FACULTY OF SCIENCE AND TECHNOLOGY
MASTER'S THESIS
Study programme/specialisation:
Petroleum Technology/Well Engineering
Spring semester, 2017 Open access
Author: Thomas Monge Øia
………
(signature of author)
Faculty Supervisor: Kjell Kåre Fjelde, University of Stavanger External Supervisor: Per Buset, Island Offshore Subsea AS
Title of master's thesis: Futuristic Approach to Riserless Plug and Abandonment Operations
Credits: 30
Keywords:
Riserless P&A Operation, Riserless Coiled Tub- ing Operation, P&A operation performed from a RLWI vessel, Rig-less retrieval of production tubing and casing, Operational sequences
Number of pages: 142
+ supplemental material/other: 8
Stavanger, 13 June 2017
