Service life design of concrete structures : aktivitet DP1 B4

(1)

BETONGKONSTRUKSJONERS LIVSLØP

Et utviklingsprosjekt i samarbeid mellom offentlige byggherrer, industri og forskningsinstitutter

Deltakere:

Statens vegvesen (prosjektledelse), Forsvarsbygg, NORCEM A.S, Selmer Skanska AS, Sika Norge AS, Norges byggforskningsinstitutt, NTNU, SINTEF, NORUT Teknologi as

Prosjektet er støttet av BA-programmet i Norges forskningsråd

Rapport nr. 19

Service Life Design of Concrete Structures Aktivitet DP1 B4

(2)

BETONGKONSTRUKSJONERS LIVSLØP

Rapport nr. 19

Service Life Design of Concrete Structures

Aktivitet DP1 B4
