The effect of a biochar temperature series on denitrification: which biochar properties matter?

(1)

Contents lists available atScienceDirect

Soil Biology and Biochemistry

journal homepage:www.elsevier.com/locate/soilbio

The e ﬀ ect of a biochar temperature series on denitri ﬁ cation: which biochar properties matter?

Simon Weldon

^a,c,∗

, Daniel P. Rasse

^a

, Alice Budai

^a

, Oliver Tomic

^b

, Peter Dörsch

^c

aDepartment of Soil Quality and Climate Change, Norwegian Institute of Bioeconomy Research, NIBO, Ås, Norway

bFaculty of Science and Technology, Norwegian University of Life Sciences, NMBU, Ås, Norway

cFaculty of Environmental Sciences and Natural Resource Management, Norwegian University of Life Sciences, NMBU, Ås, Norway

A R T I C L E I N F O

Keywords:

Biochar N2O NO Denitriﬁcation GHG mitigation Biochar properties

A B S T R A C T

Biochar has been shown to reduce nitrous oxide (N₂O) emissions from soils, but the effect is highly variable across studies and the mechanisms are under debate. To improve our mechanistic understanding of biochar effects on N2O emission, we monitored kinetics of NO, N2O and N2accumulation in anoxic slurries of a peat and a mineral soil, spiked with nitrate and amended with feedstock dried at 105 °C and biochar produced at 372, 416, 562 and 796 °C atfive different doses. Both soils accumulated consistently less N2O and NO in the presence of high-temperature chars (BC562 and BC796), which stimulated reduction of denitrification intermediates to N₂, particularly in the acid peat. This effect appeared to be strongly linked to the degree of biochar carbonisation as predicted by the H:C ratio of the char. In addition, biochar surface area and pH were identified as important factors, whereas ash content and CEC played a minor role. At low pyrolysis temperature, the biochar effect was soil dependent, suppressing N₂O accumulation in the mineral soil, but enhancing it in the peat soil. This contrast was likely due to the labile carbon content of low temperature chars, which contributed to immobilise N in the mineral soil, but stimulated denitrification and N2O emission in the peat soil. We conclude that biochar with a high degree of carbonisation, high pH and high surface area is best suited to supress N₂O emission from denitrification, while low temperature chars risk supporting incomplete denitrification.

1. Introduction

Biochar has a signiﬁcant potential to mitigate greenhouse gas emissions from agriculture, both by storing carbon in soils (Lehmann et al., 2006;Lorenz and Lal, 2014) and through mitigating N2O emissions (Cayuela et al., 2014;He et al., 2017;Grutzmacher et al., 2018).

In a recent meta-analysis, Borchard et al. (2019)reported an average reduction of N2O emission by biochar of 38 percent. This is a notable reduction in the estimated effect strength of 54 percent from a previous meta-analysis (Cayuela et al., 2014) and highlights the variability in biochar effects on N2O emissions from study to study. Some studies do notfind any effect (Zheng et al., 2012;Wang et al., 2013;Case et al., 2014;Van Zwieten et al., 2014) while others report stimulation of N2O emissions (Yanai et al., 2007;Clough et al., 2010;Shen et al., 2014).

Despite a significant body of research on the N2O suppressing effect of biochar, it is still not possible to predict whether the addition of a specific biochar will have a measurable effect on soil N2O emissions for a given combination of soil type, biochar feedstock, production method and dose. Variable effects may be expected, given the fact that N2O is

produced by a number of abiotic and biotic reactions in soil, with microbial nitrification and denitrification considered to be the most significant ones (Firestone and Davidson, 1989). Both processes respond differently to changes in abiotic factors brought about by biochar in soil, and it is unlikely that the N2O supressing effect is governed by any singular property of the biochar. Here, we focus on denitrification and study in detail how biochar influences the microbial turnover of NO and N2O under anaerobic conditions.

Many studies examining the N2O suppressing eﬀect of biochar have focused on N2O emissions (Jia et al., 2012; Fungo et al., 2014;

Verhoeven and Six, 2014;Edwards et al., 2018), while relatively few have addressed underlying processes (Ameloot et al., 2013;Cornelissen et al., 2013;Nelissen et al., 2014;Obia et al., 2015;Harter et al., 2017;

Chen et al., 2018). Among the latter, studies addressing the enzymatic reduction of N2O to N2 in denitriﬁcation are of particular interest.

Biochar has been implicated to act directly as a redox mediator supporting the reduction of N2O to N2in denitriﬁcation (Cayuela et al., 2013) or by changing the denitrifying community composition to be more eﬃcient in reducing N2O (Van Zwieten et al., 2014;Harter et al.,

https://doi.org/10.1016/j.soilbio.2019.04.018

Received 18 December 2018; Received in revised form 16 April 2019; Accepted 25 April 2019

∗Corresponding author. Department of Soil Quality and Climate Change, Norwegian Institute of Bioeconomy Research, NIBO, Ås, Norway.

E-mail address:simon.weldon@nibio.no(S. Weldon).

Soil Biology and Biochemistry 135 (2019) 173–183

Available online 03 May 2019

T

(2)

2017). Others have highlighted the alkalizing eﬀect of biochar in acid soils as a possible explanation for increased microbial N2O reduction in acidic soils (Obia et al., 2015;Harter et al., 2016).

Providing evidence for complete denitrification in soil is not trivial, because quantification of N2 production requires sophisticated incubation setups or stable isotope approaches. Recent studies have in- ferred the functioning of denitrification from copy numbers of key denitrification gene transcripts (Xu et al., 2012; Harter et al., 2017), documenting increased ratios ofnosZ(coding for N2O reductase) over nirKand/ornirStranscripts (coding for NO2−reductase), which was taken as evidence for biochar promoting N2O reducing microorganisms.

However, primer-based studies into the composition of actively denitrifying communities may be biased (Roco et al., 2017) and biochar mediated changes in the taxonomic composition of denitrifier communities require time to manifest (Brenzinger et al., 2015). By contrast, monitoring of the gaseous denitrification products can quantify direct effects of biochar on N2O turnover by denitrification and provide va- luable information about the stoichiometry of denitrification products (Cayuela et al., 2013;Obia et al., 2015;Chen et al., 2018).

Nitric oxide (NO), the precursor of N2O in denitrification, is rarely studied in the context of biochar research (Nelissen et al., 2014;Obia et al., 2015). NO is a significant atmospheric pollutant (Molina-Herrera et al., 2017;Pourhashem et al., 2017), but also an important signalling molecule during the early induction of denitrification (Nadeem et al., 2013). Therefore, studying denitrification kinetics, i.e. the sequential production and consumption of NO and N2O and the accumulation of thefinal product N2in the presence and absence of biochar may shed light on the underlying biochar-driven mechanisms suppressing denitrification-induced N2O production.

Biochars comprise a wide array of structural and chemical properties, all of which may aﬀect the redox reactions involved in deni- triﬁcation. The physico-chemical properties of biochar are a function of feedstock type, pyrolysis method and pyrolysis temperature (Antal and Gronli, 2003;Kloss et al., 2012). Increasing pyrolysis temperature de- creases volatile matter and increases the relative content of C to O and H in biochar. Indices such as a H:C ratio of < 0.3 of biochar have been suggested as proxies for N2O suppressing properties (Cayuela et al., 2015), but little is known about the actual properties responsible or their modes of action. Increasing pyrolysis temperature also increases ash content and aromaticity, while surface area and surface function- ality, i.e. the capacity to donate and receive electrons, increase non- linearly with pyrolysis temperature (Budai et al., 2014;Klüpfel et al., 2014a). This suggests that thresholds in pyrolysis temperature with respect to N2O suppression may exist.

Biochar properties may aﬀect denitriﬁcation in various ways;

through sorption or desorption of NO2−or NO3−(Yao et al., 2012;

Hagemann et al., 2017), DOC (Lu et al., 2014) and gaseous intermediates (Cornelissen et al., 2013), through increasing the activity and/

or completeness of denitriﬁcation by pH increase (Wijler and Delwiche, 1954;Bakken et al., 2012) or by redox mediation (Cayuela et al., 2013;

Klüpfel et al., 2014a;Chen et al., 2018). However, the effects may be antagonistic, as more complete denitrification may go along with increased denitrification, thus potentially nulling out N2O suppression.

The present study focuses on the effect of biochar on NO and N2O turnover in denitrification under controlled conditions, with biochar treatment temperature, dose and soil type being the main variables. We used batch incubations of constantly stirred soil slurries in a helium atmosphere to minimize matrix effects and monitored the accumulation of gaseous denitrification products (N2, N2O, NO, CO2) at high temporal resolution. Our objective was to elucidate how the N2O suppressive effect of a corncob biochar, in two contrasting soils (a mineral soil and a peat), depends on its physico-chemical properties as affected by highest treatment temperature during pyrolysis.

2. Materials and methods 2.1. Biochars and soils

Samples of top-soils (0–10 cm) were collected from a cultivated peatland and an acid mineral soil, classiﬁed as Hemic Histosol and Umbric Epistagnic Albeluvisol (WRB), respectively. Soils were stored at 4 °C until experimentation and sieved to 2 mm before incubation.

Table 1gives key properties of the soils.

A series of biochars was prepared fromZea mays corncobs using slow pyrolysis in N2atmosphere. Methods of preparation and storage are given inBudai et al. (2014). In brief, a heating rate of 2.5 °C min⁻¹ was used, and highest treatment temperatures (HTT) were measured within the 1 L retort. HTTs of samples selected for this study were 105, 372, 416, 562 and 769 °C, hereafter referred to as FS105, BC372, BC416, BC562 and BC796. The sequence was chosen to span a wide range of biochar key properties such as pH, CEC, volatile matter (VM) and ash content. The biochars were crushed through a 2 mm sieve and stored dry.

Table 2lists the biochar properties. pH(H2O)ranged from 8.8 to 10.1 and ash content from 2.1 to 4.5% w/w. Volatile matter content ranged from 6.9 to 40.5% and the C content from 71.9 to 91.5% w/w. Less than 0.1% w/w was readily biodegradable in soil regardless of pyrolysis temperature, as determined in a one-year incubation study (Budai et al., 2016). The yearly mineralization rate of the remaining C pool of the biochars was approximately 0.005 y⁻¹. Where possible, variables were scaled to the biochar dose added. Where this was not possible, e.g. for elemental ratios, properties are given as single value.

2.2. Experimental design

Denitrification kinetics were studied in two separate incubation experiments, one with each soil type. Each soil was incubated with multiple combinations of HTT and dose, each unique combination being represented by one incubation flask on which time-repeated measures were carried out to determine denitrification kinetics and derive denitrification parameters. Non-amended soils where incubated in triplicate to judge the extent of variability in N gas kinetics in our experimental set up. The statistical power of the experiment resides in the controlled nature of our incubations (see ch. 2.3) which typically guarantees high reproducibility between replicates (e.g.Obia et al., 2015). Soils were homogenised and incubated as constantly stirred, temperature controlled slurries to reduce matrix effects and ensure homogeneity. Oxygen was removed effectively (data not shown) by repeated evacuation and He-washing prior to each experiment, creating a highly controlled experimental system for testing the effect of incre- mental biochar HTTs and doses in two contrasting soils. This design was chosen to focus on relative changes in denitrification responses induced by linear changes in biochar properties. Our cross-validated partial least squares regression (PLSR) model confirmed that there was a high Table 1

Key soil properties. (Mean and Standard deviation n = 3).

Peat Mineral soil

pH(H2O) 5.08 ( ± 0.00) 5.86 ( ± 0.04)

C % 53.00 ( ± 0.10) 2.83 ( ± 0.01)

N % 1.79 ( ± 0.04) 0.29 ( ± 0.00)

C:N 29.53 ( ± 0.70) 9.87 ( ± 0.21)

H⁺(mmol/kg) 689.73 ( ± 9.43) 93.27 ( ± 0.90)

Ca (mmol/kg) 314.40 ( ± 5.06) 44.69 ( ± 0.68)

K (mmol/kg) 7.91 ( ± 0.17) 2.80 ( ± 0.03)

Mg (mmol/kg) 68.35 ( ± 0.98) 2.34 ( ± 0.03)

Mn (mmol/kg) 0.09 ( ± 0.00) 0.11 ( ± 0.00)

Na (mmol/kg) 16.75 ( ± 0.14) 0.75 ( ± 0.01)

CEC (cmol/kg) 1480.10 ( ± 21.04) 191.08 ( ± 2.35)

Base saturation (%) 53.38 ( ± 0.20) 51.07 ( ± 0.16)

(3)

degree of predictability in denitriﬁcation response by both dose and biochar HTT.

2.3. Denitriﬁcation kinetics

Soil-biochar mixtures were incubated as continuously stirred anoxic slurries in 120 ml serum flasks. Slurries were chosen to ensure full mixing of biochars with the soil, to minimize diffusional constraints and to aid equilibration of gasses between the liquid and the gaseous phase (i.e. headspace of theflasks). After washing the slurries with helium, headspace concentrations of O2, N2, N2O, NO and CO2were measured every 5 h for 182–235 h in the peat and mineral soil, respectively, using a fully automated, temperature controlled incubation system similar to that described byMolstad et al. (2007)with modifications documented inMolstad et al. (2016). We varied the length of the incubations with the aim of allowing time for treatments with lower denitrification rates to achieve complete denitrification of soil native and added NO3−, as indicated by a plateau in N2accumulation.

Theflasks were incubated in a temperature controlled water bath holding 30flasks, continuously stirred by submersible magnetic stirrers in a water bath. The flasks were sampled every 5 h by a hypodermic needle operated by an auto-sampler (CTC PAL). For each sampling,

∼1 ml of headspace gas is pumped to dedicated sampling loops of a gas chromatograph (Model 7890A, Agilent, Santa Clara, CA, USA) using a programmable peristaltic pump (Gilson minipuls3) with Marpren tubing. The GC is equipped with a 30 m PoraPLOT-U column operated at 36 °C for separating N2O, CH4and CO2from bulk gases and a 30 m 5ÅMolsieve column operated at 50 °C for separating N2and O2. Low concentrations of N2O were quantified by an electron capture detector operated at 340 °C using ArCH4(90/10 vol%) as make up gas. CO2, O2, N2and high mixing ratios of N2O were quantified by a thermal con- ductivity detector. Nitric oxide (NO) concentrations were measured by a chemoluminescence NOx-analyzer (Model 200A, Advanced Pollution Instrumentation, San Diego, CA) coupled inline to one of the sampling loops of the GC. Headspace pressure was kept constant at∼1 atm by automatically reversing the pump after sampling and backfilling with helium. Multiple internal standard gases were included. He-dilution and O2/N2leakage were evaluated in blankflasks and used to correct the gas kinetics as described by Molstad et al. (2007). Based on the observation that there was a significant early accumulation in N2in our flasks, an additional abiotic experiment with stirred biochar suspen- sions was performed to assess desorption kinetics of residual N2into the He-atmosphere of the headspace as a function of biochar HTT and dose.

This experiment is described in detail in the supplementary information (SI Section1). Dissolution of gas and modelled desorption of N2after helium-washing were modelled and subtracted from the measured N2

accumulation (for details see SI Section1).

2.4. Treatments

Soil equivalent to 1.5 g dry weight of peat and 2 g dry weight of

mineral soil was weighed into 120 ml serum flasks equipped with magnetic stirrers. Biochar was added at increasing rates of 1, 5, 10, and 20% w/w. For the peat soil an additional treatment 30% w/w was set up because we expected that the BC effect might be masked at low doses in the carbon rich peat. After adding 30 ml of MilliQ water, the flasks were sealed with butyl rubber septa and made anoxic by repeated evacuation and He-filling (six times), while continuously stirring the slurries. 10 ml of degassed 4 mM KNO3−solution was added, resulting in afinal concentration of 1 mM KNO3−(40μmol Nflask⁻¹). Allflasks were He-washed for an additional cycle before placing them in the water bath of the incubation system which was set to 15 °C. We chose this incubation temperature as it is closer to actual soil temperature in the temperate region than room temperature. After 10 min temperature equilibration, excess He was released. Headspace gases (CO2, O2, NO, N2O and N2) were monitored every 5 h until N2accumulation levelled off, indicating complete conversion of NO3−to N2. After termination of the incubation, the flasks were opened and slurry pH and residual NO3−

and NO2−

(in the mineral soil only) were measured (SI section 2), before drying the slurries to determine dry weight soil in each bottle.

2.5. Data analysis

Measured denitriﬁcation kinetics (Fig. S4a, b) were used to calcu- late a number of denitriﬁcation indices (Table 3,Fig. 1), including the N2O product ratio, N2O/(N2+N2O), calculated as a ratio of the integrated area under the curves for N2O and N2O + N2(Liu et al., 2010).

We refer to this index as the Integrated Product Ratio (IPR). Since the amount of total N denitrified throughout the incubation differed between treatments, a cutoffhad to be defined for calculating IPR. To account for differences in denitrification activity between the soils, the cut offfor the peat was chosen at 20μmol denitrified N, whereas the cut offfor the mineral soil, which was less active, was chosen at 5μmol denitrified N. The cut offs were chosen based on the lowest return of total μmol N denitrified among all treatments of each soil type throughout the full length of the incubation. Setting our limit in terms of μmol N denitrified, and not time, allowed us to normalise the treatments and to provide a more accurate comparison between treatments within each soil type. Other indices used were maximum denitrification (DRmax) calculated as the maximum rate of NO + N2O + N2

accumulation and the time needed since onset of anoxic incubation to obtain this maximum rate (TDRmax), as well as the maximum NO, N2O and N2concentrations reached during incubation, referred to as NOmax, N2Omaxand N2max, respectively.

2.6. Statistical analyses

In order to examine the relationship between the indices of deni- triﬁcation and biochar properties, we used PLSR (Martens, 1987). This method is not sensitive to issues of collinearity or autocorrelation and avoids arbitrary variable selection. We chose to use the biochar Table 2

Key properties of corn cob biochars used in this study. HTT - highest temperature treatment; BPCA:C - benzene polycarboxylic acid to carbon ratio, an indicator of aromaticity; B6CA:C–benzenehexacarboxylic acid to C ratio, an indicator of condensation; aliCH:aroCH–ratio of aliphatic to aromatic CHs measured by MIR; H:C, O:C–Elemental ratios; VM–Volatile matter; fC–Fraction ofﬁxed carbon; Ash–Ash fraction; CEC–Cation exchange capacity; SA–Surface area. All data fromBudai et al. (2014). SeeTable 3for methods of determination.

HTT BPCA:C B6CA:C aliCH:aroCH H:C O:C N:C VM fC Ash pH CEC SA

oC ratio Molar ratio % % % cmol/kg m²/g

105 18.34 0.00 4.52 1.62 0.89 0.0066 81.08 17.47 1.45 5.34 14.88 1.82

372 122.16 32.76 1.56 0.80 0.27 0.0061 40.46 57.42 2.12 8.84 14.86 1.26

416 164.16 45.01 0.75 0.59 0.17 0.0056 26.38 70.46 3.16 10.07 16.21 3.58

562 167.45 61.36 0.22 0.37 0.08 0.0083 12.66 83.94 3.40 9.36 13.46 44.93

796 192.58 136.02 0.23 0.13 0.04 0.0096 6.88 88.67 4.46 9.44 5.07 27.44

(4)

Table3 DatastructureforthePLSRmodelincludingdescriptionsofabbreviationsandanalysismethods. DataBlockaVariableUnitsDescriptionAnalysismethod X01NOmaxμmolNgdw−1MaximummeasuredN2OorNO-NaccumulationGCincubation X02N2OmaxμmolNgdw−1 X03N2maxμmolNgdw−1 X04IPRRatioIntegratedProductRatio.ThisistheN2Oproductratio[N2O/(N2O+N2)]calculatedusingthe integralofeachcurve. X05NO:N2OThisistheratioofNOtoN2Ocalculatedusingtheintegralofeachcurve. X06DRmaxμmolNgdw−1 hr−1ThisisthemaximumratemeasuredforthetotalNcurve. X07TDRmaxhrThisisthetimeatwhichthemaximumratewasachieved Y01VM1gflask−1Volatilematter-ASTMmethodD1762-84ASTMmethodD1762-84 Y02Ash1gflask−1Ashcontent-ASTMmethodD1102ASTMmethodD1102 Y03fC1%Fixedcarboncalculatedbydifferencebetween100%andthesumofmeasuredVMandash contents:=×−+fc%100ashfreefc fcvm% %%

derivedfromVMandAshcontent Y04SA1m2flask−1Surfacearea-measuredusingBrunauer–Emmett–Tellermethod Y05CEC1cmolflask−1CationExchangeCapacitymodifiedammoniumacetatecompulsorydisplacementmethod Y06FastCpool2gflask−1BiocharfastmineralisedlabileCpoolderivedfroma2poolmodelfittedtoanoxicincubation Y07H:C1Ratio:NoscalingElementalratiosderivedfromElementalanalysisLecoCHN1000analyzerandcoalreferencematerialTruSpecMakroanalyzerandO add-onmodule(LecoCorp.)Y08N:C1 Y09O:C1 Y10BPCA:C3RatiooftotalaromaticboundCtototalelementalC.BPCA:Cisanindicatorofcondensation.Benzenepolycarboxylicacidmethod. Y11B6CA:C3Ratiooffull6carbonboundtoelementalC.B6CA:Cisanindicatorofaromaticity. Y12Ali-CH:Aro-CH3TheratioofaliphaticCHtoAromaticCHderivedfromMidInfrared(MIR)analysis. aXblockmeasurementsweremadeusingtheincubationsystemandwererecordedperflask.Yblockmeasurementsarebiocharpropertiescalculatedonadoseperflaskbasiswherepossible.Allthevaluesand methodsfortheYblockvariablesweretaken:1.Budaietal.(2014)2.Budaietal.(2016)3.Budaietal.(2017).Ratioswerenotscaledtodose.

(5)

properties as response variables and denitriﬁcation indices as independent variables, as this allowed us to examine the distribution of treatments based on denitriﬁcation indices in the X matrix without imposing the highly structured values describing the pyrolysis gradient.

This was appropriate since we do not intend to use the PLSR for pre- dicting denitrification responses, but rather for exploring correlations between denitrification indices and biochar properties. Models were first built without the control soils, before subsequently projecting the control soil samples into the model. In this way we show the relation of the control soils to the biochar treatments without the lack of biochar properties in the control soils defining the model. Modelfit was judged by comparing the calibrated and validated explained variance in Y. All models werefit using the pls package in R (Mevik et al., 2015;R Core Team, 2017).

3. Results

3.1. Eﬀect of biochar HTT

In peat, the response of the IPR to biochar varied with HTT (Fig. 2a);

FS105 and BC372 strongly increased IPR at doses above 1%, BC416 had no effect, while BC562 and 796 strongly decreased IPR. Hence, the N2O product ratio of peat displayed a marked threshold with respect to HTT in the range between 372 and 562 °C, where the effect shifted from increasing to repressing N2O production relative to total denitrification.

In the mineral soil, biochars strongly reduced IPR independent of their HTT. Only the high (20%) dose of feedstock (FS105) increased the IPR (Fig. 2d). In non-amended controls, peat had a large innate N2O product ratio, while mineral soil produced little N2O and had a small innate N2O product ratio.

Biochars had little effect on the maximum denitrification rate (DRmax) in the carbon-rich peat soil except for the two highest doses of FS105 and BC416, which stimulated denitrification (Fig. 2b). Maximum denitrification was reached earlier with high-temperature biochars

(Fig. 2c) in the acid peat soil. By contrast, denitrification in the mineral soil was stimulated by low HTT biochar, particularly by BC372, and the feedstock (Fig. 2e), without affecting the time needed to reach maximum denitrification activity (Fig. 2f).

Fig. 3summarizes the effect of biochar addition on maximum N2O and NO accumulation over all HTT treatments and doses. N2O and NO accumulation was consistently reduced relative to the non-amended control when biochar produced at 562 °C and 796 °C was added to either soil, with a maximum reduction in N2O accumulation of 89% observed in peat soil with 30% w/w BC796 and of 98% with 20% w/w BC796 in the mineral soil (Fig. 3). The mineral soil accumulated approximately ten times less N2O than the peat soil (Fig. S4a, b). Inter- estingly, even the low-temperature biochar BC372 and low doses of FS105 reduced N2O accumulation in the mineral soil, which was not the case for the peat (Fig. 3). Likewise, NO and N2O accumulation in response to BC416 differed between soils. In peat, BC416 reduced NO accumulation but had little effect on N2O, whereas the opposite was the case in mineral soil. BC372 and FS105 stimulated N2O accumulation in the peat but reduced it in the mineral soil except for the 20% w/w dose of FS105. Thus, the N2O and NO response appeared to be soil dependent for biochar produced at or below 416 °C.

3.2. Eﬀect of biochar dose

In both soils, IPR responded strongly to biochar dose in the range of 1–5% w/w (Fig. 2a, d). Increasing the dose above 5% resulted in in- creasingly smaller response, irrespective of whether the effect was an increase or a decrease. Increasing the dose of biochar consistently decreased the accumulation of both NO and N2O in the BC562 and BC796 treatments of both soils (Fig. 3a, b). BC416 varied in its effect between the two soils, showing no dose effect on N2O accumulation in the peat soil while showing a dose effect comparable to the high temperature chars in the mineral soil. Higher application rates of FS105 and BC372 increased NO and N2O accumulation, particularly in the peat soil (Fig. 3 Fig. 1.Gas kinetics (a: NO, N2O, N2; b: N2O, NO + N2O + N2) and derived denitrification parameters in peat soil BC372 10% wt/wt (single bottle values). N2values in Fig. 1a are corrected for sampling loss, leakage and desorption whereas the transient accumulation of the intermediates NO and N2O are shown uncorrected. In Fig. 1b both N₂O and NO + N₂O + N₂are corrected for sampling loss to derive the integrated product ratio (IPR) from the integrals with a cut offof 20μmol N g dw soil⁻¹total denitrification. Denitrification parameters shown in Fig. 1a are NOmax, N2Omaxand N2maxand in Fig. 1b, DRmax, TDRmaxand IPR. The shading signifies the

(6)

a, b).

3.3. Relationship to BC properties

PLSR models for both soils (Fig 4a, c) confirmed the strong effect of pyrolysis temperature (HTT) on denitrification. HTT is represented by thefirst component in the model (Fig. 4a, component 1: X scores 77%, Y scores 60% explained variance,Fig. 3b, component 1: X scores 40%, Y scores 63% explained variance) with higher doses of BC372 and FS105 located at the left side of the plot and high temperature chars (BC416, 562 and 796) located to the right. For the peat, the second component (Fig. 4a, component 2: X scores 7%, Y scores 10% explained variance, Fig. 3b, component 2, X scores 22%, Y scores 9% explained variance) appears to represent biochar dose, with low doses located at the top and high doses located towards the bottom of the score plot. In the mineral soil, this trend was much less apparent, reflecting the variability between the two soils in the overall effect strength of dose. The higher

overall explained variance in both Y and X in thefirst component shows that the effect of temperature treatment prevailed over the effect of dose in affecting denitrification kinetics. The central grouping of the control soils (which were subsequently projected onto the model) and the 1% dose treatments confirms that low-dose biochar treatment had little effect on denitrification kinetics since they contributed little to the variation explained by component 1 and 2. The loading plots (Fig. 4b) revealed that in the peat, all denitrification indices except for the NO:N2O ratio were strongly positively correlated with H:C, O:C and the aliCH:aroCH ratio, and strongly negatively correlated with BPCA, B6CA, pH and SA (Fig. 4b). In the mineral soil, the correlation structure was similar, except for TDRmax(Fig. 4d). FastCpool appeared to play a more significant role in the minerals soil, while the opposite was true for SA. In the peat, measurements of denitrification activity, DRmaxand TDRmax, were strongly negatively correlated to SA and pH along component 1, respectively, whereas in the less active mineral soil, DRmax

was strongly negatively correlated to pH and less so to SA. TDRmax

Fig. 2.Scatter plot showing selected denitrification variables (Integrated product ratio (IPR), Maximum denitrification rate (DR_max) and Time needed to reach maximum denitrification (TDRmax)) in slurries of peat (a, b, c) and mineral soil (d, e, f) amended with different corn cob HTT biochars plotted against dose. Mean values for control soils without biochar are represented along with the standard deviation (n = 3) as dotted lines.

Fig. 3.Eﬀect of biochar addition on maximum N₂O and NO accumulation in anoxic batch incubations of peat and mineral soil. The values are calculated as relative diﬀerence from the un-amended control (in %).

(7)

played no role in the mineral soil owing to the lack of exponential product accumulation in this soil.

Biochar pH was highly negatively correlated with maximum NO and N2O accumulation in both soils and positively correlated with the ratio of NO to N2O along component 1, which increased with increasing pyrolysis temperature and dose in both soils (Fig. S7). SA, which was scaled toﬂask, showed a strong positive correlation with NO:N2O in the peat, but a somewhat weaker correlation in the mineral soil. VM and CEC had little impact on the correlation structure in both soils. The FastCpool which mainly represents the large labile carbon pool in the feedstock, appeared to play a more signiﬁcant role for NO and N2O accumulation in the mineral than the peat soil.

N2maxwas removed from the peat model since added N was com- pletely transformed to N2in all treatments (Fig. S4a), i.e. reaching close to mass balance between added and recovered gaseous N. By contrast, in the mineral soil, analyses of residual NO3−and NO2−post-incubation (Fig. S3) revealed that denitriﬁcation was incomplete for treatments with high-temperature chars and low doses of BC372. Interest- ingly, less gaseous N was recovered with high doses of FS105 and BC372 despite complete conversion, indicating immobilization or sorption of added NO3−-N. Therefore, N2maxwas positively correlated with biochar properties representing C availability (FastCpool, ali- CH:aroCH, O:C and H:C) and negatively with properties indicating the degree of carbonisation (B6CA:C, BPCA:C) in the mineral soil (Fig. 4d).

In the mineral soil only the 20% w/w dose of BC372 and all doses of FS105 induced exponential N2 accumulation indicative of denitriﬁer growth (Fig S4b). In the peat, all biochar treatments showed exponential N2 accumulation, which, however, diﬀered strongly with

biochar HTT (Fig. S4a). The onset of exponential production occurred earlier with high HTT chars, which was well captured by TDRmax, i.e. the time needed to achieve the steepest slope of N2production. N2accu- mulation eventually changed to linear accumulation (Fig. S4a) suggesting that denitriﬁer growth became substrate limited. This change occurred earlier with high temperature chars (Fig S4a). No such linear phase in product accumulation was seen in peat soil amended with feedstock and the highest doses (20 and 30%) of BC372 (Fig. S4a).

4. Discussion

4.1. Which process dominated nitrate reduction?

We assert that the predominant NO3− reduction pathway in our flasks was denitrification, even though there exist a number of alter- native pathways (DNRA, anammox, chemodenitrification, co-denitrification) dissipating NO3−under anoxic conditions. Both DNRA and anammox are favoured by high pH (Zhang et al., 2015) and are considered to be of limited significance in well drained upland soils (Schmidt et al., 2011;Ligi et al., 2015;Xi et al., 2016). Anammox, in particular, requires the accumulation of nitrite (Long et al., 2013), which only occurs in moderately acidic to alkaline soil. The mineral soil incubations accumulated considerable amounts of NO2− (Fig. S3) concomitant with rising pH in the slurries (Fig. S5b), however, the fact that NO2− accumulated at the end of the experiment suggests that NO2−consumption by anammox was not the dominating process. Co- denitrification (Spott et al., 2011) may have been an important process in our peat due to the abundance of organic N moieties. However, we Fig. 4.PLSR models for peat (top: a & b.) and mineral soil (bottom: c & d). X scores plots (left a & c.) represent the objects/rows in matrix X and Y and show how the objects relate to one another in the multivariate space spanned by the model. X & Y correlation loading plots (right b & d) show the X (explanatory, blue) and Y (response, red) correlation loadings. The X & Y loading plot represents percent explained variance of each variable, variables within the inner circle have less than 50% of variance explained by the components, variables within the outer ring have greater than 50%

variance explained by the 2 plotted components. Variables close to one another on this plot are highly positively correlated for the part of the data explained by the 2 components. (For interpretation of the re- ferences to colour in thisﬁgure legend, the reader is referred to the Web version of this article.)

(8)

assume that the utilisation of this additional N source would have al- tered the mass balance of recovered N2-N relative to the added NO3−-N.

Since we did not see this in our incubations with the peat soil, we assume that co-denitriﬁcation was negligible. Chemodenitriﬁcation, i.e.

the dismutation of protonized nitrite (HNO2) to NO and N2O and/or the reaction of HNO2 with redox active compounds on mineral surfaces cannot be ruled out and is addressed later in the discussion. A study by Wankel et al. (2017), however, suggested that in the presence of high NO3− concentrations, bacterial and fungal denitrifiers are likely to dominate N2O and N2production. For these reasons we are confident that the dominating process of NO3−consumption in our experiments was canonical denitrification, with minor interference from other NO3−/NO2−dissipating processes.

4.2. Biochar produced at high temperature reduces N2O and NO emission

Accumulation of N2O and NO was consistently reduced when corncob biochars produced at 562 °C and 796 °C were added to either soil. Our results do not allow us to define a precise HTT threshold responsible for this effect, however 416 °C appeared to be a pyrolysis temperature above which there was a neutral to supressing effect on NO and N2O release in both soils (Fig. 2). The two biochars which reduced N2O and NO the most were the ones with the highest degree of carbonisation as indicated by low H:C, O:C, aliCH:aroCH and high BPCA:C and B6CA:C ratios (Table 2). In a meta-analysis,Cayuela et al. (2015) found that a biochar H:C ratio < 0.3 is a good predictor for N2O suppression. We found consistent N2O suppression with BC562 and BC796, which had H:C values of 0.37 and 0.13, respectively, while BC416, which showed an inconsistent effect had a H:C ratio of 0.59. Therefore our results support the concept of H:C being a predictor for suppression of N2O emissions from denitrification and extend this concept to NO emissions. Our results also suggest that there is a plateau in the mitigation potential beyond a specific HTT as evidenced by the quite similar responses to BC562 and BC796.

Pronounced NO and N2O suppression in the presence of high temperature chars points towards several key properties involved in N2O suppression. Carbonisation and aromaticity (BPCA:C, aliCH:aroCH) as well as condensation (B6CA:C) increase with increasing HTT and condensed polyaromatic structures of chars have been shown to carry electro-chemical properties (Klüpfel et al., 2014a), which may facilitate redox reactions taking place during denitriﬁcation (Chen et al., 2018).

However, in our study, increasing degree of carbonisation also correlated positively with other properties such as ash content, pH and SA.

The high correlation of SA with indicators of denitriﬁcation in the peat soil and pH in both soils suggests that pH and SA could be causally involved in N2O suppression by biochar.

SA was negatively correlated with NO and N2O accumulation and positively with the ratio of NO:N2O. SA, which has been proposed as a proxy for the sorption capacity of biochar for organic compounds (Hale et al., 2016), may increase NO and N2O reduction rates by con- centrating these denitrification intermediates locally around chars thus increasing the effective concentration for the catalytic reaction (Harter et al., 2016). Interestingly, the effect of higher temperature chars in the peat soil was larger for N2O than NO, suggesting a stronger relative effect of biochar on N2O than NO accumulation (Fig S7). The shape of the SA response to pyrolysis temperature for our biochars differs substantially from that of H:C or pH (Budai et al., 2014), and is defined by a peak in SA at BC562 followed by a reduction at BC796. Although it has been shown that biochar can permanently sorb N2O under anhydrous conditions (Cornelissen et al., 2013), this was probably not the case in our soil slurries as plateauing N2-N accumulation in peat incubations indicated that N2O-N was fully denitrified. Our results instead support the hypothesis ofHarter et al. (2016), who argued that the ability of biochar to sorb N2O transiently increases its residency time and local concentration, thereby facilitating microbial reduction.

Biochar pH appeared to be another key variable linked to NO and

N2O suppression, as indicated by the opposite position of these two variables in the PLSR loading plots (Fig. 4). Over the range of pyrolysis temperatures, the pHH2Oof our biochar, measured in water, plateaued at 416 °C with a value of 10.07 (Table 2). Despite highest pH in the BC416 treatment, measurements of slurry pH after 182–235 h of stirred anoxic incubation showed a strong linear correlation between pH and ash content of the biochar that increased with pyrolysis temperature through the entire range of BC pyrolysis temperatures (Fig. S6). This suggests that biochar ash contributed significantly to the observed al- kalisation, likely owing its high proportion of secondary carbonates and base cations (Yuan et al., 2011). The liming effect of biochar in acidic soils can strongly reduce NO accumulation by repressing the chemical dismutation of nitrous acid (HNO2), the protonated form of NO2−, to NO (Chalk and Smith, 1983). Low pH is also known to impair N2O reductase (N2OR), the enzyme responsible for N2O reduction, with increasing inhibitory effects below pH 6.1 (Liu et al., 2014;Brenzinger et al., 2015). However, in our study, while the pH of the biochar strongly correlated with denitrification indices, the ash content did not (Fig. 4). This may be because the ash content can have confounding effects on other variables influencing denitrification. For instance, it has been suggested that ash can result in salting out of N2O from solution, which would increase N2O release (Yanai et al., 2007).

4.3. Biochar prepared at low temperature has contrasting eﬀects on N2O emission in mineral soil and peat

The low-temperature char (BC372) was characterized by a low degree of carbonisation and high O:C and H:C ratios, high VM and low ash content. Stimulation of N2O emissions by low-temperature chars has been reported previously (Kammann et al., 2012;Li et al., 2013). A re- analysis of the data synthesized inCayuela et al. (2015)shows that high H:C chars have a potential to stimulate N2O emissions (p < 0.01, SI section 4). However, this eﬀect appears to be less clear-cut than the < 0.3 threshold for N2O suppression, suggesting that there are other, interacting factors modulating the relationship between H:C >

0.3 and N2O emission.

The contrasting effects of low temperature char (BC372) and feedstock (FS105) on N2O accumulation in the two soils suggests that soil properties interacted with biochar in its effect on denitrification. The most obvious differences between peat and mineral soil were carbon content (53.0 vs 2.8%), C/N ratio (29.5 vs. 9.8), CEC (1480 vs.

51 cmol kg⁻¹) and pHH2O (5.1 vs 5.9). Surprisingly, low-temperature char and feedstock increased N2O accumulation in the carbon-rich peat, which supported high denitrification rates, indicating ample decomposable carbon. One would expect that adding low-temperature char and feedstock, with their relatively large pool of readily decomposable carbon, to this carbon rich peat would have little or no effect on denitrification and its product stoichiometry. Studies have suggested that adding labile C to a system with limited biologically available carbon would increase the reductant-to-oxidant ratio (DOC:NO3−), which should result in more complete denitrification (Senbayram et al., 2012).

This mechanism could explain the observed kinetics in the mineral soil where low temperature char and feedstock caused an increase in total denitriﬁcation (Fig S4b, S3) accompanied by an overall reduction in N2O accumulation (Fig. 3b). A closer inspection of the N2kinetics of peat revealed that the FS105 and BC372 treatments accumulated N2

much slower than the treatments with high-temperature chars (Fig.

S4b). Accordingly, TDRmax, the time needed to express maximum denitrification activity, was larger and positively correlated with indices of low carbonisation degree (Fig. 4b). While the faster increase in denitrification activity with high-temperature chars may be explained by their stronger alkalizing effect (Fig. S5), it is unclear which properties of low-temperature biochar and feedstock caused this delay. Acid peat soils are known to harbour denitrifier communities with low taxonomic diversity and hence limited metabolic versatility (Palmer et al., 2010;

Braker et al., 2012;Dörsch et al., 2012). Addition of allochthonous C-

(9)

sources, in the form of dried corn cob or its low-temperature pyrolysis product, to anoxic incubations may have triggered growth of competing functional groups (e.g. fermenters). This may have initially repressed denitrifier activity, until denitrifier community composition changed (e.g.Brenzinger et al., 2015) and supported exponential N2accumula- tion with high DRmaxvalues and rapid N2O uptake. We therefore ten- tatively attribute the N2O stimulating effect of low-temperature corncob biochar and its feedstock to some unidentified disruption of initial denitrification activity resulting in transiently incomplete denitrification.

4.4. Biochar and denitriﬁcation: which biochar properties matter?

The signiﬁcant variables for explaining the N2O mitigation eﬀect of biochar in our study were carbonisation indices, pH and SA (Fig. 4b, d).

Carbonisation indices encapsulate concurrent changes in biochar properties: 1) disappearance of labile organic carbon with increasing temperature, and 2) formation and condensation of aromatic structures with increasing temperatures. This implies that one must consider the effects of both labile organic carbon structures at low pyrolysis temperature and condensed aromatic sheet formation at higher temperature when assessing potential biochar effects on denitrification.

Aromatic structures of chars formed at higher pyrolysis temperature have been shown to alter the electro-chemical properties of biochar (Klüpfel et al., 2014a) which can mediate redox reactions (Kappler et al., 2014;Chen et al., 2018). Our experiment does not provide direct evidence for this effect, but the more efficient denitrification, represented by smaller TDRmaxand lower accumulation of intermediates, could be due to redox reactions mediated directly by the biochar. In a peat soil, however, which contains abundant redox active components (Klüpfel et al., 2014b), it is unlikely that the addition of biochar would have a measurable impact on these processes.

The effect of pH on heterotrophic denitrification is well established (as reviewed inBlum et al., 2018). pH affects not only the accumulation of intermediates (Kappelmeyer et al., 2003) but low pH is also well documented to inhibit the reduction of N2O to N2(Šimek and Cooper, 2002;Bakken et al., 2012). Low pH does not affect the transcription of nosZ, the gene encoding for N2O reductase, but its functioning appears to be impaired post-transcriptionally (Bergaust et al., 2010). The pH of both of our soils was lower than the pH threshold of 6.1 for fully functional N2O reductase proposed byLiu et al. (2010)andBrenzinger et al. (2015), i.e. pH 5.86 for the mineral soil and 5.08 for the peat (Table 1). However, the pH of the anoxic slurries increased as denitrification progressed, surpassing this threshold (Fig. S5). The peat was more buffered, with a higher CEC (Table 1), than the mineral soil (Fig.

S6), which probably explains why the pH in biochar treatments of the peat soil was more highly correlated with IPR and TDRmaxand with the total accumulation of intermediates, i.e. NOmaxand N2Omax, (Fig. 4b).

The higher buﬀering capacity of the peat also resulted in a more pro- gressive denitriﬁcation response to pH over the full range of dose (Fig. 3). The strong negative correlation between TDRmax and pH (Fig. 4b) shows that biochar accelerated the induction of a measurable N2O reduction.

Biochar SA is an indicator for the sorption capacity of biochar (Hale et al., 2015) and is a result of the concurrent loss of amorphous carbon and the development of graphitic structures and highly reduced surface functional groups. There are several potential mechanisms by which biochar SA could affect denitrification.Cornelissen et al. (2013)proposed permanent sorption of N2O to biochar surfaces. Others have suggested that biochar can sorb DOC, reducing access to electron do- nors (Lu et al., 2014). Because we see no effect of high SA biochar on the recovery of added N, our results support neither permanent sorption of N2O nor reduced access to DOC as mechanisms. By contrast, our results support the hypothesis of more complete denitrification due to increased residency time of N2O on or near biochar surfaces through temporary sorption (Harter et al., 2016). Along with the other

mechanisms we have discussed, such as pH and carbonisation degree, this could explain the positive correlation we observed between NO and N2O suppression and SA of the biochars (Fig. 4b).

In summary, we used a well-characterized biochar temperature series with continuously scaled properties in standardized denitrification assays to examine which biochar properties are responsible for the observed effect of biochar on N2O emissions from denitrification. Our results suggest that biochar effects on N2O emissions from denitrification are variable, or even contrasting, depending on which soils are used. Biochar from a single feedstock type can shift from stimulating N2O emissions to reducing them over a relatively small range of HTT, highlighting that the N2O effect of biochar is likely not caused by a single property of the biochar. We further show that biochar is interacting not only with thefinal reduction step of denitrification but may also impact total denitrification.

Contrary to our highly standardized experimental design, environmental conditions in bulk soil vary substantially in time and space.In situN2O emissions are highly variable in time, driven by events such as fertilization, rewetting, tillage or freeze-thaw. In these conditions per- iods of high emissions can last over several days and are likely driven by denitrification (Flessa et al., 1995). While the effect of biochar on event- driven N2O emissions is largely unknown (Edwards et al., 2018), our study focuses primarily on denitrifier response to longer lasting anoxia in the presence of biochar. Our study shows how biochar interacts with denitrification and potentially lowers the N2O product ratio under those conditions. We demonstrate a link between biochar properties and denitrification functioning for one specific corncob feedstock. We are confident that our results with corncob biochar are relevant for a range of other biochars, as we have shown previously that corncob biochar is comparable in chemical and physical properties to those produced from other grass feedstocks over wide ranges of pyrolysis temperature (Budai et al., 2014,2017). However, key response variables highlighted in our study, such as SA and pH, can be manipulated not only through feedstock selection but also through post-processing of biochar products (Chintala et al., 2013; Rajapaksha et al., 2016). Because substantial reduction of N2O emission from agricultural soils is needed, future in- vestigations should specifically target the effects of biochar-property enhancement, thereby supporting the transition from mechanistic understanding to pilot implementation.

Declaration of interests None.
