6, left panel, it can be seen that relative entropy in the E. coli core genomes was significantly higher than for the corresponding whole genomes (R²~

Escherichia coli O7 K1 CE10 Escherichia coli IAI39 Escherichia coli SMS 3 5 Escherichia coli UMN026 Escherichia coli APEC O1 Escherichia coli IHE3034 Escherichia coli UTI89 Escherichia coli UM146 Escherichia coli CFT073 Escherichia coli clone D i14 Escherichia coli clone D i2 Escherichia coli LF82 Escherichia coli O83 H1 NRG 857C Escherichia coli ED1a Escherichia coli ABU 83972 Escherichia coli NA114 Escherichia coli SE15 Escherichia coli S88 Escherichia coli O127 H6 E2348 69 Escherichia coli 536 Escherichia coli BW2952 Escherichia coli K 12 substr DH10B Escherichia coli K 12 substr MDS42 Escherichia coli K 12 substr W3110 Escherichia coli DH1 Escherichia coli DH1 2 Escherichia coli O55 H7 RM12579 Escherichia coli O55 H7 CB9615 Escherichia coli O157 H7 Sakai Escherichia coli Xuzhou21 Escherichia coli O157 H7 EC4115 Escherichia coli O157 H7 TW14359 Escherichia coli 55989 Escherichia coli O104 H4 2011C 3493 Escherichia coli O104 H4 2009EL 2071 Escherichia coli O104 H4 2009EL 2050 Escherichia coli KO11FL Escherichia coli KO11FL 2 Escherichia coli W Escherichia coli W 2 Escherichia coli B REL606 Escherichia coli BL21 DE3 Escherichia coli P12b Escherichia coli UMNK88 Escherichia coli BL21 Gold DE3 pLysS AG Escherichia coli HS Escherichia coli APEC O78 Escherichia coli SE11 Escherichia coli IAI1 Escherichia coli O111 H 11128 Escherichia coli O26 H11 11368 Escherichia coli E24377A Escherichia coli O103 H2 12009

Escherichia coli O7 K1 CE10 Escherichia coli IAI39 Escherichia coli SMS 3 5 Escherichia coli UMN026 Escherichia coli APEC O1 Escherichia coli IHE3034 Escherichia coli UTI89 Escherichia coli UM146 Escherichia coli CFT073 Escherichia coli clone D i14 Escherichia coli clone D i2 Escherichia coli LF82 Escherichia coli O83 H1 NRG 857C Escherichia coli ED1a Escherichia coli ABU 83972 Escherichia coli NA114 Escherichia coli SE15 Escherichia coli S88 Escherichia coli O127 H6 E2348 69 Escherichia coli 536 Escherichia coli BW2952 Escherichia coli K 12 substr DH10B Escherichia coli K 12 substr MDS42 Escherichia coli K 12 substr W3110 Escherichia coli DH1 Escherichia coli DH1 2 Escherichia coli O55 H7 RM12579 Escherichia coli O55 H7 CB9615 Escherichia coli O157 H7 Sakai Escherichia coli Xuzhou21 Escherichia coli O157 H7 EC4115 Escherichia coli O157 H7 TW14359 Escherichia coli 55989 Escherichia coli O104 H4 2011C 3493 Escherichia coli O104 H4 2009EL 2071 Escherichia coli O104 H4 2009EL 2050 Escherichia coli KO11FL Escherichia coli KO11FL 2 Escherichia coli W Escherichia coli W 2 Escherichia coli B REL606 Escherichia coli BL21 DE3 Escherichia coli P12b Escherichia coli UMNK88 Escherichia coli BL21 Gold DE3 pLysS AG Escherichia coli HS

Escherichia coli APEC O78 Escherichia coli SE11 Escherichia coli IAI1 Escherichia coli O111 H 11128 Escherichia coli O26 H11 11368 Escherichia coli E24377A Escherichia coli O103 H2 12009

Value

5 10 15 20 25

02004006008001000

Color Key and Histogram

Count

Figure 4dS/dN-based heatmap.The heatmap demonstrates a hierarchical cluster analysis of estimateddS/dN(the rate of synonymous to non-synonymous substitutions between taxa) of 1729 core genes from the 53E. coligenomes. The differently colored labels designate phylogroups: D (light green), B2 (red), E (green), B1 (blue), and A (dark blue). Groups D, B2 and E consisted predominantly of pathogens; Group A was almost exclusively non-pathogenic, while Group B1 consisted of a mixture of pathogenic and non-pathogenic strains. The horizontal axis of the color key legend indicates multiples ofdStodN, where values close to 1 designates neutrality of selection.

(8)

Figure 5(See legend on next page.)

(9)

0.98, p<0.001). This indicates that the core genome has been subjected to substantially stronger selective pressures than the non-core part of the genome. As previously shown (Figures 3 and 4) the dS estimates were substantially larger than dN estimates, which suggest strong selection of the purifying type. Additionally, it can be seen from Figure 6, right panel, that the core genome was significantly less AT rich (R²~0.98, p<

0.001) than the rest of the genome. This finding has also been linked to increased selection in other studies al- though of an unspecified type [30]. In the instance discussed here, relating to the E. coli core genome, there seems to be a connection between purifying selection and decreased AT content.

We also examined whether there was any association between core- and whole genome levels of both relative entropy and AT content, which could point towards similar selective pressures operating on the core- and whole genome. Our findings indicate no correlation between core- and whole genome relative entropy (p~ 0.26) suggesting that selective pressures operating on the core genome are most likely unrelated to selective forces effective on the rest of the genome. Core- and whole genome AT content may be negatively correlated (p~ 0.058), albeit weakly. Since this negative correlation was produced with robust regression, the result was some- what surprising. An extra generalized additive model (GAM) [31] was therefore fitted, since such models are more capable of modeling non-linear relations, but the association between core- and whole genome AT content was no longer statistically significant (p~0.23).

Hence, these results seem to suggest that different selective pressures form the E. coli core and non-core genomes.

The effect of selective pressures onE. coligenome size Since we have explored how selective pressures operate on whole and core genomes using bothdN/dSand relative entropy, we have the necessary results to examine whether selective forces are associated with genome size in E. coli. Previously, a negative correlation between E.

coli strains and relative entropy was established which may give the impression that an increase in genome size is a consequence of reduced selective pressures. How- ever, foreign DNA sequences incorporated into a host genome typically have lower relative entropy. Accord- ingly, the negative association between genome size and relative entropy may be due to the lower relative entropy of the foreign DNA [11]. In Figure 7, it can be seen that the negative association between relative entropy and genome size still holds (R²=0.72,p<0.001). In addition, we also found a significant association between the pathogenicity status of the E. coli strains and genome size (p~0.001), AT content (p<0.001), whole genome relative entropy (p<0.001), as well as size of predicted HGT (p~0.005). Hence, we find a clear association between the acquisition of virulence factors and DNA uptake as well as genome size, suggesting that the pathogenic potential of E. coli is associated with DNA uptake. However, we could not find any association between core genome relative entropy on one hand, and genome size (p~0.98) or predicted GI size (p~0.37) on

(See figure on previous page.)

Figure 5mutTbased phylogenic tree.The phylogenic tree is based on alignments of themutTgene found in the core genome of all 53E. coli strain. The numbers close to the branches represent bootstrap support. The differently colored labels designate phylogroups: D (light green), B2 (red), E (green), B1 (dark blue), and A (blue). Groups D, B2 and E consisted predominantly of pathogens; Group A was almost exclusively non- pathogenic, while Group B1 consisted of a mixture of pathogenic and non-pathogenic strains.

Figure 6Core genome relative entropy and AT content.The figure consists of two panels of boxplots displaying the difference between core- and whole genome relative entropy (left), and core- and whole genome fraction of AT content (right) in all 53E. colistrains.

(10)

the other. Thus, the lack of correlation between core- and whole genome relative entropy in E. coli seems to suggest that the acquisition of foreign DNA, and virulence factors in particular, is not a consequence of increased selective pressures operating on the genome, at least not on a larger time scale. In this respect, it is in- teresting that Shigellaspp., which is more or less a distinct lineage of E. coli, has been shown to obtain its pathogenic traits through reductive evolution and re- laxed selective pressures [9]. It should also be noted that due to strong bi-modality in the strain-baseddN/dSesti- mations no reliable statistical tests could be performed between group-wise median- dNand dS and any corresponding genomic property such as AT content, genome size and relative entropy. Plotting both dN and dS or dN/dS values against the genomic properties discussed

above did not reveal any indications of potential trends and were therefore excluded.

Genome expansion and genome reduction inE. coli To our knowledge, there are no previous studies of evolutionary forces responsible for genome expansion due to HGT. A recent study discusses evolutionary aspects of recombination in recently emerged clonal Staphylo- coccus aureus and Clostridium botulinum isolates by examining dN and dS of SNPs in core-, non-core- and recombined DNA, but does not deal with genome expansion as such [32]. Our findings suggest that the E.

coli core genome has been subjected to substantial selective pressures over time compared to the genome as a whole. The linear association between median dS and dN estimations for all strains indicates that purifying

Figure 7Statistical analyses of genomic properties in 53E. colistrains.The figure consists of 4 panels showing different associations between selected genomic properties of pathogenic (red dots) and non-pathogenic (green dots)E. colistrains. The blue line denotes the estimated regression line, which was significant for all panels (p<0.05). Top left panel shows genomic AT content versus chromosome size, while the top right panel depicts estimated HGT size versus genomic AT content. Bottom right panel designates whole genome relative entropy versus genome size, and bottom left panel shows whole genome relative entropy plotted against genomic fraction of AT.

(11)

selection has been directingE. colilineage evolution and the comparably low rates of non-synonymous substitutions (dN) may indicate that the core genome has remained intact for a longer time span [19]. It should also be noted that all E. coli strains examined in this study are publicly available whole genome sequences, and the fact that they have been selected for sequencing may be due to some special traits not commonly observed in wild-typeE. coli.

Conclusions

Our results support previous studies arguing that acquisition of traits through HGT may be a consequence of “spandrel”-like evolutionary processes [33] where the functions of acquired genes are formed through positive selection over time or eventually lost [34,35]. Hence, increase of selective pressures appears not to be the driv- ing force behind chromosome expansion and acquisition of new traits in E. coli, which is consistent with related findings, also those pointing to an analogous evolutionary trail for gene duplications [36,37]. PathogenicE. coli may thus have evolved as a consequence of a hostile environment, where virulence associated genes are abun- dant. We anticipate that a lot more will be said about this in the future.

Methods

59 E. coli genomes, with their annotated coding genes and corresponding proteins, were downloaded from NCBI/Genbank [10]. In six of the genomes we discov- ered a lack of correspondence between the coding genes and their listed proteins, and these six genomes were discarded from the downstream analysis. See Additional file 1 for more information on the differentE. colistrains used in the study. Genomic properties such as genome size, AT content and relative entropy were estimated using in-house scripts that are available upon request.

All statistical analyses were performed with R [38].

Extraction of the core genome

All proteins from every genome were BLASTed (blastp) [39] against all proteins of all other genomes, and a distance was computed between all protein pairs as described in [40]. Based on these distances, proteins were clustered using hierarchical clustering with complete linkage, and divided into clusters by cutting the dendro- gram tree at distance 0,1. Loosely speaking, this means any two proteins in the same cluster share 90% similarity. Using this rather strict cutoff resulted in a set of 1729 core clusters,i.e. clusters with at least one protein for each of the 53 genomes in the study. Next, paralogs were eliminated from each cluster using the same procedure as described in [40]. The 53 orthologs in each cluster were aligned using the MCoffee software [41]

and the protein-alignments were back-translated to DNA-alignments using the TranslatorX software [42].

Estimation of core genomedNanddS

To calculate dN and dS we followed the method first described by Li et al. [43]. Briefly, we sequentially performed gene-wise multiple alignments as described above on all 1729 core genes from the 53 strains used in the study. The alignment ends were trimmed manually so that the sequences within the alignments were all of the same length. We then used the seqinr package [44]

in R to read the alignments, and subsequently calculated gene-by-strain dN and dS values using the kaks() com- mand. For strain-wide assessments, the dNanddS estimates for individual genes were added up and weighted according to gene length.dNanddSfor each strain were based on the median from all versus all comparisons.

Due to the bimodal distribution of the core genome- baseddNanddSvalues, heatmaps based on hierarchical clustering with Euclidean distance were created for each of the dS,dNand dS/dNestimated distance matrices so that potential differences between the strains could be examined. These matrices are included in an R-file (see Additional file 2).

Relative entropy

Relative entropy measures the Kullback–Leibler diver- gence between observed and expected codon frequencies in coding regions [13],i.e.:

DK Li¼X

XY Z

FiðXY ZÞlog₂ FiðXY ZÞ Fið ÞFX ið ÞFY ið ÞZ

where the sum is taken over all 64 possible codons XYZconsisting of nucleotidesX,YandZ, respectively.Fi

is a function returning the frequency of codon XYZ, or nucleotides X,YandZ, from genomei. A lowDKLindi- cates that the observed codon frequencies are, on average, similar to the individual nucleotide frequencies, signifying that the codon frequencies are more random, presumably due to relaxation of the selective forces operating on the genome [13].

ThemutTbased phylogenetic tree

The phylogenic tree based on themutTgene was created, after sequence alignment, using maximum likelihood estimation and 500 bootstraps using the package Mega 6 [45].

Based on statistical analyses carried out with the “Ape”

package in R [46], we found that a nucleotide substitution model based on the Tamura-Nei 93 model [47], which assumes equal transversion rates and unequal transition rates, with Gamma-distributed among-site rate variation was the model with the lowest AIC [48] and therefore chosen. The Gamma distribution was discretized into 6

(12)

categories, which is the default number of categories;

changes to this number did not notably affect the tree topology. The DNA sequences which themutTbased phylogenetic tree is based on are included in FASTA-format (Additional file 3).

HGT predictions

HGT predictions based on the SIGI-HMM method were downloaded and computed using the Islandviewerweb- page [49-51].

Statistical analyses

The statistical analyses were carried out using an itera- tive robust MM-type regression (M-type estimator with Tukey’s biweight and initial coefficient estimates provided from an S-type estimator) [52] with significance estimates (p-values) obtained fromt-statistics. All similar strains were discarded before these statistical analyses so that the sample size was reduced to 36 strains (see Additional file 4 and Additional file 5). Robust regression was used where there were several outlying resid- uals resulting in moderately skewed distributions, otherwise standard ordinary least squares regression was used, which additionally includes a goodness-of-fit esti- mate (R²). The association between core- and whole genome AT content was also tested using a generalized additive model (GAM), where the predictor (whole genome AT content) was modeled using a spline-function [53]. Additional file 5 contains all estimates resulting from the statistical analyses.

Additional files

Additional file 1:An Excel file containing information about the strains used in the study.

Additional file 2:An R-file with the dN/dS estimates used in the cluster analyses.

Additional file 3:FASTA file with aligned sequences used to make mutT-based tree.

Additional file 4:An Excel file with data used for regression analyses.

Additional file 5:An Excel file containing data from the regression analyses.

Competing interests

The authors declare that they have no competing interests.

Authors’contributions

JB: Designed the study, performed analyses, wrote the paper. OB: Carried out dS/dN calculations. CS:E. colibased analyses. LS: Computed theE. colicore genome. OB, CS and LS all contributed to the writing of the manuscript. All authors have read and approved this submission.

Acknowledgements

JB was supported by Norwegian Institute of Public Health, CS by The Norwegian Veterinary Institute. OB and LS were both funded by The Norwegian University of Life Sciences. We thank Dr. Christine L. Parr for help with language and grammar.

Author details

1Division of Epidemiology, Norwegian Institute of Public Health, Marcus Thranes gate 6, P.O. Box 4404, Oslo 0403, Norway.²Epi-Centre, Department of Food-Safety and Infection Biology, Norwegian University of Life Sciences, Ullevålsveien 72, P.O. Box 8146 Dep, Oslo NO-0033, Norway.³Norwegian Veterinary Institute, P.O.Box 750 Sentrum, N-0106 Oslo, Norway.⁴Department of Chemistry, Biotechnology and Food Sciences, Norwegian University of Life Sciences, Ås, Norway.

Received: 24 March 2014 Accepted: 29 September 2014 Published: 9 October 2014

References

1. Fournier PE, Drancourt M, Raoult D:Bacterial genome sequencing and its use in infectious diseases.Lancet Infect Dis2007,7(11):711–723.

2. Pallen MJ, Wren BW:Bacterial pathogenomics.Nature2007,449(7164):835–842.

3. McCutcheon JP, Moran NA:Extreme genome reduction in symbiotic bacteria.Nat Rev Microbiol2012,10(1):13–26.

4. Moran NA:Microbial minimalism: genome reduction in bacterial pathogens.Cell2002,108(5):583–586.

5. Moran NA, McLaughlin HJ, Sorek R:The dynamics and time scale of ongoing genomic erosion in symbiotic bacteria.Science (New York, NY) 2009,323(5912):379–382.

6. Toh H, Weiss BL, Perkin SA, Yamashita A, Oshima K, Hattori M, Aksoy S:

Massive genome erosion and functional adaptations provide insights into the symbiotic lifestyle of Sodalis glossinidius in the tsetse host.

Genome Res2006,16(2):149–156.

7. Wernegreen JJ:Reduced selective constraint in endosymbionts: elevation in radical amino acid replacements occurs genome-wide.PLoS One2011, 6(12):e28905.

8. Yus E, Maier T, Michalodimitrakis K, Van Noort V, Yamada T, Chen WH, Wodke JA, Guell M, Martinez S, Bourgeois R, Kühner S, Raineri E, Letunic I, Kalinina OV, Rode M, Herrmann R, Gutiérrez-Gallego R, Russell RB, Gavin AC, Bork P, Serrano L:Impact of genome reduction on bacterial metabolism and its regulation.Science (New York, NY)2009,326(5957):1263–1268.

9. Hershberg R, Tang H, Petrov DA:Reduced selection leads to accelerated gene loss in Shigella.Genome Biol2007,8(8):R164.

10. Benson DA, Clark K, Karsch-Mizrachi I, Lipman DJ, Ostell J, Sayers EW:Gen- Bank.Nucleic Acids Res2014,42(1):D32–D37.

11. Bohlin J, Sekse C, Skjerve E, Brynildsrud O:Positive correlations between genomic% AT and genome size within strains of bacterial species.

Environ Microbiol Rep2014,6(3):278–286.

12. Mitchell D:GC content and genome length in Chargaff compliant genomes.Biochem Biophys Res Commun2007,353(0006–291; 1):207–210.

13. Bohlin J, Van Passel MW, Snipen L, Kristoffersen AB, Ussery D, Hardy SP:

Relative entropy differences in bacterial chromosomes, plasmids, phages and genomic islands.BMC Genomics2012,13:66-2164-2113-2166.

14. Cover TM, Thomas JA:Elements of Information Theory.New York: John Wiley

& Sons, Inc; 1991.

15. Bohlin J, Brynildsrud O, Vesth T, Skjerve E, Ussery DW:Amino acid usage is asymmetrically biased in AT- and GC-rich microbial genomes.PLoS One 2013,8(7):e69878.

16. Bohlin J, Skjerve E, Ussery DW:Investigations of oligonucleotide usage variance within and between prokaryotes.PLoS Comput Biol2008, 4(4):e1000057.

17. Hershberg R, Petrov DA:Evidence that mutation is universally biased towards AT in bacteria.PLoS Genet2010,6(9):e1001115.

18. Rocha EP, Feil EJ:Mutational patterns cannot explain genome composition: Are there any neutral sites in the genomes of bacteria?

PLoS Genet2010,6(9):e1001104.

19. Rocha EP, Smith JM, Hurst LD, Holden MT, Cooper JE, Smith NH, Feil EJ:

Comparisons of dN/dS are time dependent for closely related bacterial genomes.J Theor Biol2006,239(2):226–235.

20. Novichkov PS, Wolf YI, Dubchak I, Koonin EV:Trends in prokaryotic evolution revealed by comparison of closely related bacterial and archaeal genomes.J Bacteriol2009,191(1):65–73.

21. Touchon M, Hoede C, Tenaillon O, Barbe V, Baeriswyl S, Bidet P, Bingen E, Bonacorsi S, Bouchier C, Bouvet O, Calteau A, Chiapello H, Clermont O, Cruveiller S, Danchin A, Diard M, Dossat C, Karoui ME, Frapy E, Garry L, Ghigo JM, Gilles AM, Johnson J, Le Bouguénec C, Lescat M, Mangenot S, Martinez-Jéhanne V, Matic I, Nassif X, Oztas S,et al:Organised genome

(13)

dynamics in the Escherichia coli species results in highly diverse adaptive paths.PLoS Genet2009,5(1):e1000344.

22. Van Passel MW, Marri PR, Ochman H:The emergence and fate of horizontally acquired genes in Escherichia coli.PLoS Comput Biol2008, 4(4):e1000059.

23. Wielgoss S, Barrick JE, Tenaillon O, Wiser MJ, Dittmar WJ, Cruveiller S, Chane-Woon-Ming B, Medigue C, Lenski RE, Schneider D:Mutation rate dynamics in a bacterial population reflect tension between adaptation and genetic load.Proc Natl Acad Sci U S A2013,110(1):222–227.

24. Didelot X, Meric G, Falush D, Darling AE:Impact of homologous and non- homologous recombination in the genomic evolution of Escherichia coli.

BMC Genomics2012,13:256.

25. Monk JM, Charusanti P, Aziz RK, Lerman JA, Premyodhin N, Orth JD, Feist AM, Palsson BO:Genome-scale metabolic reconstructions of multiple Escherichia coli strains highlight strain-specific adaptations to nutritional environments.Proc Natl Acad Sci U S A2013,110(50):20338–20343.

26. Reeves PR, Liu B, Zhou ZM, Li D, Guo D, Ren Y, Clabots C, Lan RT, Johnson JR, Wang L:Rates of Mutation and Host Transmission for an Escherichia coli Clone over 3 Years.Plos One2011,6(10):e26907.

27. Balbi KJ, Feil EJ:The rise and fall of deleterious mutation.Res Microbiol 2007,158(10):779–786.

28. Garcia-Gonzalez A, Rivera-Rivera RJ, Massey SE:The Presence of the DNA Repair Genes mutM, mutY, mutL, and mutS is Related to Proteome Size in Bacterial Genomes.Front Genet2012,3:3.

29. Chen SL, Lee W, Hottes AK, Shapiro L, McAdams HH:Codon usage between genomes is constrained by genome-wide mutational processes.

Proc Natl Acad Sci U S A2004,101(10):3480–3485.

30. Hildebrand F, Meyer A, Eyre-Walker A:Evidence of selection upon genomic GC-content in bacteria.PLoS Genet2010,6(9):e1001107.

31. Hastie TJ, Tibshirani RJ:Generalized additive models.New York: Chapman and Hall/CRC Press; 1990.

32. Castillo-Ramirez S, Harris SR, Holden MT, He M, Parkhill J, Bentley SD, Feil EJ:

The impact of recombination on dN/dS within recently emerged bacterial clones.PLoS Pathog2011,7(7):e1002129.

33. Fall S, Mercier A, Bertolla F, Calteau A, Gueguen L, Perriere G, Vogel TM, Simonet P:Horizontal gene transfer regulation in bacteria as a "spandrel"

of DNA repair mechanisms.PLoS One2007,2(10):e1055.

34. Chattopadhyay S, Weissman SJ, Minin VN, Russo TA, Dykhuizen DE, Sokurenko EV:High frequency of hotspot mutations in core genes of Escherichia coli due to short-term positive selection.Proc Natl Acad Sci U S A2009, 106(30):12412–12417.

35. Treangen TJ, Rocha EP:Horizontal transfer, not duplication, drives the expansion of protein families in prokaryotes.PLoS Genet2011, 7(1):e1001284.

36. Kondrashov FA:Gene duplication as a mechanism of genomic adaptation to a changing environment.Proc Biol Sci2012,279(1749):5048–5057.

37. Paauw A, Leverstein-van Hall MA, Verhoef J, Fluit AC:Evolution in quantum leaps: multiple combinatorial transfers of HPI and other genetic modules in Enterobacteriaceae.PLoS One2010,5(1):e8662.

38. R Core Team:R: A language and environment for statistical computing.; 2012.

39. Altschul SF, Gish W, Miller W, Myers EW, Lipman DJ:Basic local alignment search tool.J Mol Biol1990,215(3):403–410.

40. Snipen L, Wassenaar TM, Altermann E, Olson J, Kathariou S, Lagesen K, Takamiya M, Knochel S, Ussery DW, Meinersmann RJ:Analysis of evolutionary patterns of genes in Campylobacter jejuni and C. coli.

Microb Inform Exp2012,2(1):8.

41. Wallace IM, O'Sullivan O, Higgins DG, Notredame C:M-Coffee: combining multiple sequence alignment methods with T-Coffee.Nucleic Acids Res 2006,34(6):1692–1699.

42. Abascal F, Zardoya R, Telford MJ:TranslatorX: multiple alignment of nucleotide sequences guided by amino acid translations.Nucleic Acids Res2010,38(Web Server issue):W7–W13.

43. Li WH, Wu CI, Luo CC:A new method for estimating synonymous and nonsynonymous rates of nucleotide substitution considering the relative likelihood of nucleotide and codon changes.Mol Biol Evol1985, 2(2):150–174.

44. Charif D, Thioulouse J, Lobry JR, Perriere G:Online synonymous codon usage analyses with the ade4 and seqinR packages.Bioinformatics2005, 21(4):545–547.

45. Tamura K, Stecher G, Peterson D, Filipski A, Kumar S:MEGA6: Molecular Evolutionary Genetics Analysis Version 6.0.Mol Biol Evol2013, 30(12):2725–2729.

46. Paradis E, Claude J, Strimmer K:APE: analyses of phylogenetics and evolution in R language.Bioinformatics2004,20(2):289–290.

47. Tamura K, Nei M:Estimation of the number of nucleotide substitutions in the control region of mitochondrial DNA in humans and chimpanzees.

Mol Biol Evol1993,10(3):512–526.

48. Akaike H:A New Look at the Statistical Model Identification.IEEE Trans Auto Contrl1974,AC-19(6):716–723.

49. Langille MG, Brinkman FS:IslandViewer: an integrated interface for computational identification and visualization of genomic islands.

Bioinformatics (Oxford, England)2009,25(5):664–665.

50. Langille MG, Hsiao WW, Brinkman FS:Detecting genomic islands using bioinformatics approaches.Nat Rev Microbiol2010,8(5):373–382.

51. Waack S, Keller O, Asper R, Brodag T, Damm C, Fricke WF, Surovcik K, Meinicke P, Merkl R:Score-based prediction of genomic islands in prokaryotic genomes using hidden Markov models.BMC Bioinformatics 2006,7:142.

52. Yohai VJ, Stahel WA, Zamar RH:A procedure for robust estimation and inference in linear regression. Directions in robust statistics and diagnostics.

New York: Springer; 1991:365–374.

53. Wood SN:Generalized Additive Models: An Introduction with R.Boca Raton:

Chapman & Hall/CRC Press; 2006.

doi:10.1186/1471-2164-15-882

Cite this article as:Bohlinet al.:An evolutionary analysis of genome expansion and pathogenicity inEscherichia coli.BMC Genomics 201415:882.

Submit your next manuscript to BioMed Central and take full advantage of:

• Convenient online submission

• Thorough peer review

• No space constraints or color ﬁgure charges

• Immediate publication on acceptance

• Inclusion in PubMed, CAS, Scopus and Google Scholar

• Research which is freely available for redistribution

Submit your manuscript at www.biomedcentral.com/submit
